Summary of Contents for DoorHan CV01

  • Page 1: Table Of Contents

    Назначение Технические характеристики Установка Схемы подключения устройств Программирование Правила техники безопасности General Information Specifications Installation Electrical Connections Programming Safety Rules Блок управления CV01 CV01 Control Unit Руководство по эксплуатации Owner’s Manual © DoorHan, 02.2021...
  • Page 2: Назначение

    ƒ электроприводами гаражных ворот; ƒ электроприводами солнцезащитных маркиз, оконных роллет и рольворот; ƒ освещением в помещении. Применяется также для совмещения пультов DoorHan с приводами других фирм и автоматизации различных приборов. 2. ТЕХНИЧЕСКИЕ ХАРАКТЕРИСТИКИ Таблица 1. Технические характеристики блока управления Наименование...
  • Page 3: Схемы Подключения Устройств

    СХЕМЫ ПОДКЛЮЧЕНИЯ УСТРОЙСТВ 4. СХЕМЫ ПОДКЛЮЧЕНИЯ УСТРОЙСТВ Рис. 1. Схема подключения двигателя рольставни к DoorHan CV01 Рис. 2. Пример схемы подключения освещения и внешнего радиоуправления к DoorHan CV01...
  • Page 4: Программирование

    ПРОГРАММИРОВАНИЕ Рис. 3. Схема подключения электрозамка Таблица 3. Назначение контактов (рис. 1, 2, 3) Контакт Назначение (N, L) XP3 Подключение питающего переменного напряжения 220 В/50–60 Гц Нейтраль Фаза Motor (M-L2, M-L1, M-N) XP5 Подключение электродвигателя Общий провод привода (голубой провод) M-L1 Направление...
  • Page 5 и клавиш выключателя показана в таблице 2. Выполнение всех команд отображается индикаторами «Open» и «Close». Индикатор «Power» включен при подаче питающего напряжения. Кнопка «P» используется при настрой- ке работы пультов дистанционного управления от встроенного приемника DoorHan. 5.2. НАСТРОЙКА РЕЖИМА РАБОТЫ...
  • Page 6: Правила Техники Безопасности

    ПРАВИЛА ТЕХНИКИ БЕЗОПАСНОСТИ ВНИМАНИЕ! ƒ В память встроенного приемника можно записать до 60 пультов DoorHan. При попытке записи 61-го пульта индикатор «Close» моргнет 3 раза, что означает переполнение памяти устройства. ƒ Многоканальный пульт занимает две ячейки памяти приемника. 5.5. ПРОГРАММИРОВАНИЕ ПУЛЬТА DOORHAN ПРИ ПОМОЩИ МНОГОКАНАЛЬНЫХ ПУЛЬТОВ...
  • Page 7: General Information

    ƒ sectional door operators; ƒ electric drives for sunshades, window shutters and rolling doors; ƒ lighting. It can also be used to provide effective operation of other companies‘ drives with DoorHan remote controls and to automate various devices. 2. SPECIFICATIONS Table 1.
  • Page 8: Electrical Connections

    220V, 50 Hz Fig. 1. Connection of roller shutter motor to CV01 control unit Built-in receiver 220V External receiver Connection of lamp power supply 220V, 50 Hz Lamp, 220 V Fig. 2. Connection of lighting and external receiver to CV01 control unit...
  • Page 9: Programming

    PROGRAMMING 220V Transformer 220 × 12, 15 W 220V, 50 Hz AC 12 V Electrical lock Fig. 3. Connection of electrical lock Table 3. Control board terminals (fig. 1, 2, 3) Terminal Function (N, L) XP3 Connection of the AC supply voltage, 220 V/50–60 Hz Power (neutral) Power (line) Motor (M-L2, M-L1, M-N) XP5...
  • Page 10 The “Open” and “Close” indicators are activated to show the commands have been executed. The “P” button is used to set up a remote control operation from the built-in DoorHan receiver.
  • Page 11: Safety Rules

    5.5. TO PROGRAM DOORHAN REMOTE CONTROLS WITH MULTI-CHANNEL REMOTE CONTROL 1. Press the button located on the rear side of a DoorHan multi-channel remote. This button switches the control board to the remote control recording mode (“Close” indicator lights up) provided that this remote control was previously recorded in the control board.
  • Page 12 For information on purchasing, distribution and servicing contact DoorHan central office at: 1 bld., 120 Novaya street, Akulovo village, Odintsovo city, Moscow region, 143002, Russia Phone: +7 495 933-24-00 E-mail: info@doorhan.com...
