Cisco CompactFlash Adapter Installation Manual page 14

Installing the SP Bootflash Memory Upgrade Kit
Figure 4
Release the SP DIMM from the socket by simultaneously releasing the two locking spring clip tabs on
Step 2
either side of the DIMM socket. (See
Figure
Hold the DIMM by its edges and carefully remove it from the DIMM socket.
Step 3
Figure 5
Immediately place the DIMM in an antistatic bag.
Step 4
Cisco CompactFlash Adapter for Bootflash Upgrade Installation Note
14
SP and RP DIMM Locations on the Supervisor Engine 720
SP Bootflash
5, right view.)
Removing the DIMM
RP Bootflash
Figure 5, left view.) The DIMM will flip up in the socket. (See
78-17277-05
