ETM ETM770-9 User Manual

Cellular network monitoring tool 2g/cat-m1/cat-nb
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GUIDE
ETM770-9
CELLULAR NETWORK MONITORING TOOL
1
For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au
1802–20180005 01, 2020-05-05
USER
2G/CAT-M1/CAT-NB
Features:
•
Cat NB & Cat M1 Connectivity
•
2G (GSM/EGPRS) Connectivity
•
Select the most suitable antenna
•
OLED display
•
Send measured data to EWO server
•
Rechargeable battery
•
Sleep Mode for super low power
consumption
•
Includes antenna, hard case and
charger

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ETM770-9 and is the answer not in the manual?

Questions and answers

Related Manuals for ETM ETM770-9

Summary of Contents for ETM ETM770-9

  • Page 1 For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au 1802–20180005 01, 2020-05-05 USER GUIDE ETM770-9 CELLULAR NETWORK MONITORING TOOL 2G/CAT-M1/CAT-NB Features: • Cat NB & Cat M1 Connectivity • 2G (GSM/EGPRS) Connectivity • Select the most suitable antenna •...

  • Page 2: Table Of Contents

    For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au TABLE OF CONTENTS Connecting the sim card ........................3 Get started scanning a signal with ETM770 ..................4 2G Mode ............................. 5 CAT-M1 Mode ............................. 6 CAT-NB Mode .............................

  • Page 3: Connecting The Sim Card

    For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au CONNECTING THE SIM CARD...

  • Page 4: Get Started Scanning Asignal With Etm770

    For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au GET STARTED SCANNING A SIGNAL WITH ETM770 1. Insert SIM card as shown in picture above. 2. Insert the charger into the mini USB connector. The battery is charged with 5V. 3.

  • Page 5: 2G Mode

    For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au 2G Mode Scan Menu 2G mode The device is connected to a 2G band. The channel is 82 and the frequency is 900 MHz Empty space III.

  • Page 6: Cat-M1 Mode

    For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au CAT-M1 Mode Scan Menu CAT-M1 mode The device is connected to a CatM1 band. The channel is 20 and the frequency is 800 MHz. Reference Signal Received Power (the signal strength without noise and interference) measured in dBm.
  • Page 7 For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au VII. Signal Quality Bar VIII. Different data rolls in the bottom bar. CH, PLMN, the scanned network and RSSI.

  • Page 8: Additional Settings

    For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au ADDITIONAL SETTINGS With ETM770 it is possible to make several additional settings. Select Radio Band Main Menu Signal Scan Menu Select Radio Band Menu 1. Starting at the main menu, press "Signal Scanning" 2.
  • Page 9 For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au 3. A list of operators is shown. To see which operators are available please see the numbers on the right of the display. First letter means Operator status and the second letter means Radio Access Technology (RAT).

  • Page 10: View Current Network Data

    For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au View Current Network Data Main Menu Signal Scan Menu Current Network Data 1. Starting at the main menu, press "Signal Scanning" 2. At the Signal Scan menu, select "Current Network Data" 3.
  • Page 11 For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au 4. If you press the down arrow once you will get a picture that looks similar to the one below: Monitoring Neighbour Cells Number of Neighbour Cells found Cell Description III.
  • Page 12 For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au 5. If you press the down arrow once again you will get the following: SIM status Registration status III. “Network provider(EONS):” (Info text string) Network provider 6.
  • Page 13 For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au 7. Table below shows a brief explanation of the network abbreviations. ABBREVIATION FULL NAME FURTHER EXPLANATIONS EARFCN CHANNEL E-UTRA Absolute Radio Frequency Channel Number Band Frequency Band E-UTRA frequency band DL bandwidth...

  • Page 14: View Last Scan

    For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au View last scan Main Menu Signal Scan Menu Last Scan 1. Starting at the main menu, press "Signal Scanning" 2. At the Signal Scan menu, select "Last Scan" Scanned network.

  • Page 15: Communication Test

    For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au Communication Test Main Menu 1. Starting at the main menu, press "Communication Test" 2. Press "PING: 8.8.8.8" This is the IP address to the Google server. 3.

  • Page 16: Send Data To Server

    Send Data to Server Main Menu 1. Starting at the main menu, press "Send Data to Server" 2. Press "Send Last Scan" The IP address 54.77.219.177 is the address to ETM WEB Office server. 3. Connecting ISP and Connecting Server.

  • Page 17: Device Data

    For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au Device Data Main Menu Device Data Device Data Menu 1. Starting at the main menu, press "System" 2. Select "Device Data" 3. Device Data SIM card ID number (SCID) Device FW ID number III.

  • Page 18: Select Apn

    For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au Select APN Main Menu Device Data Menu APN list 1. Starting at the main menu, press "System" 2. Press "Select APN" 3. Choose alternative in the menu. In order to change the APN list, send SMS with following syntax to the device: ETSAPN=“List position”, “APN name”...

  • Page 19: Server Address

    For Support Contact +46 8 25 28 75, sales@etmiot.se or +61 2 9956 7377, sales@etmiot.com.au Server Address Main Menu Device Data Menu Server Address 1. Starting at the main menu, press "System" 2. Press "Server Address" 3. See Server Address Remote IP address 1 Remote Port 1 III.

  • Page 20: Restart Device

    Note: Pressing both the up and the down key for 5 second can also perform a restart of the device. ETM Mätteknik AB ETM Pacific Pty Ltd Ekbacksvägen 32, SE-168 69 Bromma, Sweden Suite 6, 273 Alfred Street, North Sydney NSW 2060, Australia...
