Baud Rate Dip Switch Selection
2.4.3 Select and Load Configuration Files
•
The S bank of DIP switches, S0 - S3 is used to select and load a configuration file from a group of pretested/preloaded
configuration files that the OEM has programmed for their end users.
•
End customers will need to go back to the OEM of the device that they are installing to get the DIP settings for the
ProtoNode. The ProtoNode part number will need to be provided to identify the unit.
8
Baud
B0
B1
B2
9600
On
On
On
19200
Off
Off
Off
38400*
On
On
Off
57600
Off
Off
On
76800
On
Off
On
* Factory default setting = 38400
ProtoNode Start-up Guide
B3
Off
On
On
On
On
