12-bit, 65msps/40msps/25msps low power quad adcs
Hide thumbs Also See for LTC2172-12:

Advertisement

Quick Links

FeaTures
4-Channel Simultaneous Sampling ADC
n
71dB SNR
n
90dB SFDR
n
Low Power: 306mW/198mW/160mW Total,
n
77mW/50mW/40mW per Channel
Single 1.8V Supply
n
Serial LVDS Outputs: One or Two Bits per Channel
n
Selectable Input Ranges: 1V
n
800MHz Full Power Bandwidth Sample-and-Hold
n
Shutdown and Nap Modes
n
Serial SPI Port for Configuration
n
Pin-Compatible 14-Bit and 12-Bit Versions
n
52-Pin (7mm × 8mm) QFN Package
n
applicaTions
Communications
n
Cellular Base Stations
n
Software Defined Radios
n
Portable Medical Imaging
n
Multichannel Data Acquisition
n
Nondestructive Testing
n
L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Linear
Technology Corporation. All other trademarks are the property of their respective owners.
Typical applicaTion
1.8V
CHANNEL 1
12-BIT
ANALOG
S/H
ADC CORE
INPUT
CHANNEL 2
12-BIT
ANALOG
S/H
ADC CORE
INPUT
CHANNEL 3
12-BIT
ANALOG
S/H
ADC CORE
INPUT
CHANNEL 4
12-BIT
ANALOG
S/H
ADC CORE
INPUT
ENCODE
PLL
INPUT
25Msps Low Power Quad ADCs
to 2V
P-P
P-P
1.8V
V
OV
DD
DD
DATA
SERIALIZER
GND
OGND
LTC2171-12/LTC2170-12
12-Bit, 65Msps/40Msps/
DescripTion
The LTC
2172-12/LTC2171-12/LTC2170-12 are 4-channel,
®
simultaneous sampling 12-bit A/D converters designed for
digitizing high frequency, wide dynamic range signals. They
are perfect for demanding communications applications
with AC performance that includes 71dB SNR and 90dB
spurious free dynamic range (SFDR). An ultralow jitter of
0.15ps
allows undersampling of IF frequencies with
RMS
excellent noise performance.
DC specifications include ±0.3LSB INL (typ), ±0.1LSB
DNL (typ) and no missing codes over temperature. The
transition noise is a low 0.3LSB
The digital outputs are serial LVDS to minimize the num-
ber of data lines. Each channel outputs two bits at a time
(2-lane mode) or one bit at a time (1-lane mode). The LVDS
drivers have optional internal termination and adjustable
output levels to ensure clean signal integrity.
+
and ENC
The ENC
or single-ended with a sine wave, PECL, LVDS, TTL or
CMOS inputs. An internal clock duty cycle stabilizer al-
lows high performance at full speed for a wide range of
clock duty cycles.
OUT1A
OUT1B
OUT2A
OUT2B
SERIALIZED
OUT3A
LVDS
OUT3B
OUTPUTS
OUT4A
OUT4B
DATA
CLOCK
OUT
FRAME
217212 TA01
LTC2172-12/
.
RMS
inputs may be driven differentially
LTC2172-12, 65Msps,
2-Tone FFT, f
= 70MHz and 75MHz
IN
0
–10
–20
–30
–40
–50
–60
–70
–80
–90
–100
–110
–120
0
20
10
FREQUENCY (MHz)
30
217212 TA01b
21721012fb
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LTC2172-12 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Linear Technology LTC2172-12

  • Page 1 Nondestructive Testing clock duty cycles. L, LT, LTC, LTM, Linear Technology and the Linear logo are registered trademarks of Linear Technology Corporation. All other trademarks are the property of their respective owners. Typical applicaTion 1.8V...
  • Page 2: Absolute Maximum Ratings

    LTC2172-12/ LTC2171-12/LTC2170-12 absoluTe MaxiMuM raTings pin conFiguraTion (Notes 1 and 2) Supply Voltages TOP VIEW , OV ..........–0.3V to 2V – Analog Input Voltage (A PAR/SER, SENSE) (Note 3) ..–0.3V to (V + 0.2V) 50 49 48 47 46 45 44 43 42 41 –...
  • Page 3: Analog Input

