MacDon Swath Compressor Operation And Parts Manual page 71

Part
Ref Number
D 184595
E 184714
F 184694
G 136604
H 184701
J 197230
K
136731
L 152668
M 18601
N 136178
P 135799
Q 152732
R
135691
S 252291
215953
ILLUSTRATED PARTS LISTS
WASHER – CONICAL SPRING 1/2 IN.
WASHER – FLAT REG M12-300HV-A3L
NUT – HEX M12 X 1.75-8-A3L
BOLT – RHSN TFL M5 X 0.8 X 40-8.8-AA1J
WASHER – FLAT LARGE M5-200HV
NUT – HEX NYLOC M5 X 0.8-8-A2L
BOLT – RHSN M6 X 1 X 45-8.8-A2L
NUT – HEX FLG CTR LOC M6 X 1-8-A2L
WASHER – SAE FLAT 13/16 I.D. X 1.5 IN. O.D. ZP
BOLT – RHSN M10 X 1.5 X 20-8.8-A3L
NUT – HEX FLG CTR LOC M10 X 1.5-10-A3L
BOLT – RHSN M10 X 1.5 X 40-8.8-A3L
BOLT – RHSN TFL M10 X 1.5 X 35-8.8-A3L
SCREW – PAN HD M6 X 1 X 8-8.8-A2L
Description
63
Qty
Serial Number
Revision A
