Sony KSM-213CDP Service Manual page 49

Ref. No. Part No. Description
C224 1-162-968-11 CERAMIC CHIP
C229 1-104-658-91 ELECT
C230 1-126-964-11 ELECT
C234 1-126-963-11 ELECT
C251 1-126-947-11 ELECT
C252 1-162-964-11 CERAMIC CHIP
C253 1-162-964-11 CERAMIC CHIP
C254 1-126-947-11 ELECT
C255 1-126-785-11 ELECT
C256 1-104-658-91 ELECT
C257 1-107-826-11 CERAMIC CHIP
C258 1-107-826-11 CERAMIC CHIP
C260 1-126-963-11 ELECT
C261 1-126-963-11 ELECT
C262 1-126-960-11 ELECT
C263 1-115-156-11 CERAMIC CHIP
C265 1-162-960-11 CERAMIC CHIP
C302 1-126-947-11 ELECT
C320 1-126-768-11 ELECT
C321 1-126-925-91 ELECT
C322 1-113-619-91 CERAMIC CHIP
C323 1-126-964-11 ELECT
C324 1-113-619-91 CERAMIC CHIP
C326 1-126-934-11 ELECT
C329 1-162-974-11 CERAMIC CHIP
C331 1-104-662-91 ELECT
C332 1-126-926-11 ELECT
C333 1-162-974-11 CERAMIC CHIP
C350 1-104-662-91 ELECT
C351 1-162-915-11 CERAMIC CHIP
C352 1-162-915-11 CERAMIC CHIP
C360 1-104-658-91 ELECT
C361 1-104-658-91 ELECT
C801 1-162-927-11 CERAMIC CHIP
C802 1-162-927-11 CERAMIC CHIP
C803 1-162-927-11 CERAMIC CHIP
C804 1-162-915-11 CERAMIC CHIP
C805 1-162-915-11 CERAMIC CHIP
C806 1-162-915-11 CERAMIC CHIP
C807 1-162-927-11 CERAMIC CHIP
C808 1-162-927-11 CERAMIC CHIP
C809 1-162-927-11 CERAMIC CHIP
C810 1-162-927-11 CERAMIC CHIP
C811 1-162-927-11 CERAMIC CHIP
C812 1-162-927-11 CERAMIC CHIP
C813 1-162-927-11 CERAMIC CHIP
C814 1-162-919-11 CERAMIC CHIP
C815 1-162-919-11 CERAMIC CHIP
C816 1-164-156-11 CERAMIC CHIP
C817 1-104-658-91 ELECT
C818 1-162-927-11 CERAMIC CHIP
C819 1-162-927-11 CERAMIC CHIP
C820 1-115-156-11 CERAMIC CHIP
Remark Ref. No.
0.0047uF 10% 50V
100uF 20% 10V
10uF 20% 50V
4.7uF 20% 50V
47uF 20% 35V
0.001uF 10% 50V
0.001uF 10% 50V
47uF 20% 35V
47uF 20% 10V
100uF 20% 10V
0.1uF 10% 16V
0.1uF 10% 16V
4.7uF 20% 50V
(F10L)
4.7uF 20% 50V
(F10L)
1uF 20% 50V
1uF 10V
220PF 10% 50V
(F10L)
47uF 20% 35V
2200uF 20% 16V
* CN302
470uF 20% 10V
0.47uF 10% 16V * CN312
10uF 20% 50V * CN313
0.47uF 10% 16V * CN314
220uF 20% 16V
0.01uF 50V
22uF 20% 25V
1000uF 20% 10V * CN804
0.01uF 50V
22uF 20% 25V
* CN901
10PF 0.5PF 50V
10PF 0.5PF 50V
100uF 20% 10V
(F10L)
100uF 20% 10V
(F10L)
100PF 5% 50V
100PF 5% 50V
100PF 5% 50V
10PF 0.5PF 50V
10PF 0.5PF 50V
