Electrical Connections
2706-P72 and 2706-P74
184.15
(7.25 REF)
139.70 (5.50)
8.74 x 12.70 (0.344 x 0.50)
OBRound Slot (3 Places)
3. Tilt the sign to select a viewing angle. To hold the sign in place,
screw a Phillips screw (supplied) through one of the small holes
on each bracket into the screw hole in the sign case.
Phillips screw
End view,
wall-mounted
Wall
TIP
WARNING
!
1. Open the front of the sign case by turning the quarter-turn
latches to the left with a large screwdriver. (On the
2706-P72CNx, there are 3 quarter-turn latches; on the
2706-P74CNx there are 4.) Carefully let the front of the case drop
forward.
(0.50 REF)
(0.36 TYP)
End view,
Wall
wall-mounted
69.85
(2.75)
19.05
(0.75)
End view,
ceiling-mounted
Keep a minimum 1.0-inch (2.54 cm) clearance on all
sides of the sign for adequate ventilation.
Hazardous voltage. Contact with high voltage may
cause death or serious injury. Always disconnect
power to sign prior to servicing.
InView Marquee Message Display
End view,
ceiling-mounted
Hex bolt
Ceiling
