Dixie Narco 501E Technical Manual
  1. Manuals
  2. Brands
  3. Dixie Narco Manuals
  4. Merchandiser
  5. DNCB 501E
  6. Technical manual

Dixie Narco 501E Technical Manual

Pepsi-cola high visibility vender for ht2 venders produced beginning production run 6730bz for ht3 venders produced beginning production run 6757dz
Hide thumbs Also See for 501E:
Table of Contents

Advertisement

Quick Links

Pepsi-Cola High Visibility Vender
For HT2 Venders Produced Beginning Production Run 6730BZ
For HT3 Venders Produced Beginning Production Run 6757DZ
Manufactured by
Dixie-Narco, Inc.
P.O. Drawer 719
Williston, SC 29853-0719
888-353-9722
803-266-0700
fax: 803-266-4747
Visit us on the web: www.dixienarco.com
803,903,120.11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 501E and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dixie Narco 501E

Summary of Contents for Dixie Narco 501E

  • Page 1 Pepsi-Cola High Visibility Vender For HT2 Venders Produced Beginning Production Run 6730BZ For HT3 Venders Produced Beginning Production Run 6757DZ Dixie-Narco, Inc. P.O. Drawer 719 Manufactured by Williston, SC 29853-0719 888-353-9722 803-266-0700 fax: 803-266-4747 Visit us on the web: www.dixienarco.com 803,903,120.11...

  • Page 2: Table Of Contents

    Table of Contents GENERAL INFORMATION Application...........................3 Vender Safety Precautions......................3 Product Identification........................3 Physical Characteristics .......................3 INSTALLATION & SETUP Unpacking the Vender........................4 Electric Power Requirements......................4 Ground the Vender ........................4 Pepsi Electronic Door Lock......................4 - 5 Placing the Vender on Location ....................5 Level the Vender..........................5 Space the Vender ........................5 Coin Changers and Other Accessories ..................6 Loading the Change Tubes ......................6...
  • Page 3 Table of Contents WIRING DIAGRAMS AND SCHEMATICS Figure 1 – HT2 Wiring Diagram ....................41 Figure 2 – HT3 Wiring Diagram ....................42 Figure 3 – Compressor Wiring Diagram ..................43 Figure 4 – HT3 Choke / Relay Plate Assy..................44 Figure 5 – HT2 Schaffner Fitter / Relay Plate Assy..............45 PARTS LIST MAIN DOOR EXTERIOR ....................46 - 47 MAIN DOOR INTERIOR (A) ....................48 - 49...

  • Page 4: General Information

    HAZARDS DEVELOPING DUE TO IMPROPER ASSEMBLY OR ADJUSTMENTS WHILE PHYSICAL CHARACTERISTICS PERFORMING SUCH REPAIRS. PERSONS NOT HAVING A PROPER BACKGROUND MAY SUBJECT THEMSELVES TO THE RISK OF 501E INJURY OR ELECTRICAL SHOCK HEIGHT 72.5” WHICH CAN BE SERIOUS OR EVEN FATAL. WIDTH 37.5”...

  • Page 5: Unpacking The Vender

    INSTALLATION & SETUP PEPSI ELECTRONIC DOOR LOCK The Dixie-Narco Pepsi-Cola High Visibility Vender is designed utilizing the latest technology. The electronic lock provided in the vender consists of a door mounted, motor driven bayonet (shaft) UNPACKING THE VENDERS system, a cabinet mounted nut receptacle switch system, an infrared controlled CPU, and a remote Remove the stretch wrap and top cover from the control key (FOB).

  • Page 6: Placing The Vender On Location

    INSTALLATION & SETUP PLACING THE VENDER ON LOCATION TO OPEN THE PEPSI ELECTRONIC DOOR LOCK: !! CAUTION !! DO NOT TRANSPORT THE 1. Plug the vender into a properly powered VENDER TO OR FROM THE outlet. LOCATION LOADED WITH 2. Hold the key FOB 0 to 3 inches to the right PRODUCT.

