User Manual
Blood Pressure Monitor
Thank you for selecting a TRANSTEK Blood Pressure Monitor.
Please read the user manual carefully and thoroughtly to ensure the safe
usage of this product,Keep the manual well for further reference in case
you have problems.
version:1.0
TMB-1583-BS
Arm Type
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TRANSTEK TMB-1583-BS
Summary of Contents for TRANSTEK TMB-1583-BS
- Page 1 Blood Pressure Monitor TMB-1583-BS Arm Type Thank you for selecting a TRANSTEK Blood Pressure Monitor. Guangdong Transtek Medical Electronics Co., Ltd. Please read the user manual carefully and thoroughtly to ensure the safe Zone A, No.105 ,Dongli Road, Torch Development District,...
-
Page 2: Table Of Contents
CATALOGUE Table of Contents INTRODUCTION........................2 General Description Indications for Use Contraindications Measurement Principle Safety Information LCD Display Signal Monitor Components List BEFORE YOU START......................8 The Choice of Power Supply Installing and Replacing the Batteries Setting Date, Time and Measurement Unit Select the User Pair-up the Blood Pressure Monitor with Your Device MEASUREMENT........................14... -
Page 3: Introduction
Indications for Use Symbol for “Recycle” The Transtek Blood Pressure Monitor is a digital monitor intended for use in Symbol for “Serial Number” measuring blood pressure and heartbeat rate with arm circumference ranging from 22 cm to 32 cm ( about 8¾˝-12½˝ ) or 22cm to 42cm(about 8¾˝-16½˝). - Page 4 INTRODUCTION INTRODUCTION CAUTION CAUTION * This device is intended for indoor, home use. * Warning: This device is not AP/APG equipment. Do not use the device where flammable * This device is not intended for public use. anesthetic are present, or in environments mixture with air of with oxygen or nitrous oxide. * This device is portable, but it is not intended for use during patient transport.
-
Page 5: Lcd Display Signal
Start measurement,save and transmit the User 2 1.Blood Pressure Monitor 2.Cuff (Type BF applied part) measuring results for User 2 (TMB-1583-BS) (22cm~32cm or 22cm~42cm) The bluetooth icon blinks when the Bluetooth icon Bluetooth is working The average value of the latest three... -
Page 6: Before You Start
BEFORE YOU START BEFORE YOU START The Choice of Power Supply Setting Date, Time and Measurement Unit 1.Battery powered mode: It is important to set the clock before using your blood pressure 6VDC 4×AAA batteries monitor, so that a time stamp can be assigned to each record that 2.AC adaptor powered mode: is stored in the memory. -
Page 7: Select The User
BEFORE YOU START BEFORE YOU START 4.Repeat step 2 and 3 to set the [MONTH] and [DAY]. Select the User 1.When the monitor is off , press and hold the MEM button to enter user setting mode. The user ID will blink. .Repeat step 2 and 3 to set the [HOUR] and [MINUTE]. -
Page 8: Pair-Up The Blood Pressure Monitor With Your Device
CAUTION Interference may occur in the vicinity of equipment marked with the following symbol And TMB-1583-BS may interfering vicinity electrical equipment. MEASUREMENT Sensitive people, including pregnant women pre-eclamptic and those who implanted medical electronic instruments, should avoid using the unit whenever possible. -
Page 9: Tie The Cuff
MEASUREMENT MEASUREMENT Start the Measurement Tie the cuff 1.When the monitor is off, press the “START/STOP” button to turn Tie the cuff on your upper arm, then on the monitor, and it will finish the whole measurement. position the tube off-center toward the (Take user 1 for example) inner side of arm in line with the little finger. -
Page 10: Data Management
DATA MANAGEMENT MEASUREMENT Recall the Records .This device will proceed to data transmission When the monitor is off, after measurement. please press the “MEM” to The Bluetooth symbol show the average value of the blinks on the LCD latest three records.If the indicates data is records are less than three transmitting. -
Page 11: Delete The Records
SPECIAL FUNCTION DATA MANAGEMENT About the Lock Button Delete the Records If you did not get the correct measurement, you can delete all The unnecessary keys’ touch will make the blood pressure results by following steps below. (Take user 1 for example) monitor turn on and waste electricity. -
Page 12: Information For User
INFORMATION FOR USER INFORMATION FOR USER Tips for Measurement Maintenance Measurements may be inaccurate if taken in the following In order to get the best performance, please follow the circumstances. instructions below. Avoid touching water, Put in a dry place and avoid the sunshine clean it with a dry cloth in case. -
Page 13: About Blood Pressure
ABOUT BLOOD PRESSURE ABOUT BLOOD PRESSURE ABOUT BLOOD PRESSURE What are systolic pressure and diastolic pressure? Why does my blood pressure Systolic Diastolic When ventricles contract and pump blood out of the fluctuate throughout the heart, the blood pressure reaches its maximum value blood entering blood discharging vein... -
Page 14: Troubleshooting
TROUBLESHOOTING SPECIFICATIONS This section includes a list of error messages and frequently Battery powered mode: 6VDC 4×AAA batteries asked questions for problems you may encounter with your blood Power supply AC adaptor powered mode: 6V pressure monitor. If the products not operating as you think it (Please only use the recommended AC should, check here before arranging for servicing. -
Page 15: Authorized Component
For more information about our products, please visit www.transtekcorp.com.you -- Connect the equipment into an outlet on a circuit different from that to can get customer service, usual problems and customer download, transtek will serve which the receiver is connected. -
Page 16: Emc Guidance
30 cm (12 inches) to any part of Surge ±0.5 kV, ±1 kV differential mode ±0.5 kV, ±1 kV differential mode the equipment TMB-1583-BS including cables specified by the manufacturer. Otherwise, ±0.5 kV, ±1 kV, ±2 kV common mode Not Applicable IEC61000-4-5 degradation of the performance of this equipment could result. - Page 17 30 cm (12 inches) to any part of Surge ±0.5 kV, ±1 kV differential mode ±0.5 kV, ±1 kV differential mode the equipment TMB-1583-BS including cables specified by the manufacturer. Otherwise, ±0.5 kV, ±1 kV, ±2 kV common mode Not Applicable IEC61000-4-5 degradation of the performance of this equipment could result.
- Page 18 EMC GUIDANCE Table 3 Guidance and manufacturer’s declaration - electromagnetic Immunity Compliance Radiated RF Test Band Service Modulation Distance Maximum 60601-1-2 level IEC61000-4-3 Frequency (MHz) Power Test Level (V/m) (Test (MHz) (V/m) specifications 380-390 Pulse TETRA modulation ENCLOSURE 18 Hz PORT IMMUNITY to 430-470...