    LTC2172-12/ LTC2171-12/LTC2170-12 converTer characTerisTics denotes the specifications which apply over the full operating temperature range, otherwise specifications are at T = 25°C. (Note 5) LTC2172-12 LTC2171-12 LTC2170-12 PARAMETER CONDITIONS UNITS Resolution (No Missing Codes) Bits Integral Linearity Error Differential Analog Input (Note 6) –1...
  • Page 4: Dynamic Accuracy

    LTC2172-12/ LTC2171-12/LTC2170-12 DynaMic accuracy denotes the specifications which apply over the full operating temperature range, otherwise specifications are at T = 25°C. A = –1dBFS. (Note 5) LTC2172-12 LTC2171-12 LTC2170-12 SYMBOL PARAMETER CONDITIONS UNITS Signal-to-Noise Ratio 5MHz Input 70.9 70.5...
  • Page 5: Digital Inputs And Outputs

    LTC2172-12/ LTC2171-12/LTC2170-12 DigiTal inpuTs anD ouTpuTs denotes the specifications which apply over the full operating temperature range, otherwise specifications are at T = 25°C. (Note 5) SYMBOL PARAMETER CONDITIONS UNITS – ENCODE INPUTS (ENC , ENC – Differential Encode Mode (ENC...
  • Page 6: Power Requirements

    LTC2172-12/ LTC2171-12/LTC2170-12 power requireMenTs denotes the specifications which apply over the full operating temperature range, otherwise specifications are at T = 25°C. (Note 9) LTC2172-12 LTC2171-12 LTC2170-12 SYMBOL PARAMETER CONDITIONS UNITS Analog Supply Voltage (Note 10) Output Supply Voltage (Note 10)
  • Page 7 LTC2172-12/ LTC2171-12/LTC2170-12 TiMing characTerisTics denotes the specifications which apply over the full operating temperature range, otherwise specifications are at T = 25°C. (Note 5) SYMBOL PARAMETER CONDITIONS UNITS Digital Data Outputs (R = 100Ω Differential, C = 2pF to GND on Each Output)
  • Page 8: Timing Diagrams

    LTC2172-12/ LTC2171-12/LTC2170-12 TiMing DiagraMs 2-Lane Output Mode, 16-Bit Serialization N + 1 ANALOG INPUT ENCH ENCL – – DATA FRAME – – OUT#A OUT#A – OUT#B OUT#B 217212 TD01 SAMPLE N-6 SAMPLE N-5 SAMPLE N-4 AND D ARE EXTRA NON-DATA BITS FOR COMPLETE SOFTWARE COMPATIBILITY WITH THE 14-BIT VERSIONS OF THESE A/Ds.
  • Page 9 LTC2172-12/ LTC2171-12/LTC2170-12 TiMing DiagraMs 2-Lane Output Mode, 12-Bit Serialization N + 1 ANALOG INPUT ENCH ENCL – – DATA FRAME – – OUT#A OUT#A – OUT#B OUT#B 217212 TD03 SAMPLE N-6 SAMPLE N-5 SAMPLE N-4 1-Lane Output Mode, 16-Bit Serialization...
  • Page 10 LTC2172-12/ LTC2171-12/LTC2170-12 TiMing DiagraMs 1-Lane Output Mode, 14-Bit Serialization N + 1 ANALOG INPUT ENCH ENCL – – FRAME DATA – – OUT#A OUT#A 217212 TD05 SAMPLE N-6 SAMPLE N-5 SAMPLE N-4 – OUT#B , OUT#B ARE DISABLED AND D ARE EXTRA NON-DATA BITS FOR COMPLETE SOFTWARE COMPATIBILITY WITH THE 14-BIT VERSIONS OF THESE A/Ds.
  • Page 11: High Impedance

    LTC2172-12/ LTC2171-12/LTC2170-12 TiMing DiagraMs SPI Port Timing (Readback Mode) HIGH IMPEDANCE SPI Port Timing (Write Mode) HIGH IMPEDANCE 217212 TD07 21721012fb...
  • Page 12: Typical Performance Characteristics