  • Page 7: Coin Changers And Other Accessories

    INSTALLATION & SETUP COIN CHANGERS & OTHER All Pepsi-Cola High Visibility Venders are shipped ACCESSORIES ready to vend 20 oz. Pepsi Quick Slam (Swirl) PET The vender must have an MDB coin changer bottles. To vend an alternative package in the installed and can have an MDB bill acceptor Pepsi-Cola High Visibility Vender, contact a Dixie- installed.

  • Page 8: Historical Data

    INSTALLATION & SETUP PEPSI-COLA HVV PROGRAMMING METHOD June 2001 The controller has two modes of operation: NORMAL and SERVICE. NORMAL MODE: In Normal Mode, on power up display will show software installed in vender, then change to Ice Cold Pepsi message, Sold Out, Credit Value, or decimal point.

  • Page 9: Interval Data - Resettable Data

    INSTALLATION & SETUP Interval Data This function shows the user the vender accounting data since the last time of the last counter reset. This data can be reset either from the menu or by DEX interrogation. Press Select Button 1: Shows the total cash collected since the last counter reset Press Select Button 2: Shows the total number of vends since the last counter reset.
  • Page 10 INSTALLATION & SETUP Escrow: This function supports 4 (four) escrow options. To show the current condition, press select button 1 will enter mode and show current escrow setting. Press and hold select button 1 will scroll through the available Escrow options and set the escrow mode to setting displayed when the select button1 is released.

  • Page 11: User Menu

    INSTALLATION & SETUP User Menu: This function is used to configure the vender to operate in a fashion best suited for the vender location. To move to “Diagnostics”, press & hold select buttons 1&2 simultaneously, to enter the User Menu sub-menus press select button1.
  • Page 12 INSTALLATION & SETUP “Hour/Minute” - Hour and Minute Setting (0000 to 2359) Press select button 1 and the current 4-digit hour and minute setting will be displayed (24 hour). Press and hold select button 1: Set Hours Press and hold select button 2: Set Minutes Press select buttons 1&2 simultaneously to move to the next item in the menu.
  • Page 13 INSTALLATION & SETUP To change "Electronic Counter" four button code: At "Electronic Counter" press select button 1, "4231" (representing current four button code) will show on display. Press and hold select button 1 until the far left digit starts blinking indicating it can be changed. Press the select button which is desired for the code.
  • Page 14 INSTALLATION & SETUP Start 2 This function is used to set the hours and minutes to start period 2 limited access. Press select button 1 and the current four-digit hour and minute setting will be displayed (24 hour). Press & hold select button 1: Set Hours Press &...
  • Page 15 INSTALLATION & SETUP Stop This function is used to set the hours and minutes to stop secondary pricing. Press select button 1 and the current four-digit hour and minute setting will be displayed. Press and hold select button 1 to change the hour setting, press button 2 to change the minute setting. Press select buttons 1 &...
  • Page 16 INSTALLATION & SETUP Return Press select button 1 to return to “Light”. Press & hold select buttons 1 & 2 simultaneously to move to the next item on the menu. Refrigeration This function is used to electronically control the refrigeration operations of the vender. Press select button 1 will enter “Temperature”.
  • Page 17 INSTALLATION & SETUP Stop This function is used to set the hours and minutes for storage temperature to become inactive. Press select button 1 and the current four-digit hour and minute setting will be displayed (24hour). Press & hold select button 1: Set Hours Press &...

  • Page 18: Diagnostics Menu

    INSTALLATION & SETUP Override This function is used to allow a key switch to override some of the settings stored for normal operations. When enabled and the override switch is in the closed position, the controller will override “Free Vend”, disable vending, disable currency acceptance, display will show “No Sales”, and lights will be off.
  • Page 19 INSTALLATION & SETUP Motors Use this test to run any motor in the stack. Press select button 1and “Motor 1” will show on the display. Use the following select buttons to run this test. Press Select Buttons 1&2: Press until desired motor # to run or “Return” is shown on the display. Press Select Button 1: Press to run the selected motor.

