Panel Explanation; Led; Connectors - Draytek Vigor3910 Series Quick Start Manual

2 . P a n e l E
2 . P a n e l E
2 . 1 L E D
2 . 1 L E D

LED

PWR
ACT
USB
SFP+
Left
P3 ~
P12
Right
2 . 2 C o n n e c
2 . 2 C o n n e
Interface
USB1 / USB2
Console
SFP+ (P1~P2)
2.5GBase-T
(P3~P4)
GbE P5~P8
GbE P9~P12
x p l a n a t i o
x p l a n a t i o
Status Explanation
On The router is powered on.
Off The router is powered off.
Blinking The system is active.
Off The system is hanged.
On The USB device is installed and ready.
Off
No USB device is installed.
On The fiber connection is established.
Off
No fiber connection is established or the system is
hanged.
On
The Ethernet link is established on corresponding port.
Off
No Ethernet link is established.
Blinking
The data is transmitting.
On
The Ethernet link is established on corresponding port
with 1G Mbps or above.
Off
The Ethernet link is established on corresponding port
with less than 1G Mbps.
t o r s
c t o r s
Description
Connecter for the USB device.
Provided for technician use.
Connecter for SFP module with the rate of 10G/1G bps.
Connector for remote network devices or local network devices
(WAN/LAN) with the rate of 2.5G/1G/100M/10M bps.
Connectors for remote network devices or local network devices
(WAN/LAN) with the rate of 1G/100M/10M bps.
Connecter for local network devices (LAN) with the rate of
1G/100M/10M bps.
The Factory Reset button is used to restore the default settings.
Turn on the router (ACT LED is blinking). Press the hole and keep for
more than 5 seconds. When you see the ACT LED begins to blink
rapidly than usual, release the button. Then the router will restart
with the factory default configuration.
Connecter for a power cord.
ON/OFF - Power switch.