    –120 –120 –120 FREQUENCY (MHz) FREQUENCY (MHz) FREQUENCY (MHz) 217212 G05 217212 G06 217212 G04 LTC2172-12: 8k Point 2-Tone FFT, LTC2172-12: SNR vs Input LTC2172-12: Shorted Input = 68MHz, 69MHz, –1dBFS, Frequency, –1dBFS, 2V Range, Histogram 65Msps 65Msps 18000 –10 16000 –20...
  • Page 13 LTC2172-12/ LTC2171-12/LTC2170-12 Typical perForMance characTerisTics LTC2172-12: SFDR vs Input Frequency, –1dBFS, 2V Range, LTC2172-12: SFDR vs Input Level, LTC2172-12: SNR vs Input Level, 65Msps = 70MHz, 2V Range, 65Msps = 70MHz, 2V Range, 65Msps dBFS dBFS –60 –40 –30 –20 –10...
  • Page 14 LTC2172-12/ LTC2171-12/LTC2170-12 Typical perForMance characTerisTics LTC2171-12: 8k Point FFT, LTC2171-12: 8k Point FFT, LTC2171-12: 8k Point FFT, = 29MHz, –1dBFS, 40Msps = 69MHz, –1dBFS, 40Msps = 139MHz, –1dBFS, 40Msps –10 –10 –10 –20 –20 –20 –30 –30 –30 –40 –40 –40...
  • Page 15 LTC2172-12/ LTC2171-12/LTC2170-12 Typical perForMance characTerisTics LTC2171-12: SNR vs SENSE, LTC2170-12: Integral Nonlinearity LTC2170-12: Differential (INL) Nonlinearity (DNL) = 5MHz, –1dBFS –0.2 –0.2 –0.4 –0.4 –0.6 –0.6 –0.8 –0.8 –1.0 –1.0 1024 2048 3072 4096 1024 2048 3072 4096 OUTPUT CODE...
  • Page 16 LTC2172-12/ LTC2171-12/LTC2170-12 Typical perForMance characTerisTics LTC2170-12: SFDR vs Input LTC2170-12: SNR vs Input Frequency, –1dBFS, 2V Range, Frequency, –1dBFS, 2V Range, LTC2170-12: SFDR vs Input Level, 25Msps 25Msps = 70MHz, 2V Range, 25Msps dBFS –80 –70 –60 –50 –40 –30 –20 –10...
  • Page 17: Pin Functions

    LTC2172-12/ LTC2171-12/LTC2170-12 pin FuncTions – (Pin 1): Channel 1 Positive Differential Analog (Pin 18): Encode Complement Input. Conversion Input. starts on the falling edge. – CS (Pin 19): In serial programming mode (PAR/SER = 0V), (Pin 2): Channel 1 Negative Differential Analog CS is the serial interface chip select input.
  • Page 18 LTC2172-12/ LTC2171-12/LTC2170-12 pin FuncTions PAR/SER (Pin 47): Programming Mode Selection Pin. LVDS OUTPUTS Connect to ground to enable serial programming mode. The following pins are differential LVDS outputs. The CS, SCK, SDI and SDO become a serial interface that con- output current level is programmable.
  • Page 19: Functional Block Diagram

    LTC2172-12/ LTC2171-12/LTC2170-12 FuncTional block DiagraM – 1.8V 1.8V OUT1A CHANNEL 1 12-BIT SAMPLE- ANALOG ADC CORE AND-HOLD OUT1B INPUT OUT2A CHANNEL 2 SAMPLE- 12-BIT ANALOG OUT2B AND-HOLD ADC CORE INPUT DATA SERIALIZER OUT3A CHANNEL 3 SAMPLE- 12-BIT ANALOG OUT3B AND-HOLD...
  • Page 20: Applications Information

    V /2. For the CM34 2V input range, the inputs should swing from V – 0.5V The LTC2172-12/LTC2171-12/LTC2170-12 are low power, to V + 0.5V. There should be a 180° phase difference 4-channel, 12-bit, 65Msps/40Msps/25Msps A/D convert- between the inputs.
  • Page 21 LTC2172-12/ LTC2171-12/LTC2170-12 applicaTions inForMaTion Transformer Coupled Circuits Amplifier Circuits Figure 7 shows the analog input being driven by a high Figure 3 shows the analog input being driven by an RF speed differential amplifier. The output of the amplifier is transformer with a center-tapped secondary.
  • Page 22 LTC2171-12/LTC2170-12 applicaTions inForMaTion Reference Encode Input The LTC2172-12/LTC2171-12/LTC2170-12 has an internal The signal quality of the encode inputs strongly affects 1.25V voltage reference. For a 2V input range using the the A/D noise performance. The encode inputs should internal reference, connect SENSE to V .
  • Page 23: Digital Outputs