  • Page 20: Quick Reference Prompts

    INSTALLATION & SETUP Auto Test This function is used in Dixie- Narco’s manufacturing process and is not intended for use in the field. It’s purpose is a self-test routine to check the HVV components listed. For further details contact Dixie-Narco Factory Service. Press and hold select buttons 1 &...

  • Page 21: Default Space-To-Sales Setting

    CONTROLLER PROGRAMMING PEPSI HVV QUICK REFERENCE MENU PROMPTS Main Menu Sub-Menu Sub-Sub-Menu Main Menu Sub-Menu Sub-Sub-Menu Historical Data User con't. Light Days Interval Data Start Set Price Stop Cash Settings Fill Coin Mech Enable Dump Coin Mech Return Coin Rules Refrigeration Temperature Escrow...

  • Page 22: Set Vender Type

    4. Power-up the vender and the display will scroll “Set Model Number”. 5. Press button 1 and the machine will display the model number available “501E”. 6. Press buttons 1 and 2 simultaneously, this will allow the user to cycle through the available model numbers for that machine type.

  • Page 23: Cgeneral Maintenance

    GENERAL MAINTENANCE The most important facets of proper vender care and THE COMPRESSOR ELECTRICAL maintenance are the electrical power supplied to it, CIRCUIT IS ALWAYS LIVE WHEN leveling, and cleanliness of the machine and its THE PLUG IS CONNECTED TO AN components.

  • Page 24: Eprom Replacement

    INSTALLATION & SETUP EPROM REPLACEMENT Software changes / upgrades are accomplished by changing the EPROM on the Control Board. To change EPROM: Remove power to the vender. Remove existing EPROM. Replace the EPROM. (The EPROM’s legs bend easily. Remove and replace very carefully.) Note the alignment notch at one end of the EPROM and on the control board.

  • Page 25: Major Component Description Electrical

    MAJOR COMPONENT DESCRIPTION ELECTRICAL REFRIGERATION Transformer Provides 24 volt and 12 volt 110 VAC power to the Machine Controller Compressor Embraco, 1/3 HP, 115 VAC, 60 Hz Fuse (F1) 1.6 Amp Slo Blo 1 Phase Control Board Power Unit uses 7.5 oz. of 134A (includes display and MDB Refrigerant Peripherals)

  • Page 26: Ht2 Universal Controller

    MAJOR COMPONENT DESCRIPTION HT2 UNIVERSAL CONTROLLER...

  • Page 27: Ht2 Machine Controller

    MAJOR COMPONENT DESCRIPTION HT2 MACHINE CONTROLLER Board Power to Transformer Motor Extension Harness (connection) Board to Board Interface (Machine Controller to Universal Controller) Cabinet Extension Harness P2 & P6 Temp Sensor and Relay Extension...

  • Page 28: Ht3 Control Board

    MAJOR COMPONENT DESCRIPTION HT3 CONTROL BOARD Motor Secondary DEX Display Select Switches Temp Sensor Energy Management Sold Out LED’s Ready to Vend AC Power Cam / Sold Out...

  • Page 29: All Coins Are Rejected

    TROUBLESHOOTING FLOWCHARTS These charts are intended to isolate and correct most problems you might encounter. ALL COINS ARE REJECTED All coins are rejected. Main Power Apply power Disconnected. Check fuses and Blown Fuse replace if necessary. Check Prices Reset Price Check cable at Loose connection.

  • Page 30: All Bills Are Rejected

    TROUBLESHOOTING ALL BILLS ARE REJECTED All bills are rejected. Main Power Apply power Disconnected. Check fuses and Blown Fuse replace if necessary. Check cable at bill validator, controller board, Loose connection. and cable connection to coin mech. Coin mechanism low on Fill coin tubes.

