TAE
800/1250
Svetslikriktare
Svejseensretter
Likeretter for sveising
Hitsaustasasuuntaaja
Welding rectifier
Schweißgleichrichter
Redresseur de soudage
Lasgelijkrichter
Rectificador de soldadura
Raddrizzatore per saldatura
Rectificador de soldagem
ÁíïñèùôÞò óõãêüëëçóçò
Bruksanvisning
Brugsanvisning
Bruksanvisning
Käyttöohjeet
Instruction manual
Betriebsanweisung
456 221- -101 060213
Manual d'instructions
Gebruiksaanwijzing
Instrucciones de uso
Istruzioni per l'uso
Manual de instruções
Ïäçãßåò ÷ñÞóåùò
Valid from Machine no 606 XXX- -XXX
Advertisement
Table of Contents
Related Manuals for ESAB TAE 800
Summary of Contents for ESAB TAE 800
- Page 1 800/1250 Svetslikriktare Svejseensretter Likeretter for sveising Hitsaustasasuuntaaja Welding rectifier Schweißgleichrichter Redresseur de soudage Lasgelijkrichter Rectificador de soldadura Raddrizzatore per saldatura Rectificador de soldagem ÁíïñèùôÞò óõãêüëëçóçò Bruksanvisning Manual d’instructions Brugsanvisning Gebruiksaanwijzing Bruksanvisning Instrucciones de uso Käyttöohjeet Istruzioni per l’uso Instruction manual Manual de instruções Betriebsanweisung Ïäçãßåò...
- Page 2 SVENSKA ..........DANSK .
- Page 3 ENGLISH DIRECTIVE ............INTRODUCTION .
-
Page 4: Declaration Of Conformity
It consists of a control unit and fan cooled power unit. TAE 800/1250 is designed for use in combination with PEG 1 control equipment. WARNING This product is intended for industrial use. In a domestic environment this product may cause radio interference. - Page 5 WARNING ARC WELDING AND CUTTING CAN BE INJURIOUS TO YOURSELF AND OTHERS. TAKE PRECAU- TIONS WHEN WELDING. ASK FOR YOUR EMPLOYER’S SAFETY PRACTICES WHICH SHOULD BE BASED ON MANUFACTURERS’ HAZARD DATA. ELECTRIC SHOCK - - Can kill Install and earth the welding unit in accordance with applicable standards. Do not touch live electrical parts or electrodes with bare skin, wet gloves or wet clothing.
-
Page 6: Technical Data
TECHNICAL DATA TAE 800 Maximum load AC 800 A/44 V at 100 % duty cycle 1000 A/44 V at 60 % duty cycle Current setting range AC 300 A/28 V -- 1000 A/44 V Max. open circuit voltage 71 V, according to calculation card... -
Page 7: Installation
If the power source is used in a dusty or dirty environment it should be blown clean more often. Spare parts are ordered through your nearest ESAB representative, see back cover. When ordering spare parts, please state machine type and number as well as desig- nation and spare part number as shown in the spare parts list on page 67. - Page 8 ESAB subsidiaries and representative offices Europe NORWAY Asia/Pacific Representative offices AS ESAB AUSTRIA BULGARIA CHINA Larvik ESAB Ges.m.b.H ESAB Representative Office Shanghai ESAB A/P Tel: +47 33 12 10 00 Vienna- -Liesing Sofia Shanghai Fax: +47 33 11 52 03...
