- Page 1 PRM-0082I High Performance Pentium II PCI Mainboard User’s Guide Edition 1.02 © 1998 DTK Computer Inc.
- Page 2 WARNING For the system to operate normally, please make sure J4 of the mainboard is set as below. Refer to Fig. 4 in this manual for the location J4. If J4 is shorted to 1-2, no CMOS data can be retained. CAUTION The motherboard is an electrostatic sensitive device.
-
Page 3: Table Of Contents
CONTENTS CHAPTER 1 INTRODUCTION CHAPTER 2 JUMPER SETTINGS JUMPERS PRESENTATION GRAPHICAL DESCRIPTION OF JUMPER SETTINGS CPU SPEED J4 - CLEAR CMOS DATA J24 – POWER ON/OFF AFTER POWER FAILURE MEMORY CONFIGUARTION CHAPTER 3 CONNECTOR CONFIGURATION J1 - SPEAKER J2 - POWER ON/OFF SWITCH J3 - RESET J5 –... - Page 4 4.10 USER PASSWORD 4.11 IDE HDD AUTO DETECTION 4.12 SCSI HARD DISK INSTALLATION 4.13 SAVE & EXIT SETUP MENU 4.14 EXIT WITHOUT SAVING MENU CHAPTER 5 SOFTWARE INSTALLATION INTEL 82440EX PCI AGP CHIPSET PATCH UTILITY FOR WINDOWS 95 INTEL BUS MASTER IDE DRIVER FOR WIN 95 INSTALLATION SOUND DRIVER INSTALLATION THE AUDIORACK32 FOR WIN95 5.4.1...
-
Page 5: Introduction
CHAPTER 1 INTRODUCTION Preface The motherboard is a 4 layer, Mini ATX form factor high performance PCI/AGP mainboard. It includes Intel i82440EX system chipset, Winbond W83977TF Super I/O controller, ESS 1869 Sound Chip. Features Processor • Intel Pentium II series. •... - Page 6 Chapter 1 Sound Controller (Optional) • Compatible with all major PC sound standards, including Sound Blaster™ Pro, MPU-401 and Windows Sound System™. • Plug-and-Play support for Audio, Joystick, FM Controller, MPU-401. • Wave Audio support sample rates from 4KHz to 44KHz. •...
-
Page 7: Jumper Settings
CHAPTER 2 JUMPER SETTINGS JUMPERS PRESENTATION Pins 1 and 2 are shorted with a jumper cap. Pins 2 and 3 are shorted with a jumper cap. The jumper is shorted when the jumper cap is placed over the two pins of the jumper. The jumper is open when the jumper cap is removed from jumper. -
Page 8: Graphical Description Of Jumper Settings
Chapter 2 GRAPHICAL DESCRIPTION OF JUMPER SETTINGS Fig. 2 Jumper Location of the mainboard... -
Page 9: Cpu Speed
Jumper Settings CPU SPEED Fig. 3 The table below summaries the CPU frequence and settings of each jumper of the motherboard. CPU Type Freq. Ratio Bus Freq. Rating Setting Pentium II 233MHz 3.5x JP2: 1-2 OFF 3-4 OFF 5-6 ON Pentium II 266MHz 4.0x... -
Page 10: J4 - Clear Cmos Data
Chapter 2 J4 - CLEAR CMOS DATA J4 is used to clear the content of the CMOS Data in the RTC (build in PIIX4 chip). Table 2: Clear CMOS Data J24 – POWER ON/OFF AFTER POWER FAILURE This jumper sets the power of the system after the main power has failed then recovered. -
Page 11: Connector Configuration
CHAPTER 3 CONNECTOR CONFIGURATION Once the mainboard has been fastened into system case, the next step is to connect the internal cables. The internal cables are wire leads with plastic female connectors that attach to the connectors. The mainboard connectors have varying numbers of pins and are the points of contact between the mainboard and other parts of the computer. -
Page 12: J1 - Speaker
Chapter 3 J1 - SPEAKER J1 is a four pins connector, which is used to connect the system speaker. Fig. 5 Speaker J2 - POWER ON/OFF SWITCH It is used to switch on or off the ATX power supply. The power is turned on by short the power switch once. -
Page 13: J6 - Hdd Led
