- Page 1 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer Technical Manual...
-
Page 2: Product Introduction
WiFi Wireless High Speed High Precision Inclinometer Product Introduction WF-WM410 WiFi wireless high speed high precision inclinometer sensor is a miniaturized intelligent digital tilt sensor designed for structural health monitoring. Using rechargeable lithium battery, it can work continuously for 24 hours on a single charge (continuous measurement and data transmission), and can be quickly charged by an external special charger. - Page 3 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer Application Ancient building protection monitoring Dangerous building monitoring ● ● Tunnel monitoring Bridge pylon survey ● ● Foundation pit inclinometer Dam monitoring ● ● Tower tilt monitoring Slope disaster prevention ● ●...
- Page 4 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer Resolution: The measured minimum change value that the sensor can detect and resolve within the measurement range. Accuracy: The error between the actual angle and the Root mean square(RMS) of the measured angle of the sensor (≥16 times).
-
Page 5: Electrical Connections
WF-WM410 WiFi Wireless High Speed High Precision Inclinometer Package size Product Size:：L109*W65*H72.5（mm） Note:±1mm error for length and width dimensions, please refer to actual size. 4 Hole Electrical connections Definition of Aviation Plug Wiring BLACK GREEN YELLOW Color & function 4.2V POWER 12.00V... -
Page 6: Product Installation
WF-WM410 WiFi Wireless High Speed High Precision Inclinometer Product installation The correct installation method can avoid measurement error. The following points should be made when installing the sensor: First of all, to ensure that the sensor mounting surface and the measured surface completely close, the measured surface should be as horizontal as possible, can not have the angle shown in Figure A and Figure C, the correct installation is shown in Figure B and Figure D. - Page 7 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer Debugging method 1 Serial data debugger SSCOM Download link: http://www.daxia.com/sscom/ http://www.daxia.com/sscom/sscom5.13.1.rar Instructions: ① Open the software and select ‘English’. ② Select the COM Port to be used. Bewis Sensing Technology LLC www.bwsensing.com...
- Page 8 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer ③ Select the BaudRate of 115200. ④ Unselect ‘HEXShow’ and ‘SendHEX’ and select ‘AddCrLf’. Bewis Sensing Technology LLC www.bwsensing.com Tel: +86 18906177922...
- Page 9 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer ⑤ Click ‘OpenCom’.nCom’. ⑥ Enter the command to be sent and click ‘SEND’. Open source software PuTTy Download link：https://www.chiark.greenend.org.uk/~sgtatham/putty/latest.html Instructions： ① Obtain the serial number, right-click ’ This PC->Manage->Device Manager->Ports (COM & LPT)’, if there are multiple COM*, you can try them one by one, but generally not COM1;...
- Page 10 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer ② Open the software; ③ Click Serial and select the serial port mode; ④ Enter the serial port number (Serial line: COM*) and baud rate (Speed: 115200); ⑤ Click Open to open the serial port;...
- Page 11 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer ⑥ Enter the command, and press Enter after entering a command. Note: Except Enter and Backspace, please do not press any non-printing characters (such as up, down, left and right, ESC), otherwise the input commands may be wrong, and please do not enter spaces if necessary, the same Causes a command error.
- Page 12 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer ③ Click Listen to start receiving data, if there is a pop-up window prompting network access, please click Allow, the sensor will automatically connect, and the receiving effect is as shown in the figure: ④...
-
Page 13: Command List
WF-WM410 WiFi Wireless High Speed High Precision Inclinometer Command list String commands sent through the serial port The following commands can configure the basic parameters of the sensor through the serial port. The serial port parameters are 115200bps, 8-bit Frame Length, 1 stop bit, and no parity bit. For the use of the serial port, please refer to the serial debugging tools section in the debugging method. - Page 14 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer Prompt: Most commands display further prompts when entering commands without entering parameters. ④ ECHO echo mode setting and acquisition MINIMALIST: Minimalist mode, only display the status of sending success or failure and query information,...
- Page 15 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer Set echo mode Send: ECHO+MINIMALIST or NORMAL or ADVANCED return: OK Example: ECHO+ADVANCED Get current echo mode Send: ECHO+STATUS Return: Current Mode: Current Mode ⑤ ADDR device address (not IP address) setting and...
- Page 16 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer ⑥ AOUT automatic output frequency setting and acquisition The allowed frequency range is 0-1000 (Hz), but higher than 50Hz may cause unstable operation. Please try to select a frequency within 0-50Hz. When the set automatic output frequency exceeds 1000, it is automatically set to 0.
- Page 17 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer Get current Wi-Fi information and status Send: WLAN+STATUS Return: Current Status: SSID<current network name> Password<current password> Connected or Disconnected ⑧ SOCKET socket settings and acquisition The protocol can choose TCP or UDP protocol, the actual sending frequency (pack/s) of UDP can be higher but the packet will be lost.
- Page 18 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer Get the current zero state Send: ZERO+STATUS Return: Current Status: Current status ⑩ SAVE Save configuration Save the sensor address, sending frequency, WLAN and SOCKET configuration, but do not save the echo mode.
- Page 19 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer Hexadecimal commands sent over the network 1 Data frame format: Identifier Frame Length Address Code Command Data Checksum (1 byte) (1 byte) (4 byte) （1 byte) (n byte) (1 byte) 0x77 Data format: 16...
- Page 20 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer The Data part is 12 Byte, divided into four groups, namely x-axis angle, y-axis angle, temperature, battery power. Each group of angle 4 bytes is a compressed BCD code, the first bit is the sign bit (0 positive, 1 negative), three integer values, four decimal places;...
- Page 21 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer 2.6 Set automatic output frequency Command：77 09 00 00 00 01 0C 00 10 26 Identifier Frame Length Address Code Command Data Checksum (1 byte) (1 byte) (4 byte) （1 byte) (2 byte)
- Page 22 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer 2.9 Save Settings Command：77 07 00 00 00 01 0A 12 Identifier Frame Length Address Code Command Data Checksum (1 byte) (1 byte) (4 byte) （1 byte) (0 byte) (1 byte) 0x77...
- Page 23 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer Executive standard Enterprise quality system standard: ISO9001:2015 standard (certificate number: 23919Q10455R0S) ● CE certification (certificate number: M.2019.103.UY1151) ● RoHS ( Certificate: G190930099 ) ● Bewis Sensing Technology LLC www.bwsensing.com Tel: +86 18906177922...
- Page 24 WF-WM410 WiFi Wireless High Speed High Precision Inclinometer Wuxi Bewis Sensing Technology LLC Address: Building 30, No. 58 Xiuxi Road, Binhu District, Wuxi City, Jiangsu Province, China Tel/Whatsapp: +86 17606 118 008 Email: support@bwsensing.com Website: www.bwsensing.com...