  • Page 31: Incorrect Change Dispensed

    TROUBLESHOOTING INCORRECT CHANGE DISPENSED Incorrect change dispensed. Check price and Vend prices set reset if incorrectly. necessary. Check coin Coins not laying tubes; clear and flat in tubes. reload coins. Defective coin Replace. mechanism. Defective Universal Replace. controller board. HT2 defective Universal controller board or HT3 defective controller board.

  • Page 32: Selection Will Not Vend

    TROUBLESHOOTING SELECTION WILL NOT VEND Selection will not vend. Check price and Vend price set reset if incorrectly. necessary. Check price, ensure credit is Insufficient credit. equal to or greater. Fill column with product. No product in column. Check sold-out switch in diagnostics. Replace if necessary.

  • Page 33: Ice / Frost On Evaporator

    TROUBLESHOOTING ICE / FROST ON EVAPORATOR Ice / frost on evaporator. See: "Compressor Is refrigeration Runs Continuously" unit cycling? Below Inspect / Repair: 1. Gasket seal on inner door. Air leak. 2. Delivery port door seal. 3. Verticle "L-Profile" Gasket. 4.

  • Page 34: Compressor Will Not Start

    TROUBLESHOOTING COMPRESSOR WILL NOT START Compressor will not start. Electronic problem. 1. Check relay. Power to the 2. Harnessing. Refrigeration system. 3. Temperature Sensor or control. 4. Control Board. Plug compressor in outlet on Compressor is face of main wiring harness unplugged.

  • Page 35: Machine Not Cooling

    TROUBLESHOOTING MACHINE NOT COOLING Machine not cooling. Dirty or clogged Clean. condenser. Check rear of vender for obstructions. Ensure rear of Restricted airflow. cabinet is at least 3.25" (82.6 mm) from wall. Faulty product seal. Replace. Check blade for Condenser fan or obstruction.

  • Page 36: Can't Enter The Menu Or Diagnostics

    TROUBLESHOOTING CAN’T ENTER THE MENU OR DIAGNOSTICS Note: Prior to checking wires or connections, ensure power has been removed from vender. Can't enter the Menu or Diagnostics. Put lock switch Check the lock switch position. in door open position. Check lock switch Repair or wiring.

  • Page 37: Lights Are Not On

    TROUBLESHOOTING LIGHTS ARE NOT ON Lights are not on. Check that two-pin stack plug is plugged in. Check two-pin light power plug at bottom of main door. Check wiring from stack plug to the lamp sockets. Check the "Light" programming routine. Replace if Check bulbs.

  • Page 38: One Or More Motors Run When Main Door Is Closed

    TROUBLESHOOTING ONE OR MORE MOTORS RUN WHEN MAIN DOOR IS CLOSED (Display Scrolls “Homing”) One or more motors run when the main door is closed. (Display scrolls "Homing") Check cam / sold-out connector at HT2 Machine Board (J1). [for HT3 (J4)] Check the connectors at the bottom of the main door.

  • Page 39: Sold Out Switch

    TROUBLESHOOTING SOLD OUT SWITCH Vender is indicating Sold Out on a column that contains product. Check Sold out switch for Replace if continuity. necessary. Check harnessing and connections for continuity (from J1 at the HT2 machine board to sold out switches). [For HT3 (J4) at board.] Check wire from appropriate sold out switch, back to J1 at the HT2 machine...

  • Page 40: The Display Is Dead

    TROUBLESHOOTING THE DISPLAY IS DEAD The display is dead. Check the 1.6 amp fuse on the HT2 machine board or HT3 board. Check continuity of the display harness from the display to P2 at the HT2 Universal board. [For HT3, to P3 at controller board.] Replace the display Replace the HT2 Universal Control Board or HT3 control...

