Cisco Modular Gigabit Ethernet Line Card I Installation And Configuration Manual page 3

Ensure that the connector guide pins are aligned. Once the connector is engaged, apply gentle pressure
Step 3
with your thumbs to the two rear outer corners of the EPA, as shown in
Figure 4
Figure 5
78-17296-01 A0
Press on the Rear Outer Corners of the EPA
Rear Outer Corners of the EPA (Close-up)
PUSH PUSH
BOTH
CORNERS CORNERS
TO
INSTALL INSTALL
BOTH
TO
Inserting an EPA into a Modular Gigabit Ethernet Line Card
Figure 4 and Figure 5.
3
