78K0R – Save It!
Please check that the correct host communication port is selected. The used communication port can be
seen in the Windows Device

9.2 Using WriteEZ4

After a successful device selection the internal flash memory can be blank-checked, erased, programmed or
verified. WriteEZ4 can be controlled either by menu or by buttons
WriteEZ4 supports Intel-Hex and Motorola S-record file formats as input file.
_______________________________________________________________________________________________
Manager.

Figure 29: WriteEZ4 Device Menu

device setup button
load file button
blank check button
erase button
program button
verity button
Autoprocedure button

Table 9: WriteEZ4 action buttons

U19663EE1V0UM00
User's Manual
34
