Preparation

Attaching the speakers

The supplied speaker unit can be attached to or detached from the Display. It must be attached unless you use
external amplifier/speakers.
Before attaching (or detaching) speakers, unplug the AC cord from the AC outlet.
Be sure to attach or detach the speakers with two or more people.
Example: Attaching right speaker.
1
Insert the speaker plug into the
terminal on the Display.
• Make sure that the speaker plug
is inserted completely.
CAUTION
• The speaker terminals on the Display are only for the supplied speaker unit. Do not connect any third party plug to the
terminal or speaker to the Display.
• Do not handle or move the Display by the speakers.
NOTE
• Perform the same steps for both left and right speakers.
• To detach the speakers, perform the above steps in reverse order.
• You can connect your own amplifier/speakers to the Display. See page 56 for connecting external speakers.
8
Downloaded from: http://www.usersmanualguide.com/
2
Speaker
plug
Bulge
Take hold of the speaker and
slowly slide it to the Display.
• Make sure that the two bulges of
the speaker align with the holes
on the Display.
3
Hole
Hole
Bulge
Fasten the screws to secure the
speaker in place.
• Use a screwdriver.
• Perform the same steps for
attaching left speaker.
