7-6. TAPE MECHANISM DECK SECTION (MF-F10)

252
Ref. No. Part No. Description
251 3-244-079-01 BELT (B), SUB
252 3-244-080-01 BELT (B), MAIN
253 3-244-083-01 +SCREW BIND DT M2X6
* 254 A-3683-864-A TC BOARD, COMPLETE (F10L)
* 254 A-4547-315-A TC BOARD, COMPLETE (F10)
M801
253
not
supplied
not
supplied
251
Remark
#3
not
supplied
254
not
supplied
256
not
supplied
Ref. No. Part No. Description
255 3-237-719-02 CHASSIS, TC
256 3-237-718-01 LEVER REC
M801 3-244-082-01 PULLEY (MOTOR)
#3 7-685-851-01 SCREW BV 2X4 CR-N4
CFD-F10/F10L
255
not
supplied
Remark
45