Connector Configuration J6 - HDD LED J6 is usually connected to a HDD LED on front of the system case. If the HDD is in operation, the indicator lights during operation. Fig. 7 HDD LED J7 - IrDA CONNECTOR J7 is a IrDA connector that use UART2 as interface of IrDA Infrared and ASKIR. Fig. -
Page 14: J15 - Cd-Rom Audio Connector (Mitsumi/Panasonic)
Chapter 3 J15 – CD-ROM AUDIO CONNECTOR (MITSUMI/PANASONIC) Fig. 10 CD-ROM Audio 3.10 J16, JA1 – CPU, SYSTEM/POWER SUPPLY FAN CONNECTOR J16 is a three-pin connector, which is used to connect with the CPU Fan Power cable. JA1 is another three-pin connector for optional System/Power Supply Fan. 3.11 J19 - FLOPPY DRIVE CONTROLLER This connector supports the floppy drive ribbon cable. -
Page 15: Ps1 - Atx Power Supply Connector
Connector Configuration 3.14 PS1 - ATX POWER SUPPLY CONNECTOR Fig. 13 ATX Power Supply Connector Fig. 14 I/O Connector 3.15 PS/2 KEYBOARD CONNECTOR This connector is a six-pin female mini DIN connector using a PS/2 plug. If a standard AT size keyboard plugs, you may use the DIN to mini DIN adaptor. 3.16 PS/2 MOUSE CONNECTOR This connector is a six-pin female mini DIN connector using a PS/2 plug. -
Page 16: Serial Port Com1 & Com2
Chapter 3 3.18 SERIAL PORT COM1 & COM2 This is a D-Type 9 pin male connector for pointing devices or other serial devices. 3.19 PARALLEL PORT CONNECTOR This is a D-Type 25 pin female connector. 3.20 AUDIO PORT CONNECTOR Three 1/8” female connectors used as speaker, line in and microphones. SPK can be connected to headphones or preferably powered speakers. - Page 17 Connector Configuration Retention Mechanism Attach Mount Fig. 15b Heatsink Top Support Fig. 15c Heatsink Support Base Fig. 15d...
- Page 18 Chapter 3 Top Holder for Celeron Fig. 15e Before the installation of RM Kits find the six holes on the motherboard for RM installation. The hole position and usage is as following: Fig. 16 Installation Guide for Pentium II Mount the two RM Attach Mounts onto the motherboard from bottom side. These mounts will be used to attach the RM Assembly.
- Page 19 Connector Configuration Install the Heatsink Support Base onto the motherboard, insert the two plastic nail to the hole in the Heatsink Support Base as following diagram: Fig. 17 Insert the Heatsink Top Support to the Pentium II Heatsink and the Heatsink Support Base as the following diagram: Fig.
- Page 20 Chapter 3 Insert the Top Holder for Celeron as the following diagram: Fig. 19 Fig. 20 Note: There is mechanical conflict between Intel Box Celeron CPU’s Cooler with normal Pentium II retention. Cause the CPU with a bit inclination. When installing the Top Holder for Celeron, make sure that the PCB of the CPU is fitted into the rail inside the Top Holder.
-
Page 21: Award Bios Setup Guide
CHAPTER 4 AWARD BIOS SETUP GUIDE This following manual is specially provided for the BIOS supported system. After the configuration of the mainboard, and have assembled the components, user can turn on the completed system. At this point, run the software setup to ensure that the system information is correct. - Page 22 Chapter 4 Press the <DEL> key to enter the AWARD BIOS setup program and the following screen appears: ROM PCI/ISA BIOS (2A69JD1F) CMOS SETUP UTILITY AWARD SOFTWARE, INC. STANDARD CMOS SETUP INTEGRATED PERIPHERALS BIOS FEATURES SETUP SUPERVISOR PASSWORD CHIPSET FEATURES SETUP USER PASSWORD POWER MANAGEMENT SETUP IDE HDD AUTO DETECTION...