  • Page 41: Can't Read The Display

    TROUBLESHOOTING CAN’T READ THE DISPLAY Can't read the display. Reset the display by unplugging the vender and plugging it back in. Check display in Diagnostics. This will check that all dots are working. The display will illuminate in a scrolling manner. This also checks the red (sold out) and green (vend ready) lamps.
  • Page 42 WIRING DIAGRAMS AND SCHEMATICS...
  • Page 43 TROUBLESHOOTING...
  • Page 44 WIRING DIAGRAMS AND SCHEMATICS Refrigeration Circuit Diagrams...
  • Page 45 WIRING DIAGRAMS AND SCHEMATICS...
  • Page 46 WIRING DIAGRAMS AND SCHEMATICS Schaffner Fitter / Relay Plate Assy. 1 – Relay Mounting Plate 2 – Light Relay Label 3 – Fuse Relay Label 4 – Compressor Relay Label 5 – 6 Amp Power Line Filter 6 – Filter / Stack Plug Harness 8 –...

  • Page 47: Gparts List

    PARTS LIST MAIN DOOR PARTS (EXTERIOR) NA = Not Applicable Part numbers subject to change without notice.
  • Page 48 HT3 (501E) ITEM PART DESCRIPTION HT2 (501E) 631,050,00x.x3 Main Door Assembly 501E Pepsi 631,004,40x.x3 631,054,70x.x3 Main Door Assembly 501E Mtn. Dew 631,050,10x.x3 Door Weld Assembly Pepsi 631,004,20x.x3 631,054,80x.x3 Door Weld Assembly Mtn. Dew 801,814,63x.x1 Trim, Top Panel Cap Pepsi 631,001,23x.x3 801,814,82x.x1...

  • Page 49: Main Door Interior (A)

    PARTS LIST MAIN DOOR INTERIOR (A) NA = Not Applicable Part numbers subject to change without notice.
  • Page 50 PARTS LIST MAIN DOOR INTERIOR (A) HT3 (501E) ITEM PART DESCRIPTION HT2 (501E) Rain Guard Pepsi 164,151,14x.x3 164,151,14x.x3 Rain Guard Mtn. Dew 631,050,39x.x3 Cash Box 631,000,69x.x3 631,052,10x.x3 Vault Enclosure 631,005,30x.x3 Cash Box Mount Weld Assy. 631,051,10x.x3 Protective Plate, Door 165,150,33x.x3 165,150,33x.x3...

  • Page 51: Main Door Interior (B)

    PARTS LIST MAIN DOOR INTERIOR (B) NA = Not Applicable Part numbers subject to change without notice.
  • Page 52 PARTS LIST MAIN DOOR INTERIOR (B) HT3 (501E) ITEM PART DESCRIPTION HT2 (501E) Coin Return Bracket 631,001,39x.x3 631,050,18x.x3 Coin Return Rocker 631,001,38x.x3 631,050,17x.x3 Roller Pin 900,502,19x.x1 900,502,19x.x1 Roller Pin Retainer 900,900,90x.x1 900,900,90x.x1 Coin Return Spring 901,700,63x.x1 901,700,63x.x1 Top Coin Chute Assembly (HT2 only) 631,005,60x.x3...

  • Page 53: Select Panel

    PARTS LIST SELECT PANEL NA = Not Applicable Part numbers subject to change without notice.
  • Page 54 PARTS LIST SELECT PANEL HT3 (501E) ITEM PART DESCRIPTION HT2 (501E) 631,051,60x.x3 Select Panel Assy., Right (shown) Pepsi 631,004,20x.x3 631,050,60x.x3 Select Panel Assy., Right (shown) Mtn. Dew 631,051,70x.x3 Select Panel Assy., Left (not shown) Pepsi 631,005,40x.x3 631,055,10x.x3 Select Panel Assy., Left (not shown) Mtn. Dew 631,050,16x.x3...

