ETM770 Users Manual 201709RV01
ETM770-4 4G/3G HSPA Signal Strength Meter
ETM770-4 Signal Strength Meter
User Manual
Features:
◩
LCD Display with backlight
◩
Scan for signal strength
◩
Identify network operators
◩
SMA antenna connectors (FME adapter included)
◩
Internal rechargeable battery pack
◩
Mini USB connector for programming and recharging
◩
Send TCP/IP data packages to a server to confirm connectivity
Advertisement
Table of Contents
Related Manuals for ETM ETM770-4
Summary of Contents for ETM ETM770-4
- Page 1 ETM770 Users Manual 201709RV01 ETM770-4 4G/3G HSPA Signal Strength Meter ETM770-4 Signal Strength Meter User Manual Features: ◩ LCD Display with backlight ◩ Scan for signal strength ◩ Identify network operators ◩ SMA antenna connectors (FME adapter included) ◩ Internal rechargeable battery pack ◩...
-
Page 2: Table Of Contents
Page 2 of 20 For Support Contact +61-2-9956-7377 Or support@etmpacific.com.au Contents Explanatory List of Network Abbreviations ..................3 Introduction ............................4 Nomenclature ..........................4 Overview............................4 Applications ........................... 4 Specifications ............................ 4 Charging Temperature Limitation ..................... 4 Understanding Unit Operation Issues ....................5 Limitations - Selecting a Net Operator then Scanning for Signal .......... -
Page 3: Explanatory List Of Network Abbreviations
Page 3 of 20 For Support Contact +61-2-9956-7377 Or support@etmpacific.com.au Explanatory List of Network Abbreviations Abbreviation Full Name Explanation CHANN Channel Shows the ARFCN (Absolute Frequency Channel Number) of the Radio Band Frequency Primary Synchronization Code Describes start and stop time for the time slot that the device has been allocated PLMN... -
Page 4: Introduction
ETM770-4 incorporates the Cinterion ELS61-AUS wireless module. Overview. The ETM770-4 is designed for measuring the signal strength of 4G and 3G cellular operators at a particular location. The unit can detect the frequency bands indicated on the following page, around the world there are more 3G and 4G frequencies used than the ETM770-4 can detect - make sure that the unit is suitable for the signal being scanned. -
Page 5: Understanding Unit Operation Issues
Page 5 of 20 For Support Contact +61-2-9956-7377 Or support@etmpacific.com.au Understanding Unit Operation Issues Key operational features of the unit may limited by the SIM/Network being used, these limitations need to be understood to ensure you get the most out of the unit. Note Registration to 4G networks can take longer than normally expected and depends on the network/SIM. -
Page 6: Interfaces
Username and "password" Password SIM Pin This is not set If required to be set contact ETM IP addresses and ports for ping These are not set If required to be set refer Checking IP Connectivity test... -
Page 7: Starting The Unit
Page 7 of 20 For Support Contact +61-2-9956-7377 Or support@etmpacific.com.au Starting the Unit After ensuring the unit is off, insert a suitable SIM card and connect your antenna of choice. We recommend that the SIM PIN (if applicable) is deactivated before inserting in the unit. If the unit has sufficient charge then depressing the On/Off button will start the unit. -
Page 8: Last Scan
Page 8 of 2 For S Support Co ontact +61-2 2-9956-7377 Or supp ort@etmpa acific.com.au Last Scan This option n will show results of th he last scan n that was p performed. Neighbour Cells This option n will indicat te how man ny neighbou ur cells are a... -
Page 9: Set Ip Address
Page 9 of 20 For Support Contact +61-2-9956-7377 Or support@etmpacific.com.au ETSAPN=x,APN Where = the position in the list APN = The APN for that position in the list Example: ETSAPN=1,telstra.internet ETSAPN=2,telstra.extranet Set IP Address The following commands should be used to set the IP-Address for connection to a Server, these commands can be sent using a terminal window or by SMS to the unit. -
Page 10: Main Menu - 3. Network Operators
Page 10 of 20 For Support Contact +61-2-9956-7377 Or support@etmpacific.com.au Main Menu - 3. Network Operators Signal strength and cell information for available networks can be scanned from a SIM of any valid network operator. Note that registration on the network and ISP connectivity testing (see above) is only applicable for the network which provided the SIM. -
Page 11: Main Menu - 4. Status
Page 11 of 20 For Support Contact +61-2-9956-7377 Or support@etmpacific.com.au Main Menu – 4. Status The Status section provides additional information on the current network connection as well as details of the unit’s battery status and firmware version. Press the UP and DOWN buttons to select 4. Status and press ENTER to access the unit status details. -
Page 12: Network
Page 12 of 20 For Support Contact +61-2-9956-7377 Or support@etmpacific.com.au Network Select Network. Information such as cell details, relating to the network to which the unit is set will be displayed. Scroll down until Return appears and press Enter to return to previous menu. Settings Select Settings. -
Page 13: Main Menu - 5. Services
Page 13 of 20 For Support Contact +61-2-9956-7377 Or support@etmpacific.com.au Main Menu – 5. Services The Services menu section allows you to change Radio Band Region and Radio Band as well as Shutdown and Restart the device. Radio Band Setting This section allows the selection of a specific radio band for scanning. -
Page 14: Restart Device
Note pressing the UP and DOWN arrows together will software reset the unit. Using a Terminal Window to Configure the Unit Any suitable terminal program, such as Windows HyperTerminal, ETM’s Term42 Program, or the units configuration tool (available free of charge upon request) can be used to set certain parameters in the unit. -
Page 15: Some Common Useful Commands To Use With Terminal Window
Page 15 of 20 For Support Contact +61-2-9956-7377 Or support@etmpacific.com.au Some Common Useful Commands to Use with Terminal Window Command Usage Typical Response To gain a quick summary of See above example the units status as well as information on units firmware version ETSEND=AT+COPS? To determine network &... -
Page 16: Troubleshooting
(recomm ended) Use C Configuration n tool to enter SIM PIN con ntact ETM for as ssistance No or very y weak signa If S SIM PIN oka ay the followi ng start-up Check... - Page 17 Page 17 of 20 For Support Contact +61-2-9956-7377 Or support@etmpacific.com.au this page has intentionally been left blank Etm770 Users Manual 201709rv01...
- Page 18 Page 18 of 20 For Support Contact +61-2-9956-7377 Or support@etmpacific.com.au this page has intentionally been left blank Etm770 Users Manual 201709rv01...
- Page 19 Page 19 of 20 For Support Contact +61-2-9956-7377 Or support@etmpacific.com.au this page has intentionally been left blank Etm770 Users Manual 201709rv01...
- Page 20 Tel: +46 (0)8 25 28 75 Tel: +61 (0)2 9956 7377 Fax: +46 (0)8 80 11 10 Fax: +61 (0)2 9956 5791 Email: etm@etm.se Email: info@etmpacific.com.au Web: www.etm.se Web: www.etmpacific.com.au © ETM Pacific Pty Ltd · Subject to change without notice.
