4. Connect a serial device to the NETRS232.
Serial port activity is indicated by two status LEDs per port.The
yellow LED illuminates when the serial port is transmitting data.
The green LED illuminates when the serial port is receiving data.
Serial Tx
indicator
Serial Rx
indicator
NOTE: This NETRS232 is factory pre-configured with passwords
as follows:
Administrative password:
Port 1 password:
Port 2 password
... etc.
Before using the NETRS232 you will need to unlock the unit
using the administrative password in order to configure the
device's IP address and other settings. We recommend changing
the administrative password to something other than the factory
default for best security.
Port passwords can be removed or altered as needed provided
administrative access is granted.
Serial connector
Single Port
admin
port1
(if needed):
Serial 2
connector
Serial Rx
indicators
port2
Serial Tx
indicators
Serial 1
connector
Dual Port
