Use the Aim tool to adjust your device. Please see the section
The device includes a grounding connection (marked ) which you should connect to the grounding installation of the tower or building where the device will
be used. This is to substantially reduce the risk of ESD and lightning damage. Grounding connector included in the package.
Warning! This equipment should be installed and operated with a minimum distance of 95 cm between the device and your body. Operation of
this equipment in the residential environment could cause radio interference.
The IP rating scale for this device is IP54.
Mounting and configuration of this device should be done by a qualified person.

Extension slots and ports

One Ethernet port, supporting automatic cross/straight cable correction (Auto MDI/X), so you can use either straight or cross-over cables for
connecting to other network devices.
WiGig, 802.11ad.

Powering

The devices accept powering from the Ethernet port. The Ethernet port accepts PoE input 12-57 V DC (passive and 802.3af/at). A power adapter and a
passive PoE injector are included in the box. When using the PoE injector, make sure to use the "Power + Data" connector to connect to the device, and
the "Data" connector to your PC, router or switch.
Connecting to a POE Adapter:
1. Connect the Ethernet cable from the device to the POE+DATA port of the POE adapter.
2. Connect an Ethernet cable from your local network (LAN) to the POE adapter.
3. Connect the power cord to the adapter, and then plug the power cord into a power outlet.
Maximum power consumption 5 W.

Configuration

We recommend clicking the "Check for updates" button and updating your RouterOS software to the latest version to ensure the best performance and
stability. RouterOS includes many configuration options in addition to what is described in this document. We suggest starting here to get yourself
accustomed to the possibilities:
to the MAC address of the device from the LAN side.
Please get yourself familiar with additional information on this interface:
For recovery purposes, it is possible to boot the device for reinstallation, see section

Buttons and jumpers

The routerBOOT reset button has the following functions. Press the button and apply the power, then:
Release the button when green LED starts flashing, to reset RouterOS configuration to defaults.
https://mt.lv/help . In case the IP connection is not available, the Winbox tool (

LED status.

https://wiki.mikrotik.com/wiki/Manual:Interface/W60G
Buttons and jumpers
https://mt.lv/winbox ) can be used to connect
.