-
Page 23: Standard Cmos Setup
Award BIOS Setup Guide STANDARD CMOS SETUP ROM PCI/ISA BIOS (2A69JD1F) STANDARD CMOS SETUP AWARD SOFTWARE, INC. Date (mm:dd:yy) : Wed, May 21 1997 Time (hh:mm:ss) : 20 : 27 : 55 HARD DISKS TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE Primary Master : Auto AUTO... -
Page 24: Bios Features Setup
Chapter 4 BIOS FEATURES SETUP ROM PCI/ISA BIOS (2A69JD1F) BIOS FEATURES SETUP AWARD SOFTWARE, INC. Virus Warning : Enabled Video BIOS Shadow : Disabled CPU Internal Cache : Disabled C8000-CBFFF Shadow : Disabled External Cache : Disabled CC000-CFFFF Shadow : Disabled Quick Power On Self Test : Disabled D0000-D3FFF Shadow... - Page 25 Award BIOS Setup Guide Boot Sequence: With the default setting the BIOS first attempts to boot from drive A: and then, if unsuccessful, from hard disk C:. User can select other boot up sequence. Available sequences are “A,C,SCSI”, “C,A,SCSI”, “C,CDROM,A”, “CDROM,C,A”, “D,A,SCSI”, “E,A,SCSI”, “F,A,SCSI”, “SCSI,A,C”, “SCSI,C,A”, “C only”, “LS120/ZIP,C”.
-
Page 26: Chipset Features Setup
Chapter 4 Report No FDD For WIN 95: Choose Yes or No. Yes will show a removable disk in Windows 95 when the floppy drive is set as None. Video BIOS Shadow: ROM Shadow copies Video BIOS code from slower ROM to faster RAM. Video BIOS can then execute from RAM. - Page 27 Award BIOS Setup Guide A short description of the screen items follows: Auto Configuration: When Auto Configuration is Enabled, BIOS will sets the CPU Clock according to CPU speed. Otherwise, set it manually. DRAM Speed Selection: Choose 60ns or 70ns according to the DRAM SIMM Module on the motherboard.
-
Page 28: Power Management Setup Menu
Chapter 4 POWER MANAGEMENT SETUP MENU The Power Management Setup option is used to change the values of the chipset registers for system power management functions. ROM PCI/ISA BIOS (2A69JD1F) POWER MANAGEMENT SETUP AWARD SOFTWARE, INC. ACPI Function : Enabled ** Reload Global Timer Events ** Power Management : Disabled... - Page 29 Award BIOS Setup Guide Video Off Method: Choose V/H SYNC+Blank, DPMS or Blank Screen. This is monitor Power Saving Method. V/H SYNC+Blank means turn off Vertical, Horizontal scanning and blank the screen. Blank Screen will blank the display screen. DPMS (Display Power Management System) can allow the System BIOS control the Display Card to turn off the Display.
-
Page 30: Pci Configuration
Chapter 4 Reload Global Timer Event: When Enabled, an event occurring on each device listed below restarts the global time for Standby Mode. IRQ[3-7,9-15], NMI Primary IDE 0 Primary IDE 1 Secondary IDE 0 Secondary IDE 1 Floppy Disk Serial Port Parallel Port PCI CONFIGURATION The PCI Configuration Setup option is used to configure the PCI add-on Cards on PCI... - Page 31 Award BIOS Setup Guide A short description of the screen items follows: PNP OS Installed: Set this option to Yes if the operating system installed in the computer is Plug and Play-aware (e.g. Windows 95). Resources Controlled By: The Award Plug and Play BIOS can automatically configure all the boot and Plug and Play compatible device.
-
Page 32: Integrated Peripherals Setup Menu
Chapter 4 INTEGRATED PERIPHERALS SETUP MENU The Integrated Peripherals setup option is need to change the values of the I/O chipset registers for I/O functions. ROM PCI/ISA BIOS (2A69JD1F) INTEGRATED PERIPHERALS AWARD SOFTWARE, INC. IDE HDD Block Mode : Enabled Onboard Parallel Port : 378/IRQ7 IDE Primary Master PIO... - Page 33 Award BIOS Setup Guide IDE Primary Master UDMA/IDE Primary Slave UDMA/IDE Secondary Master UDMA/IDE Secondary Slave UDMA: Available selection are “Auto” or “Disabled”. To choose “Auto”, the system BIOS will scan the IDE device and decide Ultra DMA supported or not.