    1.1V to 1.6V. In the differential encode mode, DIGITAL OUTPUTS – should stay at least 200mV above ground to avoid The digital outputs of the LTC2172-12/LTC2171-12/ falsely triggering the single-ended encode mode. For LTC2170-12 are serialized LVDS signals. Each channel good jitter performance ENC...
  • Page 24: Data Format

    LTC2172-12/ LTC2171-12/LTC2170-12 applicaTions inForMaTion Table 1. Maximum Sampling Frequency for All Serialization Modes. Note That These Limits Are for the LTC2172-12. The Sampling Frequency for the Slower Speed Grades Cannot Exceed 40MHz (LTC2171-12) or 25MHz (LTC2170-12). MAXIMUM SAMPLING SERIALIZATION MODE...
  • Page 25 To decode, the reverse operation is applied—an exclusive-OR operation is applied between The operating modes of the LTC2172-12/LTC2171-12/ the LSB and all other bits. The FR and DCO outputs are LTC2170-12 can be programmed by either a parallel not affected.
  • Page 26 LTC2172-12/ LTC2171-12/LTC2170-12 applicaTions inForMaTion Serial Programming Mode Timing Diagrams section). During a readback command the register is not updated and data on SDI is ignored. To use the serial programming mode, PAR/SER should be tied to ground. The CS, SCK, SDI and SDO pins become a The SDO pin is an open-drain output that pulls to ground serial interface that program the A/D mode control registers.
  • Page 27 LTC2172-12/ LTC2171-12/LTC2170-12 applicaTions inForMaTion REGISTER A2: OUTPUT MODE REGISTER (ADDRESS 02h) ILVDS2 ILVDS1 ILVDS0 TERMON OUTOFF OUTMODE2 OUTMODE1 OUTMODE0 Bits 7-5 ILVDS2:ILVDS0 LVDS Output Current Bits 000 = 3.5mA LVDS Output Driver Current 001 = 4.0mA LVDS Output Driver Current 010 = 4.5mA LVDS Output Driver Current...
  • Page 28: Heat Transfer

    ADC. HEAT TRANSFER High quality ceramic bypass capacitors should be used at Most of the heat generated by the LTC2172-12/LTC2171-12/ the V , OV , REFH and REFL pins. Bypass LTC2170-12 is transferred from the die through the bottom- capacitors must be located as close to the pins as possible.
  • Page 29: Typical Applications

    LTC2172-12/ LTC2171-12/LTC2170-12 Typical applicaTions Silkscreen Top Top Side Inner Layer 3 Inner Layer 2 GND 21721012fb...
  • Page 30 LTC2172-12/ LTC2171-12/LTC2170-12 Typical applicaTions Inner Layer 4 Inner Layer 5 Power Bottom Side Silkscreen Bottom 21721012fb...
  • Page 31 LTC2172-12/ LTC2171-12/LTC2170-12 Typical applicaTions LTC2172 Schematic SENSE PAR/SER 1µF 1µF 1µF 50 49 48 47 46 45 44 43 42 41 DIGITAL OUTPUTS OUT2A 0.1µF – – OUT2A OUT2B CM12 – OUT2B – – REFH LTC2172 REFH 2.2µF 0.1µF OGND REFL 0.1µF...
  • Page 32: Package Description

    LTC2172-12/ LTC2171-12/LTC2170-12 package DescripTion UKG Package 52-Lead Plastic QFN (7mm × 8mm) (Reference LTC DWG # 05-08-1729 Rev Ø) 7.50 ±0.05 6.10 ±0.05 5.50 REF (2 SIDES) 0.70 ±0.05 6.45 ±0.05 6.50 REF 7.10 ±0.05 8.50 ±0.05 (2 SIDES) 5.41 ±0.05 PACKAGE OUTLINE 0.25 ±0.05...
  • Page 33: Revision History

    Information furnished by Linear Technology Corporation is believed to be accurate and reliable. However, no responsibility is assumed for its use. Linear Technology Corporation makes no representa- tion that the interconnection of its circuits as described herein will not infringe on existing patent rights.
  • Page 34: Related Parts

    Integrated High Speed ADC, Passive Filters and Fixed Gain Differential Amplifiers Subsystem 21721012fb Linear Technology Corporation LT 0711 REV B • PRINTED IN USA 1630 McCarthy Blvd., Milpitas, CA 95035-7417 (408) 432-1900 FAX: (408) 434-0507 www.linear.com  LINEAR TECHNOLOGY CORPORA TION 2010 ● ●...
