GUIDE
ETM770-PRO
CELLULAR NETWORK MONITORING TOOL
Cat M1/Cat NB/NB2/4G/3G/2G
1
For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au
1802–20220005 Rev PA1, 2022-04-14
USER
Features:
•
Cat NB, Cat M1 Connectivity
•
4G/3G/2G Connectivity
•
GPS Functionality
•
Select the most suitable antenna
•
OLED display
•
Send measured data to EWO server
•
Rechargeable battery
•
Sleep Mode for super low power
consumption
•
Includes antenna, hard case and
charger