-
Page 34: Load Setup Defaults Menu
Chapter 4 LOAD SETUP DEFAULTS MENU This Main Menu item uses the default setup values. Use this option as a diagnostic aid if the system behaves erratically. Choose this item and the following message appears: “Load SETUP Defaults (Y/N)? N” To use the Power-On defaults, change the prompt to “Y”... -
Page 35: Ide Hdd Auto Detection
Award BIOS Setup Guide 4.11 IDE HDD AUTO DETECTION When users can not find the Hard Disk information, it is very helpful to use this option. Choose this item and press <Enter>. After couple seconds, the screen will appear the Hard Disk information and following message: “SELECT PRIMARY MASTER OPTION(N=SKIP): N”... -
Page 36: Software Installation
CHAPTER 5 SOFTWARE INSTALLATION In order to let the system board to work efficiently, a series of drivers have to installed according to the operating system used. The drivers may be delivered via CD-ROM or floppy diskettes. The device driver installation procedures from CD-ROM and floppy diskettes are similar. -
Page 37: Sound Driver Installation
Chapter 5 SOUND DRIVER INSTALLATION This section is valid for the system with sound chip built in. Windows 3.1 Under Windows 3.1, insert the ESS ES1869 Sound Driver & Utility Disk 1 diskette into the floppy drive (say A:) Click File on the menu bar in Windows 3.1 Select Run command by clicking Run Type A:\WIN31\SETUP (A: being the letter of the floppy drive) Follow the on screen instructions to complete the installation... -
Page 38: Introduction
Software Installation 5.4.1 INTRODUCTION The AudioRack32 enables you to take advantage of your computer's audio capabilities with all of the controls conveniently in one compact space. You can play audio CDs, wave files (in .WAV and .AUD formats), and MIDI files (in .MID and .RMI formats). - Page 39 Chapter 5 In the Run dialog box, type the letter of the drive and setup (for example, A:\ARCK32\SETUP), then click OK. The first AudioRack32 Setup dialog box appears. Note the instructions, then click Next to proceed or Cancel to leave Setup. Next the Choose Destination Location dialog box appears.
- Page 40 Software Installation If you wish to install the AudioRack32 in a directory other than the default directory, enter the directory path in the Browse dialog box. When you are done click OK or Cancel to return to the Choose Destination Location dialog box.
-
Page 41: Uninstalling The Audiorack32
Chapter 5 Upon successful completion of the AudioRack32 installation, the following message will be displayed. 5.4.3 UNINSTALLING THE AudioRack32 To remove the AudioRack32 from your system, start by clicking on (but not releasing) Start on the task bar. Move the cursor to Settings and select Control Panel. -
Page 42: Flash And Dmi Utility
CHAPTER 6 FLASH AND DMI UTILITY AWARD FLASH UTILITY This section will provide instructions to guide you through updating your old BIOS. The file name we use to program here is test.bin, and the file name to save old BIOS is 2A59F000.OLD. - Page 43 Chapter 6 If you do not wish to save the old BIOS: Please type “N”, and then press the ENTER key. Then you will be request to answer: “Are You Sure to Program?” Answer “N” if you do not want to program, and then it will exit. To save the old BIOS: Please respond “Y”, and then press the ENTER key.
-
Page 44: Desktop Management Interface (Dmi) Overview
Flash and DMI Utility DESKTOP MANAGEMENT INTERFACE (DMI) OVERVIEW This motherboard can support DMI within the BIOS level. DMI is able to auto- detect and record information pertinent to a computer’s system such as the CPU type, CPU speed, and internal/external frequencies, and memory size. The onboard BIOS will detect as many system information as possible and store those collected information in a 4KB block in the motherboard’s flash EPROM and allow the DMI to retrieve data from this database. - Page 45 Chapter 6 Use the ←→ (left-right) cursors to move the top menu items and the ↑↓ (up-down) cursor to move between the left hand menu items. The bottom of the screen will show the available keys for each screen. Press enter at the menu item to enter the right hand screen for editing. “Edit component”...
- Page 46 Flash and DMI Utility Load DMI File You can load the disk file to memory by entering a drive and path and file name here.
- Page 47 Chapter 6 Save DMI File You can save the DMI (normally only saved to flash ROM) to a file by entering the drive and path here. If you want to cancel save, you may press ESC and a message “Bad File Name” appears here to show it was not saved.
-
Page 48: Quick Guide
APPENDIX A QUICK GUIDE The table below summaries the functions and settings of each jumper of the motherboard. Function Jumper Settings CPU Speed Pentium II 233MHz 1-2 off Selection 3-4 off 5-6 on Pentium II 266MHz JP2: 1-2 on 3-4 on 5-6 off Pentium II 300MHz JP2:...
