Use and Care Manual

30" Gas Pro-Range

HGR30*

Important Safety Instructions ....................................................................1

Consignes de Sécurité Importantes ......................................................... 3

Getting to Know the Range ....................................................................... 5

Operating the Range ...................................................................................7

Care and Cleaning ......................................................................................12

Troubleshooting .........................................................................................15

Warranty and Service ................................................................................16

Part No. 113712 Rev. G

Need help?

Do you have a question about the HGR30 Series and is the answer not in the manual?

Questions and answers

sarah hamilton

March 25, 2025

adjusting the legs in the front

Summary of Contents for Dacor HGR30 Series

Page 1: Table Of Contents
Use and Care Manual 30" Gas Pro-Range HGR30* Table of Contents Important Safety Instructions ..............1 Consignes de Sécurité Importantes ............3 Getting to Know the Range ............... 5 Operating the Range ...................7 Care and Cleaning ..................12 Troubleshooting ..................15 Warranty and Service ................16 Part No.
Page 2: Important Safety Instructions
Use common sense home, immediately call the gas supplier, and follow their and caution when using the range, and always contact Dacor instructions. (If you cannot reach the gas supplier, call the ﬁre Customer Service regarding issues you cannot resolve.
Page 3 Important Safety Instructions General Safety Precautions To reduce risk of ﬁre, electric shock, serious injury, and death in using the range, follow basic safety precautions, including: WARNING WARNING • If you receive a damaged product, immediately contact your dealer or builder. •...
Page 4: Consignes De Sécurité Importantes
éviter un incendie ou une explosion pouvant entraîner des dommages matériels, des blessures corporelles ou la mort. Contactez toujours l’équipe du service clientèle de Dacor à propos • Ne stockez pas ou n’utilisez pas d’essence ou d’autres vapeurs et de problèmes ou de situations que vous ne comprenez pas.
Page 5 Consignes de sécurité importantes Précautions générales de sécurité Pour réduire les risques d’incendie, d’électrocution, de blessure grave ou de mort lors de l’utilisation de votre cuisinière, suivez les précautions de sécurité de base, notamment: ATTENTION ATTENTION • Si vous recevez un produit endommagé, contactez immédiatement votre revendeur ou •...
Page 6: Getting To Know The Range
Getting to Know the Range Parts of the Cooktop Burner Locations and Cooktop Features A. 1300 to 9500 BTU Standard Burner BACKGUARD: The range comes with a 3-in. tall backguard, which B. 1700 to 15000 BTU Standard Burner protects the wall from heat and grease spatter. C.
Page 7 Getting to Know the Range Parts of the Oven Callout Feature Name Description Oven-Door Switch Monitors the self-cleaning cycle to lock/unlock the self-cleaning latch (M). This high-efﬁciency, infra-red broil burner is the oven’s source of top heat; burner glows orange on and off IR Broil Burner during a broil cycle.
Page 8: Operating The Range
Operating the Range Assembling the Cooktop 2. Install the burners as shown. When installing burner parts, twist WARNING each piece back and forth slightly until it drops into place. The burners do not work properly unless all pieces are properly seated. Operate the cooktop only when all burners are properly assembled.
Page 9 1. Orient the rack with the safety notches toward the oven. risk of scorching the food. • Dacor’s SimmerSear feature lets you precisely control the ﬂame on the SimmerSear burner, from low to high heat. Lighting a Burner Each knob has a small diagram next to it that shows which burner it controls.
Page 10 Operating the Range 6. To remove the rack: a. grasp it with both hands, and pull gently until it stops. Rack support b. tip the front up so the front safety clips clear the front of the supports, and pull the rack away from the oven. (Jiggle Slide rack the rack side-to-side as you pull to ease removal.) onto...
Page 11 Operating the Range Baking Tips Using Broil Mode WARNING Tips: All Bake Modes • Avoid opening the oven door if possible. Instead, check food • To avoid burn injuries, turn the oven knob to BROIL, immediately through the door window. put the food in the oven, and shut the door completely.
Page 12 Operating the Range Tips: Broiling Tips: Bakeware • For best results, use the pan size/type speciﬁed in the recipe. Broiling is a quick, ﬂavorful way to cook such foods as steak, chicken, chops, hamburgers, and ﬁsh. It is normal and necessary •...
Page 13: Care And Cleaning
Use these cleaners very carefully and only • Turn the oven off, or self-cleaning will restart when you close occasionally; otherwise, they will damage the ﬁnish. Dacor is not responsible for ﬁnish damage from abrasive cleaners. the oven door.
Page 14 If the ﬂame is uneven, verify proper burner assembly, and check for dirt/grime. If clicking is erratic, ensure the igniter is fully dry. If issues persist, call a Dacor-authorized service agent. Cleaning Porcelain Surfaces The oven chamber, oven-door interior, and spill tray have a porcelain-enamel ﬁnish.
Page 15 Care and Cleaning Replacing the Oven Light WARNING • Before starting, ensure all range surfaces are cool enough to touch. Push up to remove • Do not use the oven without the lens in place; the lens protects the bulb from breakage due to high temperature and mechanical Clips on back Horizontal shock.
Page 16: Troubleshooting
Troubleshooting Problem May Be Caused By What to Do Disconnected cord Verify that range is plugged in. Turn on power at circuit-breaker panel or fuse box; check for tripped Nothing works Power is off breaker or blown fuse. Power outage Contact power company.
Page 17: Warranty And Service
3. If none of these tips or suggestions resolves your roads, or other travel expenses. loss, time away from work, or visit dacor.com or call our Customer Service center at: restaurant meals. (833) 353-5483 (United States) Failure of the product caused Commercial, business, or rental by improper product installation.
Page 18 This Limited Warranty does not cover any defect, malfunction, We warrant to the original purchaser (“Purchaser”) that your failure or damage caused by or resulting from any of the Dacor Pro-Range purchased from an authorized reseller or following: distributor in Canada (the “Products”) is free from defects in...
Page 19 LIMITED WARRANTY IS GOVERNED BY THE LAWS OF THE directed to deliver the Product to a Dacor Authorized PROVINCE OF QUEBEC. Service Center for warranty service. The cost of transportation...
Page 20 (G) THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY If your Dacor product fails to function within one year of the FROM PROVINCE TO PROVINCE. THIS LIMITED WARRANTY original date of purchase due to a defect in material or workman- STATES THE PURCHASER’S EXCLUSIVE REMEDY.
Page 21 Notes...
Page 22 Notes...
Page 23 Notes...
Page 24 Contact Dacor If you have any questions or comments relating to Dacor appliances, please contact the Dacor Customer Service Center. Country Contact Center Web Site U.S.A 1-833-353-5483 www.dacor.com CANADA 1-844-509-4659 www.dacor.com...
