KERR ENDODONTICS Elements 8:1 Instructions For Use Manual page 75

7 Reprocessing steps in accordance with ISO 17664
Servicing the chuck
KaVo recommends servicing the chuck system once a week using
the chuck servicing program integrated in the device.
Note
Handpieces must be taken off the service couplings before the
chuck service can be started and performed.
▶ Close the front door and press the chuck service button for
at least three seconds until the spray canister control LED
flashes three times consecutively.
ð The device is in chuck service mode.
▶ Remove the service coupling of the chuck from the side
hatch of the QUATTROcare PLUS and attach it to coupling
service point four, on the far right. A MULTIflex adaptor
must be mounted there.
73 / 268
