Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk
Di641 Intergrated Dishwasher.indd 1
Di641 Intergrated Dishwasher.indd 1
D i s h w a s h e r
I n s t r u c t i o n M a n u a l
D I 641
07/01/2020 16:55
07/01/2020 16:55

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DI641 and is the answer not in the manual?

Questions and answers

Related Manuals for Caple DI641

Summary of Contents for Caple DI641

  • Page 1 D i s h w a s h e r I n s t r u c t i o n M a n u a l D I 641 Contact Caple on 0117 938 7420 for spare parts or www.caple.co.uk Di641 Intergrated Dishwasher.indd 1 Di641 Intergrated Dishwasher.indd 1...

  • Page 2: Table Of Contents

    Cleaning and Maintenance Caring for the Dishwasher Installation Instruction Built-In Installation Instruction Troubleshooting Technical Information Caple Contact Details Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 2 Di641 Intergrated Dishwasher.indd 2 07/01/2020 16:55 07/01/2020 16:55...
  • Page 3 - Please unplug before cleaning or performing maintenance on the appliance. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 3 Di641 Intergrated Dishwasher.indd 3 07/01/2020 16:55 07/01/2020 16:55...
  • Page 4 - Improper connection of the equipment-earthing conductor can result in the risk of an electric shock. - Check with a qualified electrician or Caple service representative if you are in doubt whether the appliance is properly grounded.
  • Page 5 - The appliance may only be used with correctly adjusted door springs. - If the supply cord is damaged, it must be replaced by Caple, its service agent or a similarly qualified person in order to avoid a hazard. - During installation, the power supply must not be excessively or dangerously bent or flattened.

  • Page 6: Warnings

    Use the required 10 amp fuse, time delay fuse or circuit breaker recommended and provide separate circuit serving only this appliance. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 6 Di641 Intergrated Dishwasher.indd 6 07/01/2020 16:55 07/01/2020 16:55...
  • Page 7 If it is not fit for the outlet. Have a proper outlet installed by a qualified electrician. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 7 Di641 Intergrated Dishwasher.indd 7 07/01/2020 16:55 07/01/2020 16:55...

  • Page 8: Environmental Protection

    (placed on the inside of the appliance storage drawer). Registration can also be completed online by visiting www.caple.co.uk. Ensure you keep your warranty card safe, you may need to show it to Caple Service together with proof of purchase.

  • Page 9: Control Panel

    4 - H A L F - L O A D of the Half Load button cycles between upper rack only and lower rack only. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 9 Di641 Intergrated Dishwasher.indd 9 07/01/2020 16:55 07/01/2020 16:55...
  • Page 10 If the “ ” indicator is lit, it means the dishwasher is low on dishwasher salt and needs to be refilled. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 10 Di641 Intergrated Dishwasher.indd 10 07/01/2020 16:55 07/01/2020 16:55...

  • Page 11: Product Overview

    » Add 1.5Kg dishwasher salt and then fill the salt container with water. » Fill the Rinse Aid dispenser. » Fill in detergent. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 11 Di641 Intergrated Dishwasher.indd 11 07/01/2020 16:55 07/01/2020 16:55...

  • Page 12: Water Softener

    The manufactory setting: H3 Contact your local water board for information on the hardness of your water supply. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 12 Di641 Intergrated Dishwasher.indd 12 07/01/2020 16:55 07/01/2020 16:55...
  • Page 13 This will prevent any grains of salt or salty water, which may have been spilled, remaining on the bottom of the machine for any period of time, which may cause corrosion. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 13 Di641 Intergrated Dishwasher.indd 13 07/01/2020 16:55 07/01/2020 16:55...
  • Page 14 If salt has spilled, run a soak or quick program to remove it. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 14 Di641 Intergrated Dishwasher.indd 14 07/01/2020 16:55 07/01/2020 16:55...

  • Page 15: Rinse Aid And Detergent Dispenser

    Don’t put powdered detergent into the dispenser until you are ready to wash dishes. Dishwasher detergent is corrosive. Keep dishwasher detergent out of the reach of children. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 15 Di641 Intergrated Dishwasher.indd 15 07/01/2020 16:55 07/01/2020 16:55...
  • Page 16 Adjust lever(Rinse) Adjust lever(Rinse) Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 16 Di641 Intergrated Dishwasher.indd 16 07/01/2020 16:55 07/01/2020 16:55...
  • Page 17 N OT E : Please observe the manufacturer’s recommendations on the detergent packaging. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 17 Di641 Intergrated Dishwasher.indd 17 07/01/2020 16:55 07/01/2020 16:55...

