  • Page 1 Integrated Dishwasher instruction manual Di651 Contact Caple on 0117 938 7420 or for spare parts www.caple.co.uk Di651 Intergrated Dishwasher.indd 1 08/02/2017 12:59...
  • Page 2: Table Of Contents

    CONNECTION OF DRAIN HOSES DISHWASHER INSTALLATION STEPS ELECTRICAL CONNECTION COLD WATER CONNECTION TROUBLESHOOTING TIPS ERROR CODES TECHNICAL INFORMATION TECHNICAL FICHE CAPLE CONTACT DETAILS Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 2 08/02/2017 12:59...
  • Page 3: Warnings

    - This appliance is for indoor household use only. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 3 08/02/2017 12:59...
  • Page 4 - Improper connection of the equipment-earthing conductor can result in the risk of an electric shock. - Check with a qualified electrician or Caple service representative if you are in doubt whether the appliance is properly grounded.
  • Page 5 - Use only detergent and rinse additives designed for an automatic dishwasher. - Never use soap, laundry detergent, or hand washing detergent in your dishwasher. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 5 08/02/2017 12:59...
  • Page 6 - The appliance may only be used with correctly adjusted door springs. - If the supply cord is damaged, it must be replaced by Caple, its service agent or a similarly qualified person in order to avoid a hazard. - During installation, the power supply must not be excessively or dangerously bent or flattened.
  • Page 7 - DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of such waste separately for special treatment is necessary. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 7 08/02/2017 12:59...
  • Page 8 This appliance has been manufactured to the strictest standards and complies with all applicable legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility (EMC). Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 8 08/02/2017 12:59...
  • Page 9: Quick Operation Guide

    Unload the Dishwasher more susceptible to break. They will also dry better.Unload the appliance, starting from the lower basket Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 9 08/02/2017 12:59...
  • Page 10: Control Panel

    Eg: program time program time Delay time 4. Status Indicators: Faucet is not open Rinse detergent needs to be refilled Salt needs to be refilled Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 10 08/02/2017 12:59...
  • Page 11: Dishwasher Features

    - Add 1.5Kg dishwasher salt and then fill the salt container with water - Fill the rinse aid dispenser - Fill in detergent Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 11 08/02/2017 12:59...
  • Page 12: Water Softener

    3.1-4.0 23-34 41-60 29-42 4.1-6.0 35-55 61-98 43-69 6.1-9.8 NOTE: 1 NOTE: 2 °dH=1.25 °Clarke=1 1.78°fH=0.178mmol/l The manufactory setting: H3 °dH: German degree (EN 50242) °fH: French degree °Clark: British degree Instruction manual Di651 Di651 Intergrated Dishwasher.indd 12 08/02/2017 12:59...
  • Page 13: Loading The Salt Into The Softener

    After filling the container, screw the cap tightly back on, turning clockwise. The salt warning light will turn off after the salt container has been filled with salt. Di651 Intergrated Dishwasher.indd 13 08/02/2017 12:59 Immediately after filling the salt into the salt container, a washing program should be started...
  • Page 14: Fill The Rinse Aid Dispenser

    Only use branded rinse aid for dishwasher. Never fill the rinse aid dispenser with any other substances (e.g. Dishwasher cleaning agent, liquid detergent). This would damage the appliance. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 14 08/02/2017 12:59...
  • Page 15 Clean up any rinse aid spilled during filling with an absorbent cloth to avoid excessive foaming during the next wash. Don’t forget to replace the cap before you close dishwasher door. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 15 08/02/2017 12:59...
  • Page 16: Function Of Detergent

    DETERGENTS There are 3 sorts of detergents 1.With phosphate and with chlorine 2.With phosphate and without chlorine 3.Without phosphate and without chlorine Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 16 08/02/2017 12:59...
  • Page 17 Always add the detergent just before starting each wash cycle. Always add the detergent just before starting each wash cycle. Only use branded detergent aid for dishwasher. Only use branded detergent aid for dishwasher. Di651 Intergrated Dishwasher.indd 17 08/02/2017 12:59...
  • Page 18 (e.g. in cutlery Please keep this instruction manual for future reference sket, detergent compartment, etc.). ke sure that the lid on the detergent mpartment is closed, even if you are Instruction manual Di651 ng tablets. Di651 Intergrated Dishwasher.indd 18 08/02/2017 12:59...
  • Page 19: Loading The Dishwasher Basket

    - Pewter or copper items - Crystal glass - Steel items subject to rusting - Wooden platters - Items made from synthetic fibres Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 19 08/02/2017 12:59...
  • Page 20 - Please do not overload your dishwasher. This is important for good results and for reasonable consumption of energy. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 20 08/02/2017 12:59...
  • Page 21: Loading The Upper Basket

    Pull handle and lower ft the basket for Instruction manual Di651 for lower position pper position Do not let any item Di651 Intergrated Dishwasher.indd 21 08/02/2017 12:59...
  • Page 22 Cups Saucers Glasses Small serving bowl Medium serving bowl 2. Lower basket Large serving bowl Dessert dishes Dinner plates Soup plates Oval plates Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 22 08/02/2017 12:59...
  • Page 23 Instruction manual Di651 t let any item Do not let any item Do not let any item Di651 Intergrated Dishwasher.indd 23 08/02/2017 12:59...
  • Page 24: Cutlery Tray

    Mode 3 Position three: lift the right tray up, both left and right trays are flat. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 24 08/02/2017 12:59...
  • Page 25 Mode 5 Position Five: Remove the right tray from the tray, only has the left tray. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 25 08/02/2017 12:59...
  • Page 26 3. Knives 7. Serving forks 4. Teaspoons 8. Gravey ladies WARNING: Do not let any item extend through the bottom of the tray. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 26 08/02/2017 12:59...
  • Page 27: Wash Cycle Table