  • Page 55: T8 Lighting

    PARTS LIST T8 LIGHTING NA = Not Applicable Part numbers subject to change without notice.
  • Page 56 PARTS LIST T8 LIGHTING HT3 (501E) ITEM PART DESCRIPTION HT2 (501E) Fluorescent Bulb (F17T8 / TL865) 2’ (Not Shown) 804,700,77x.x1 804,700,77x.x1 Fluorescent Bulbs (F32T8 / TL865) 4’ 804,700,76x.x1 804,700,76x.x1 Ballast T8 804,400,59x.x1 804,400,59x.x1 4 Lamp T8 Lighting Harness 804,918,34x.x1 804,918,34x.x1 Fluorescent Lamp Boot 802,001,42x.x1...

  • Page 57: Electronic Components

    PARTS LIST ELECTRONIC COMPONENTS NA = Not Applicable Part numbers subject to change without notice.
  • Page 58 PARTS LIST ELECTRONICS COMPONENTS HT3 (501E) ITEM PART DESCRIPTION HT2 (501E) Electronic Lock Assembly 805,202,44x.x1 805,202,44x.x1 Electronic Lock Light Pipe 801,814,19x.x1 801,814,19x.x1 631,053,30x.x3 Machine Controller 804,918,15x.x1 801,306,15x.x1 Machine Controller Base 801,813,45x.x1 801,306,16x.x1 Machine Controller Cover 631,000,68x.x3 Universal Controller 804,916,31x.x1 Display (Vacuum Fluorescent) 804,918,69x.x1...

  • Page 59: Inner Door

    PARTS LIST INNER DOOR NA = Not Applicable Part numbers subject to change without notice.
  • Page 60 PARTS LIST INNER DOOR HT3 (501E) ITEM PART DESCRIPTION HT2 (501E) Inner Door Assembly 631,004,90x.x3 631,004,90x.x3 Inner Door Gasket 801,804,06x.x1 801,804,06x.x1 Discharge Frame Assembly 801,809,16x.x1 801,809,16x.x1 Discharge Frame Retainer 801,809,15x.x1 801,809,15x.x1 Pull Knob 901,501,70x.x1 901,501,70x.x1 Carriage Bolt ¼ -20x¼ 900,201,23x.x1 900,201,23x.x1...

  • Page 61: Harnessing

    PARTS LIST HARNESSING Dual Board (HT2) NA = Not Applicable Part numbers subject to change without notice.
  • Page 62 PARTS LIST HARNESSING Dual Board (HT2) ITEM PART DESCRIPTION HT2 (501E) MACHINE BOARD HARNESS Board to board interface harness 804,917,34x.x1 (J3 of machine board to J14 of universal board) Motor Extension Harness, 90 inches 804,909,29x.x1 (P10 to bottom of door) Temp Sensor and Relay Extension Harness 804,917,43x.x1...
  • Page 63 PARTS LIST HARNESSING Single Board (HT3) NA = Not Applicable Part numbers subject to change without notice.
  • Page 64 PARTS LIST HARNESSING Single Board (HT3) ITEM PART DESCRIPTION HT3 (501E) Motor Extension Harness, 90” (see page 61) 804,909,29x.x1 Motor Harness (see page 61) 804,912,56x.x1 Cabinet Harness (see page 61) 804,912,57x.x1 Cabinet Extension Harness, 80 inches J4 to (see page 61) 804,913,96x.x1...

  • Page 65: Cabinet And Vend Mechanism (Section One)

    PARTS LIST CABINET AND VEND MECHANISM (SECTION ONE) NA = Not Applicable Part numbers subject to change without notice.
  • Page 66 PARTS LIST CABINET AND VEND MECHANISM (SECTION ONE) ITEM DESCRIPTION HT3 (501E) HT2 (501E) Vend Motor Cover Assy. 609,070,43x.x3 609,070,43x.x3 Clamp Nylon Cable 3/4 (2) not shown 901,900,55x.x1 901,900,55x.x1 Vend Motor Assy., Wide HVV (Electronic) 609,070,70x.x3 609,070,70x.x3 Vend Cam, Wide Column Grey 801,809,80x.x1...