  • Page 18: Loading The Baskets

    » Silver and aluminium parts have a tendency to discolour during washing » Glazed patterns may fade if machine washed frequently Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 18 Di641 Intergrated Dishwasher.indd 18 07/01/2020 16:55 07/01/2020 16:55...
  • Page 19 Very small items should not be washed in the dishwasher as they could easily fall out of the basket. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 19 Di641 Intergrated Dishwasher.indd 19 07/01/2020 16:55 07/01/2020 16:55...
  • Page 20 Do not let any item extend through the bottom. Always load sharp utensils with the sharp point down. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 20 Di641 Intergrated Dishwasher.indd 20 07/01/2020 16:55 07/01/2020 16:55...
  • Page 21 Medium serving bowl 2. Lower Basket Large serving bowl Dessert dishes Dinner plates Soup plates Oval plates Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 21 Di641 Intergrated Dishwasher.indd 21 07/01/2020 16:55 07/01/2020 16:55...
  • Page 22 5. Dessert spoons 2. Forks 6. Serving spoons 3. Knives 7. Serving forks 4. Teaspoons 8. Gravy ladle Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 22 Di641 Intergrated Dishwasher.indd 22 07/01/2020 16:56 07/01/2020 16:56...
  • Page 23 The spikes are used for holding plates and a platter. They can be lowered to make more room for large items. raise upwards fold backwards 11 11 Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 23 Di641 Intergrated Dishwasher.indd 23 07/01/2020 16:56 07/01/2020 16:56...
  • Page 24 Remove the right basket from the tray. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 24 Di641 Intergrated Dishwasher.indd 24 07/01/2020 16:56 07/01/2020 16:56...

  • Page 25: Programming The Dishwasher

    Rinse (65˚C) 90 Min Drying Wash (45˚C) ¡ Rinse (55˚C) 0.75 Rinse (55˚C) Radid Prewash 0.02 Prewash Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 25 Di641 Intergrated Dishwasher.indd 25 07/01/2020 16:56 07/01/2020 16:56...
  • Page 26 W A R N I N G It is dangerous to open the door mid-cycle, as hot steam may scald you. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 26 Di641 Intergrated Dishwasher.indd 26 07/01/2020 16:56 07/01/2020 16:56...

  • Page 27: Cleaning And Maintenance

    Pictures are only for reference, different models of the filtering system and spray arms may be different. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 27 Di641 Intergrated Dishwasher.indd 27 07/01/2020 16:56 07/01/2020 16:56...
  • Page 28 NEVER use the dishwasher without filters in place. Improper replacement of the filter may reduce the performance level of the appliance and damage dishes and utensils. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 28 Di641 Intergrated Dishwasher.indd 28 07/01/2020 16:56 07/01/2020 16:56...
  • Page 29 3. Wash the arms in soapy warm water and use a soft brush to clean the jets. Replace them after rinsing them thoroughly. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 29 Di641 Intergrated Dishwasher.indd 29 07/01/2020 16:56 07/01/2020 16:56...

  • Page 30: Caring For The Dishwasher

    If the appliance must be moved, try to keep it in the vertical position. If absolutely necessary, it can be positioned on its back. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 30 Di641 Intergrated Dishwasher.indd 30 07/01/2020 16:56 07/01/2020 16:56...

  • Page 31: Installation Instruction

    E N S U R E T H AT P R O P E R E A R T H I N G E X I S T S B E F O R E U S E Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 31 Di641 Intergrated Dishwasher.indd 31 07/01/2020 16:56...
  • Page 32 H O W TO D I S C O N N E C T T H E S A F E T Y S U P P LY H O S E 1. Turn off the water. 2. Unscrew the safety supply hose from the faucet. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 32 Di641 Intergrated Dishwasher.indd 32 07/01/2020 16:56 07/01/2020 16:56...
  • Page 33 The waste connection must be at a height less than 100 cm (maximum) from the bottom of the dishwasher. The water drain hose should be fixed. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 33 Di641 Intergrated Dishwasher.indd 33 07/01/2020 16:56 07/01/2020 16:56...
  • Page 34 Once the appliance is positioned for levelling, the height of the dishwasher may be altered via adjustment of the screwing level of the feet. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 34 Di641 Intergrated Dishwasher.indd 34 07/01/2020 16:56 07/01/2020 16:56...

