Summary of Contents for Kärcher HDS995
- Page 1 HDS 995 www.karcher.com...
- Page 2 HDS 995 Deutsch Lesen Sie vor der Inbetriebnahme diese Betriebsanleitung und beachten Sie besonders die “Sicherheitshinweise für Hochdruckreiniger”. Seite English Please read these operating instructions before starting and strictly observe the "Safety Instructions for High Pressure Cleaners". Page 16 Français Veuillez lire attentivement la présente notice d´instructions avant la mise en service et respecter en particulier les "Consignes de sécurité...
- Page 3 HDS 995...
- Page 4 HDS 995 1. Diagram of the appliance 2. Controls Filling orifice for fuel Pressure and volume control Handle Guide roller with parking brake Instrument panel Water connection with strainer View window with maintenance/fault High-pressure connection display Hand-held spray gun with high-pressure Reset button hose Compartment for accessories...
-
Page 5: Technical Data
HDS 995 3. Technical Data 1.027-111 1.027-261 1.027-291 1.027-8_1 Power connection Voltage 420 V 230 V Type of current 3 Ph/ 50 Hz 3 Ph/ 50 Hz Connected load 6.4 kW 6.4 kW Mains fuse (slow) 13 A 25 A Water connection Supply temperature (max.) 30 °C... - Page 6 HDS 995 4. Start-up 4.1 Unpacking the appliance 4.5 Pouring in the liquid softener • The liquid softener prevents the heating • Please contact your dealer immediately if, on element from becoming calcified when unpacking the appliance, you discover operating with hard supply water. The liquid damage has been caused during trans- softener is added in drops to the supply water portation.
- Page 7 HDS 995 4. Start-up • 4.8 Intended use Until the pump has drawn in the water, you should: • Use the appliance to clean machines, vehicles, – rotate the pressure and volume control to “MAX”, buildings, tools, etc. – close the detergent metering valve. •...
-
Page 8: Operation
HDS 995 5. Operation 5.1 Venting the appliance – The appliance must not be left unatten- ded during operation. • • • • • Open the water intake. – Ensure that the appliance is situated on firm ground. • • • • • Allow the appliance to run without the high- –... - Page 9 HDS 995 5. Operation 5.3 Adjusting the Operating Pressure 5.6 Operating with steam and Flow Rate • When operating temperatures are above • • • • • You can adjust the operating pressure and 98°C, the operating pressure must not exceed flow rate in two different ways: 32 bar.
- Page 10 HDS 995 5. Operation 5.8 Interrupting operation 5.7 Operating with detergent • • If you release the trigger of the hand-held Fill the detergent tank. spray gun, the appliance switches off. If the • trigger is pulled again, the appliance switches Set the detergent metering valve to the desired on again.
-
Page 11: Care And Maintenance
HDS 995 6. Care and maintenance 6.1. Maintenance/Fault Warning Light Always disconnect the appliance from Illuminates the electric mains supply before carrying out any maintenance work. • • • • • If certain maintenance work is required on the • • • • • You can arrange a regular safety inspection basis of elapsed operating hours, this warning with your dealer or take out a maintenance... - Page 12 HDS 995 6. Care and maintenance • • • • • 6.2. Visual Inspection When the oil has completely drained, screw the oil drain plug back in and slowly pour in oil • • • • • up to the “MAX” position on the oil tank (air Checking the connector cable bubbles must escape).
-
Page 13: Troubleshooting
HDS 995 7. Troubleshooting 7.1 Maintenance/Fault Warning Light – Always disconnect the appliance from Illuminates the electric mains supply before carrying out any repair work. • • • • • This warning light illuminates if there is a fault. – The electrical components must only be checked by the authorized customer •... - Page 14 HDS 995 7. Troubleshooting 7.2 Indicator lights 7.5 Detergent is not being drawn in • • • • • • • • • • Indicator light for fuel tank lights up Let the appliance run with opened metering – Refill with fuel. valve (max.
-
Page 15: General Information
HDS 995 8. General Information 8.1 Safety equipment 8.3 Spare parts Overflow valve with 2 pressure switches Please note that the use of other than Kärcher When the water flow rate is reduced with the spare parts can result in damage and even servo compression valve on the hand-held spray serious accidents if these parts have not been gun or with the flow regulator on the pump head,... - Page 16 HDS 995 HDS 995 5.063-448.0 6.388-225.0 1.027-111.0 1.027-261.0 1.027-281.0 GB 1.027-291.0 CH 5.363-290.0 1.027-611.0 SF 4.821-071.0 1.027-801.0 1.027-811.0 6.388-559.0 1.027-821.0 1.027-831.0 5.042-463.0 5.030-834.0 2.884-085.0 6.414-028.0 7.306-328.0 2.884-085.0 6.313-014.0 5.321-378.0 6.313-014.0 5.321-377.0 5.063-447.0 5.363-290.0 5.731-039.0 5.337-021.0 5.321-379.0 5.321-403.0 5.392-017.0 1.027-111.0 7.312-004.0 1.027-281.0 7.306-049.0 1.027-611.0...
