1 Product Overview

The RG-WS6816 wireless LAN controller is introduced by Ruijie Networks to provide powerful WLAN access control for
medium-large-sized wireless networks.
1.1 RG-WS6816
Table 1-1 Technical Specifications of RG-WS6816
Model
Memory
Port
Power Supply
Module
Hot Swapping
Interface Standard
Dimensions
(W x D x H)
Voltage
Power Consumption
Operating
Temperature
Operating Humidity
The system may not support all USB disks. It is recommended to use the Kingston USB disk and set the file system
format to FAT32.
RG-WS6816 wireless controller is a class A product. In a domestic environment, this product may cause radio
interference, in which case the user may be required to take adequate measures.
RG-WS6816
DDR3 SDRAM:16GB
BOOTROM: 8MB
FLASH: 512MB
8-1000M combo Ethernet ports.
The copper port supports 10/100/1000Mbps auto-negotiation and network cable/cross-over
cable auto-identification.
The fiber port supports the 1000BASE-SX/LX/ZX mini GBIC optical transceiver.
4-10Gigabit fiber ports are provided, including port 2 combo with 1000M ports 0/1, 0/2, 0/3, 0/4
and port 3 combo with 1000M ports 0/5, 0/6, 0/7, 0/8.
Modules XG-SFP-SR-MM850, XG-SFP-LR-SM1310 and XG-SFP-ER-SM1550 are supported.
One management port, which supports 10/100/1000Mbps auto-negotiation and network
cable/cross-over cable auto-identification.
One console port.
Two USB ports.
Up to two RG-PA300I power modules are supported. One is supplied.
Fan tray hot swapping: supported
Power hot swapping: supported
Ethernet port: 10Base-T/100Base-TX/1000Base-TX and 1000BASE-SX/LX/ZX
Configuration port (Console port): RS-232
560mm x 440mm x 88.1mm (excluding foot pad)
100-240V~, 50/60Hz
100W max.
0ºC to 45ºC (32 to 113ºF)
5% to 95% RH (noncondensing)