  • Page 35: Built-In Installation Instruction

    Depending on where your electrical outlet is, you may need to cut a hole in the opposite cabinet side. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 35 Di641 Intergrated Dishwasher.indd 35 07/01/2020 16:56 07/01/2020 16:56...
  • Page 36 Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 36 Di641 Intergrated Dishwasher.indd 36 07/01/2020 16:56 07/01/2020 16:56...
  • Page 37 » Marble or granite work top: fix to the side panel with the screws provided. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 37 Di641 Intergrated Dishwasher.indd 37 07/01/2020 16:56 07/01/2020 16:56...
  • Page 38 DOWN N OT E : The maximum adjustment height of the feet is 50 mm. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 38 Di641 Intergrated Dishwasher.indd 38 07/01/2020 16:56 07/01/2020 16:56...
  • Page 39 The aesthetic door panel should be processed in accordance with the illustrated dimensions (Unit: mm) (Unit: mm) Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 39 Di641 Intergrated Dishwasher.indd 39 07/01/2020 16:56 07/01/2020 16:56...

  • Page 40: Troubleshooting

    The lid of the softer Check the lip. Ensure the fix is fine. is loose Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 40 Di641 Intergrated Dishwasher.indd 40 07/01/2020 16:56 07/01/2020 16:56...
  • Page 41 Detergent left in Dishes block detergent cups. Re-loading the dishes properly. dispenser cups Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 41 Di641 Intergrated Dishwasher.indd 41 07/01/2020 16:56 07/01/2020 16:56...
  • Page 42 Use of cutlery with a low- of this type are not suitable for washing in quality coating the dishwasher. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 42 Di641 Intergrated Dishwasher.indd 42 07/01/2020 16:56 07/01/2020 16:56...
  • Page 43 » If there is water in the base pan because of an overfill or small leak, the water should be removed before restarting the dishwasher. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 43 Di641 Intergrated Dishwasher.indd 43 07/01/2020 16:56 07/01/2020 16:56...

  • Page 44: Technical Information

    D E P T H ( D 1 ) : D E P T H ( D 2 ) : 1150mm (with the door opened 90°) Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 44 Di641 Intergrated Dishwasher.indd 44 07/01/2020 16:56 07/01/2020 16:56...
  • Page 45 5 This program is suitable for cleaning soiled normally soiled tableware and that it is the most efficient programme in terms of its combined energy and water consumption for that type of tableware. Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 45 Di641 Intergrated Dishwasher.indd 45 07/01/2020 16:56 07/01/2020 16:56...
  • Page 46 N OT E S : Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 46 Di641 Intergrated Dishwasher.indd 46 07/01/2020 16:56 07/01/2020 16:56...
  • Page 47 N OT E S : Instruction manual DI641 Please keep this instruction manual for future reference Di641 Intergrated Dishwasher.indd 47 Di641 Intergrated Dishwasher.indd 47 07/01/2020 16:56 07/01/2020 16:56...

  • Page 48: Caple Contact Details

    Caple Service T: 0117 938 1900 Fourth Way E: service@caple.co.uk Avonmouth www.caple.co.uk Bristol BS11 8DW Di641 Intergrated Dishwasher.indd 48 Di641 Intergrated Dishwasher.indd 48 07/01/2020 16:56 07/01/2020 16:56...

  • Page 49: Dish Wash Er I Nstal Lati On

    DISH WASH ER I NSTAL LATI ON D I 6 5 2 , DI6 4 1 & D I6 3 1 INS TA LLAT ION www.caple.co.uk For more information visit www.caple.co.uk...
  • Page 50 For more information visit www.caple.co.uk...
  • Page 51 For more information visit www.caple.co.uk...
  • Page 52 For more information visit www.caple.co.uk...
  • Page 53 C U T- OUT D IM E N SI O N S Please note image is not to scale. 589± 1 mm Please refer to printed template supplied with dishwasher for correct scale. www.caple.co.uk For more information visit www.caple.co.uk...
