Installing the SP Bootflash Memory Upgrade Kit
Reinstalling the Supervisor Engine 720
During this procedure, wear grounding wrist straps and handle modules by the carrier edges only to
Caution
avoid ESD damage to the card.
To reinstall the Supervisor Engine 720 in the chassis, follow these steps:
Step 1
Attach an ESD grounding strap to your wrist and to ground. (If you are unsure about the correct way to
attach an ESD grounding strap, see the
instructions.)
Verify that the captive installation screws are tightened on all modules installed in the chassis. This
Step 2
action assures that the EMI gaskets on all modules are fully compressed in order to maximize the
opening space for the removed module.
Note
Fully open both ejector levers on the supervisor engine that is being installed. (See
Step 3
Cisco CompactFlash Adapter for Bootflash Upgrade Installation Note
16
If the captive installation screws are loose, the EMI gaskets on the installed modules will push
adjacent modules toward the open slot, reducing the opening size and making it difficult to
install the removed module.
"Attaching Your ESD Grounding Strap" section on page 24
for
Figure
7.)
78-17277-05
