Basic Parameters; Troubleshooting - Roborock WD1S1A User Manual

Basic Parameters

Body
WD1S1A
Model
1112 x 270 x 191 mm (3.648 x 0.886 x 0.627 ft)
Dimensions
5 kg (11.03 lbs)
Weight
260 W
Rated power
21.6 V
Rated voltage
< 4 hours
Charging time
22.2 V/5130 mAh(TYP) Lithium-ion battery
Battery
21.6 V/5000 mAh(TYP) Lithium-ion battery
Power Supply
Model S036-1A256140HU
Rated input 100–240 V~50/60 Hz, 1.0 A
Rated output 25.6 V
22.2 V/5130 mAh(TYP) Lithium-ion battery
Battery
21.6 V/5000 mAh(TYP) Lithium-ion battery
/22.2 V
1.4 A

Troubleshooting

If an error occurs during operation, the vacuum will stop operating
and play a voice alert. Follow the instructions provided by the alert.
Error
Error 1: Low battery. Recharge now.
Error 2: Clean water tank empty. Refill now.
Error 3: Dirty water tank full. Empty now.
Error 4: Remove blockages from the cleaning head.
For after-sales support, contact our support team at:
Email (US/Non-Europe): support@roborock.com
Phone (US only): 1-855-960-4321
18