    12.5 1 pieces Rinse (65˚C) wash. Drying Radid A shorter wash for Wash (45˚C) lightly soiled loads and Rinse (55˚C) 0.75 quick wash. Rinse (55˚C) « Fill rinse-aid into the dispenser Instruction manual Di651 Di651 Intergrated Dishwasher.indd 27 08/02/2017 12:59...
  • Page 28: Turning On The Appliance

    After you close the door, the machine will continue working again. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 28 08/02/2017 12:59...
  • Page 29: At The End Of The Wash Cycle

    Basket onto the dishes in the lower one. WARNING: It is dangerous to open the door during a wash cycle, because the hot water or steam may scald you. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 29 08/02/2017 12:59...
  • Page 30: Cleaning And Maintenance

    - Improper replacement of the filter may reduce the performance level of the appliance and damage dishes and utensils. Step 1 Turn the filter in anti-clockwise direction, : Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 30 08/02/2017 12:59...
  • Page 31 When cleaning the filters, don’t knock on them. Otherwise, the filters could be contorted and the performance of the dishwasher could be decreased. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 31 08/02/2017 12:59...
  • Page 32: Caring For The Dishwasher

    4. Reconnect the water inlet pipe to the water valve. 5. Remove the filter at the bottom of the dishwasher and use a sponge to soak up water in the sump. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 32 08/02/2017 12:59...
  • Page 33 One of the factors that cause odours to form in the dishwasher is food that remains trapped in the seals. Periodic cleaning with a damp sponge will prevent this from occurring Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 33 08/02/2017 12:59...
  • Page 34: Installation Instruction

    One side of the cabinet sink should be chosen to facilitate the connection of drain hoses of the dishwasher. NOTE: Please check the accompanying installation accessories (fixing for aesthetic door panel). Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 34 08/02/2017 12:59...
  • Page 35 Figure 3. The aesthetic door panel could be processed according to the Figure 3. Please keep this instruction manual for future reference Instruction manual Di651 【 Figure3 】 Di651 Intergrated Dishwasher.indd 35 08/02/2017 12:59 hould...
  • Page 36 Figure3 【 】 The aesthetic door panel should be processed in accordance with the illustrated dimensions (Unit: mm) (Unit: mm) Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 36 08/02/2017 12:59...
  • Page 37 . Remove the four screws screws short screws insert the four long screws 2. Insert the four long screws Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 37 08/02/2017 12:59...
  • Page 38: Tension Adjustment Of The Door Spring

    Front Counter 1000mm. Drain pipe NOTE The top of the hose must be less than 1000mm. φ 40mm Please keep this instruction manual for future reference Instruction manual Di651 Drain pipe Di651 Intergrated Dishwasher.indd 38 08/02/2017 12:59 φ 40mm...
  • Page 39: Dishwasher Installation Steps

    (6). B. Marble or granite work top:Fix the side with Screw. (7). Figure 7 【Figure 7】 Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 39 08/02/2017 12:59...
  • Page 40 If the electrical socket to which the appliance must be connected is not appropriate for the plug , replace the socket, rather than using a adapter as they could cause overheating Di651 Intergrated Dishwasher.indd 40 08/02/2017 12:59 and burns.
  • Page 41: Electrical Connection

    Do not modify the plug provided with the appliance; If it is not fit for the outlet. Have a proper outlet installed by a qualified electrician. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 41 08/02/2017 12:59...
  • Page 42: Cold Water Connection

    Ensure that the water inlet hose is not kinke Extension Hose Instruction manual Di651 If you need a drain hose extension, make s It must be no longer than 4 metres; otherwis Syphon Connection Di651 Intergrated Dishwasher.indd 42 08/02/2017 12:59...
  • Page 43 5. The power is switched on 6. The inlet and drain hoses are not knotted 7. All packing materials and printings should be taken out from the dishwasher Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 43 08/02/2017 12:59...
  • Page 44: Troubleshooting Tips

    The lid of the softer Check the lip .Ensure the fix is fine. is loose Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 44 08/02/2017 12:59...
  • Page 45 Use a mild abrasive cleaner to eliminate those marks. dishes dishes. Detergent left in Dishes block Re-loading the dishes properly dispenser detergent cups. cups Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 45 08/02/2017 12:59...
  • Page 46: Error Codes

    - If there is water in the base pan because of an overfill or small leak, the water should be removed before restarting the dishwasher. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 46 08/02/2017 12:59...
  • Page 47: Technical Information

    Power supply: see rating label Water pressure: 0.04-1.0MPa Power supply: see rating label Capacity: 15 place settings Capacity: 15 place settings Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 47 08/02/2017 12:59...
  • Page 48: Technical Fiche

    55 cm Power consumption 1930 W Rated voltage / frequency 230 V~ / 50 Hz Water pressure (flow pressure) 0.4-10 bar = 0.04-1 MPa Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 48 08/02/2017 12:59...
  • Page 49 Results may vary greatly according to quantity and pollution of the dishes, water hardness, amount of detergent, etc. The manual is based on the European Union’s standards and rules. Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 49 08/02/2017 12:59...
  • Page 50 Notes: Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 50 08/02/2017 12:59...
  • Page 51 Notes: Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 51 08/02/2017 12:59...
  • Page 52: Caple Contact Details

    Caple Service Fourth Way Avonmouth Bristol BS11 8DW t: 0117 938 7420 e: service@caple.co.uk www.caple.co.uk Please keep this instruction manual for future reference Instruction manual Di651 Di651 Intergrated Dishwasher.indd 52 08/02/2017 12:59...