10PF 0.5PF 50V
100PF 5% 50V
100PF 5% 50V
100PF 5% 50V
100PF 5% 50V
100PF 5% 50V
100PF 5% 50V
100PF 5% 50V
22PF 5% 50V
22PF 5% 50V
0.1uF 25V
100uF 20% 10V
100PF 5% 50V
100PF 5% 50V
1uF 10V
Part No. Description
C821 1-115-156-11 CERAMIC CHIP
C822 1-126-923-91 ELECT
C823 1-164-156-11 CERAMIC CHIP
C824 1-115-156-11 CERAMIC CHIP
C825 1-126-964-11 ELECT
C826 1-164-156-11 CERAMIC CHIP
C830 1-162-974-11 CERAMIC CHIP
C832 1-162-974-11 CERAMIC CHIP
C833 1-162-927-11 CERAMIC CHIP
C835 1-162-974-11 CERAMIC CHIP
C905 1-164-156-11 CERAMIC CHIP
C910 1-126-937-11 ELECT
C951 1-162-974-11 CERAMIC CHIP
C952 1-162-974-11 CERAMIC CHIP
C953 1-126-935-11 ELECT
C957 1-162-974-11 CERAMIC CHIP
C959 1-126-923-91 ELECT
C960 1-107-826-11 CERAMIC CHIP
< CONNECTOR >
1-815-552-11 PIN, CONNECTOR (PWB) 4P
CN310 1-784-774-11 CONNECTOR, FFC 13P
1-815-551-11 PIN, CONNECTOR (PWB) 3P (F10L)
1-815-551-11 PIN, CONNECTOR (PWB) 3P (F10L)
1-815-551-11 PIN, CONNECTOR (PWB) 3P (F10L)
CN320 1-784-765-11 CONNECTOR, FFC 4P
CN802 1-784-773-11 CONNECTOR, FFC 12P
CN803 1-784-775-11 CONNECTOR, FFC 14P
1-815-550-11 PIN, CONNECTOR (PWB) 2P
CN806 1-784-775-11 CONNECTOR, FFC 14P
1-815-552-21 PIN, CONNECTOR (PWB) 4P
< DIODE >
D101 8-719-988-61 DIODE 1SS355TE-17
D201 8-719-988-61 DIODE 1SS355TE-17
D322 8-719-988-61 DIODE 1SS355TE-17
D323 8-719-988-61 DIODE 1SS355TE-17
D324 8-719-988-61 DIODE 1SS355TE-17
D801 8-719-083-93 DIODE KDS120-RTK
D802 8-719-941-86 DIODE DAN202U (AEP, UK, IT, EE, AUS)
D803 8-719-082-07 DIODE KDS121-RTK
D804 8-719-988-61 DIODE 1SS355TE-17
D910 8-719-083-93 DIODE KDS120-RTK
D920 8-719-082-07 DIODE KDS121-RTK
D921 8-719-069-54 DIODE UDZSTE-175.1B
D953 8-719-978-33 DIODE DTZ-TT11-6.8B
D957 8-719-083-58 DIODE UDZSTE-173.9B
< IC >
IC302 6-701-919-01 IC PT2257-S
IC304 8-759-426-51 IC BA5417
IC305 8-759-426-51 IC BA5417
IC801 6-804-289-01 IC uPD789477GC-A44-8BT
IC802 6-703-285-01 IC S-812C33AUA-C2NT2G
IC804 6-705-413-01 IC BD4826G-TR
IC805 6-703-769-01 IC BR24L01AF-WE2
CFD-F10/F10L
MAIN
Remark
1uF 10V
220uF 20% 10V
0.1uF 25V
1uF 10V
10uF 20% 50V
0.1uF 25V
0.01uF 50V
0.01uF 50V
100PF 5% 50V
0.01uF 50V
0.1uF 25V
4700uF 20% 16V
0.01uF 50V
0.01uF 50V
470uF 20% 16V
0.01uF 50V
220uF 20% 10V
0.1uF 10% 16V
49