  • Page 67: Cabinet And Vend Mechanism (Section Two)

    PARTS LIST CABINET AND VEND MECHANISM (SECTION TWO) NA = Not Applicable Part numbers subject to change without notice.
  • Page 68 PARTS LIST CABINET AND VEND MECHANISM (SECTION TWO) ITEM DESCRIPTION HT3 (501E) HT2 (501E) Sold-Out Switch Assy. Electronic (w/ gold cross point) - Xenoy 1731 804,100,75x.x1 804,100,75x.x1 Sold-Out Paddle Standard Emodel (shown) 432,070,19x.x3 432,070,19x.x3 Special Use Only - E-Models 609,070,19x.x3 609,070,19x.x3...

  • Page 69: Cabinet And Vend Mechanism (Section Three)

    PARTS LIST CABINET AND VEND MECHANISM (SECTION THREE) NA = Not Applicable Part numbers subject to change without notice.
  • Page 70 Relay (3) (Environmental Control Venders Only) 804,200,26x.x1 804,200,26x.x1 Plate Mounting Relay (used on all HVV Machines) 631,000,64x.x3 631,000,64x.x3 Filter (powerline) (All HT2 501E) 804,917,96x.x1 Choke (Used on all HVV Machines ) (replaces Filter – 5C) 804,919,09x.x1 804,919,09x.x1 Label, Light Relay (Environmental Control Venders Only) 803,860,68x.x1...

  • Page 71: Cabinet Interior

    PARTS LIST CABINET INTERIOR NA = Not Applicable Part numbers subject to change without notice.
  • Page 72 PARTS LIST CABINET INTERIOR ITEM DESCRIPTION HT3 (501E) HT2 (501E) Lock Housing Assy. Vertical Recpt Mount 631,006,40x.x3 631,006,40x.x3 Plate Assy (Black) 801,306,05x.x1 801,306,05x.x1 Screw 1/4x20x1 900,301,73x.x1 900,301,73x.x1 Nut 1/4-20 Nylong Insert, Locking 800,303,48x.x1 800,303,48x.x1 E-Lock Shim 631,000,76x.x3 631,000,76x.x3 Gate, Wire 801,401,72x.x1...

  • Page 73: Hinges And Roller Assy

    PARTS LIST HINGES AND ROLLER ASSY. NA = Not Applicable Part numbers subject to change without notice.
  • Page 74 PARTS LIST HINGES AND ROLLER ASSY. DESCRIPTION HT3 (501E) HT2 (501E) Roller, Main Door All Styles 901,806,20x.x1 901,806,20x.x1 Roller Pin All Styles 900,502,19x.x1 900,502,19x.x1 Assy., Top Hinge (drop in pin) E-Models All Styles Pepsi 609,051,40x.x3 609,051,40x.x3 All Styles Mtn. Dew 631,055,40x.x3...

  • Page 75: Refrigeration System (Section One)

    PARTS LIST REFRIGERATION SYSTEM (SECTION ONE) NA = Not Applicable Part numbers subject to change without notice.
  • Page 76 PARTS LIST REFRIGERATION SYSTEM (SECTION ONE) ITEM DESCRIPTION HT3 (501E) HT2 (501E) Complete Refrigeration System Domestic 1203 C-E 115/60 609,043,50x.x4 609,043,50x.x4 1/3 HP 220-240/50 "E" (1222B-E IEC) 609,040,20x.x3 609,040,20x.x3 1/3 HP 220-240/50 "E" (1222B-E AUS) 609,040,30x.x3 609,040,30x.x3 1/3 HP 220-240/50 "E" (1222B-E GEN) 609,040,40x.x3...

