LC-37HV4M LC-37HV4H SERVICE MANUAL S63D1LC37HV4M LCD COLOUR TELEVISION LC-37HV4M LC-37HV4H MODELS In the interests of user-safety (Required by safety regulations in some countries) the set should be re- stored to its original condition and only parts identical to those specified should be used.
LC-37HV4M LC-37HV4H IMPORTANT SERVICE SAFETY PRECAUTION Ë Service work should be performed only by qualified service technicians who are thor- oughly familiar with all safety checks and the servicing guidelines which follow: » Use an AC voltmeter having with 5000 ohm per volt,...
Page 3
LC-37HV4M LC-37HV4H Precautions for using lead-free solder 1 Employing lead-free solder PWBs of this model employs lead-free solder. The LF symbol indicates lead-free solder, and is attached on the PWBs and service manuals. The alphabetical character following LF shows the type of lead-free solder.
( 1), Antenna cable ( 1) • As a part of policy of continuous improvement, SHARP reserves the right to make design and specification changes for product improvement without prior notice. The performance specification figures indicated are nominal values of production units.
LC-37HV4M LC-37HV4H REMOVING OF MAJOR PARTS 1.Take off the center and lower terminal covers. 2.Remove the two speaker fixing screws each and the speaker connecting terminal, and take off the speaker. 3.Remove the four stand fixing screws and take off the stand.
Page 13
LC-37HV4M LC-37HV4H 9.Open six FFC cable holders and remove the three FFC holder (right & left) fixing screws each and all the connec- tors of flat cables (FFC), and take off the FFC holders (right & left). 10.Remove the Speaker-L and-R PWB fixing screws each and the connectors of them, and take off the Speaker-L and-R PWBs.
Page 14
LC-37HV4M LC-37HV4H 13.Remove the five main PWB fixing screws, and take off the main PWB. 14.Remove the six power PWB fixing screws, and take off the power PWB. 15.Remove the four audio PWB fixing screws, and take off the audio PWB.
Page 15
LC-37HV4M LC-37HV4H • Handling Precautions for LCD Panel 1. Work in a clean room. (Humidity above 50%) 2. Operators should wear an earthing band. 3. Do not give a shock such as falling and vibration. 4. Use the ionizer. (Within 30 cm) 21.Remove the six LCD panel fixing screws and take off the LCD panel unit.
1. Preparation for Adjustment The unit needs to be replaced when the AVC System CONFIGROM/IC2202, receiver IC2206 and HDCP key ROM/IC2208 are replaced. Applicable unit: DKEYHB453FE54 (LC-37HV4M) DKEYHB453FE58 (LC-37HV4H) 2. Adjustment Enter Adjustment Process mode. → VLSBIAS/15V voltage adjustment →...
Page 17
~ Display the screen for adjustment/High-side 200 gradation & Low-side 48 gradation. ~ Adjust ROFFSET, GOFFSET and BOFFSET to allow 200-gradation patterns as a standard. Adjust the chromaticity of High pattern/screen left to be x=0.283 and y=0.286 (LC-37HV4M) x=0.276 and y=0.285 (LC-37HV4H).
Page 18
LC-37HV4M LC-37HV4H ~ In this state, enter the command, listed below, and "ENTER" on the keyboard for adjustment. Press "ENTER" and make sure that "OK" appears on the terminal software. If "ERR" appears, try again. RS232C commands list Command Function...
Page 19
LC-37HV4M LC-37HV4H Lamp error detection [1] Function This LCD color TV set is equipped with automatic power-off (lamp error detection) function. This safety measure serves if the lamp or the lamp circuit gets in trouble. If by any chance the lamp or the lamp circuit gets in trouble, or if the lamp error detector gets activated for any other reasons, the following happens.
Note that it is necessary to replace the unit when replacing the Config ROM for receiver (IC2202), receiver IC (IC2208) and HDCP key ROM (IC2208). Have the relevant unit (DKEYHB453FE07 (LC-37HV4M)/DKEYHB453FE58 (LC-37HV4H)) handy. LED flashing timing list...
Page 23
LC-37HV4M LC-37HV4H TROUBLE SHOOTING TABLE (Continued) No image comes out. Is a HIGH appearing Check the circuits at the RESET terminal around X2201 of pin (3) of IC2206? connected to pin (161) of IC2206. Is a clock (91.3 MHz) Is X2201 connected to pin...
Page 24
LC-37HV4M LC-37HV4H TROUBLE SHOOTING TABLE (Continued) Noise appears on the moving image when the QS drive is turned ON. Is OSTEMP.AD on the 3rd page Check IC4701, IC4901 and of the process adjustment the circuits around them. mode set to 255?
Page 25
LC-37HV4M LC-37HV4H TROUBLE SHOOTING TABLE (Continued) No sound comes out. (Connect to the AVC System and check.) Check around the Is power supplied to each power regulator circuit IC in the audio unit? (IC3809, IC3810). Is an audio signal appearing...
LC-37HV4M LC-37HV4H DESCRIPTION OF SCHEMATIC DIAGRAM VOLTAGE MEASUREMENT CONDITION: 1. When the exclusive-use AC adapter is used, the colour bar signal of colour bar generator for service is input to get the normal screen. When the audio is minimized, the voltage value is measured with the 20 kΩ/V tester.
LC-37HV4M LC-37HV4H Ref. No. Part No. Description Code Ref. No. Part No. Description Code PARTS LIST LC-37HV4H PARTS REPLACEMENT DUNTKB401FE11 – MAIN Unit(AVC System) — DUNTKB493FE11 – POWER Unit(AVC System) — Replacement parts which have these special safety characteristics DUNTKB593DE06 –...
