78K0R – Save It!

6.7 Confirmation of USB Driver Installation

After installing the USB driver, check that the driver has been installed normally, according to
the procedure below. When using the Save It! board the "NEC Electronics Starter Kit Virtual
UART" should be present like in the figure below.
Please check in the Windows "Device Manager" within the Windows Properties ("Hardware"
tab), that the driver is installed normally.
_______________________________________________________________________________________________

Figure 23: USB Driver Installation Completion (Windows XP)

Figure 24: Windows Device Manager

U19663EE1V0UM00
User's Manual
Click.
Check that "NEC Electronics
Starter Kit Virtual UART (COM?)"
is present.
29
