THORLABS CVH100-COL Quick Reference Manual

Quick reference guide
The CVH100-COL fiber port can be used as an accessory to
the CVH100 cuvette holder. It holds ½" diameter lenses and
connects to SMA Multimode fibers. Therefore you can choose
from a wide range of optical materials to suit your application
and wavelength range.
Alternatively it mounts onto any SM1 internal thread used for
a wide range of opto-mechanic components of Thorlabs.
Ordering codes and Accessories
Ordering code
CVH100-COL
SM05RR
SM005LTRR
M25L01
BFH22-200-030-SMA-1M*
*
Non standard item, on special request
Please see our website for further information
Unpacking the CVH100-COL
Inspect the shipping container for damage. If the shipping container seems to be
damaged, keep it until you have inspected the contents and you have inspected the
CVH100-COL.
Verify that you have received the following items:
• CVH100-COL, SMA fiber port with 1/2" lens mounting option
• 2x spacers tubes
• SM 0.5 retaining ring
• Quick reference guide
Short description
SMA fiber port (SM1) with ½" lens mounting option
SM05 retaining ring
SM05 series stress-free retaining ring
SMA-SMA MM fiber, 200µm, Low-OH, 1m (VIS/NIR)
SMA-SMA MM fiber, 200µm, High-OH, 1m (UV)