  • Page 77: Refrigeration System (Section Two)

    PARTS LIST REFRIGERATION SYSTEM (SECTION TWO) NA = Not Applicable Part numbers subject to change without notice.
  • Page 78 PARTS LIST REFRIGERATION SYSTEM (SECTION TWO) ITEM DESCRIPTION HT3 (501E) HT2 (501E) Fan Housing Assy. Assy., Housing Fan (Wide) 609,044,80x.x1 609,044,80x.x1 Temperature Sensor (Board) 804,917,44x.x1 804,917,44x.x1 Temp Sensor Harness 804,917,41x.x1 804,917,41x.x1 Cover, Temp Sensor HVV 631,001,42x.x3 631,001,42x.x3 Condenser Fan Shroud 491,040,11x.x3...

  • Page 79: Miscellaneous Labels

    PARTS LIST MISC. LABELS ITEM DESCRIPTION HT3 (501E) HT2 (501E) Labels Price Label Sheet 803,861,87x.x1 803,861,87x.x1 HVV Programming (English) 803,862,08x.x1 803,862,08x.x1 Package Set-Up Guide Domestic (Non Coke) 803,849,11x.x1 803,849,11x.x1 Label, Light Relay 803,860,68x.x1 803,860,68x.x1 Label, Fan Relay 803,860,69x.x1 803,860,69x.x1 Label, Compressor Relay 803,860,70x.x1...

  • Page 80: Signs And Decals

    PARTS LIST DOMESTIC SIGNS & SIDE DECALS (Contact Parts Department for any not listed) ITEM DESCRIPTION HT3 (501E) HT2 (501E) Pepsi Side Decals Pepsi Domestic Bottle 72 x 25.25 803,861,85x.x1 803,861,85x.x1 Mountain Dew 803,864,92x.x1 NA = Not Applicable Part numbers subject to change without notice.

  • Page 81: Screws & Nuts

    PARTS LIST SCREWS & NUTS NA = Not Applicable Part numbers subject to change without notice.
  • Page 82 PARTS LIST SCREWS & NUTS ITEM PART NUMBER PART NAME AND DESCRIPTION 900,301,70x.x1 Screw, Phil Pan Swage Form #6 - 32 x 3/8" 900,301,64x.x1 Screw, Phil Pan Swage Form w/washer #8 - 32 x 1/2" 900,301,83x.x1 Screw, Phil Pan Swage Form #10 - 32 x 5/16" 900,301,50x.x1 Screw, Phil Pan w/out washer, #8 - 18 x 1/2"...
  • Page 83 PARTS LIST WASHERS, BOLTS, & MISC. HARDWARE NA = Not Applicable Part numbers subject to change without notice.
  • Page 84 PARTS LIST WASHERS, BOLTS, & MISC. HARDWARE ITEM PART NUMBER PART NAME AND DESCRIPTION 900,700,60x.x1 Washer, Delrin .047 Thick 3/8"IDx5/8"OD 901,303,77x.x1 Washer, Door Hinge 901,503,06x.x1 Washer, Flat #2949 (T-Handle) 901,503,08x.x1 Washer, Hex #29-34 (T-Handle) 900,700,36x.x1 Lockwasher, Split 3/8" 900,700,89x.x1 Lockwasher, Shakeproof 5/8" (1132-00-00-0551) 900,700,02x.x1 Steel Washer, 18 Gauge (1/2"x3/16") 900,700,62x.x1...

  • Page 85: Washers, Bolts, & Misc. Hardware

    901,901,00x.x1 Wire Ties, 4" 901,900,55x.x1 Clamp, Nylon 3/4" Heyco 3382BL 901,902,83x.x1 Cable Tie, x.x" 900,902,14x.x1 Canoe Clip #254-090-301-00-0108 ELECTRONICS & COMPONENTS HT3 (501E) ITEM PART NAME AND DESCRIPTION HT2 (501E) Electronic Lock Assembly 805,202,44x.x1 805,202,44x.x1 Electronic Lock Light Pipe 801,814,19x.x1 801,814,19x.x1...
