- Page 1 PRM-23I E1 High Performance Socket370/Pentium II PCI/AMR Mainboard User’s Guide Edition 3.00 © 1999 DTK Computer, Inc. P/N: 155100-8840...
- Page 3 WARNING For the system to operate normally, please make sure JP2 of the mainboard is set as below. Refer to Fig. 2 in this manual for the location JP2. If JP2 is shorted to 2-3, no CMOS data can be retained. CAUTION The motherboard is an electrostatic sensitive device.
- Page 4 change without notice.
-
Page 5: Table Of Contents
CONTENTS CHAPTER 1 INTRODUCTION CHAPTER 2 JUMPER SETTINGS JUMPERS PRESENTATION GRAPHICAL DESCRIPTION OF JUMPER SETTINGS CPU SPEED JP1 - ONBOARD ETHERNET SELECT JP2 - CLEAR CMOS DATA JP3 - BIOS LOCK/UNLOCK SELECT JP6 - KEYBOARD/MOUSE POWER SELECT RESERVED JUMPERS MEMORY CONFIGUARTION CHAPTER 3 CONNECTOR CONFIGURATION J1 –... - Page 6 CHAPTER 5 DRIVER INSTALLATION VGA ON BOARD DRIVERS INSTALLATION IDE DRIVERS INSTALLATION AUDIO/AC97 ON BOARD DRIVERS INSTALLATION CHAPTER 6 FLASH AND DMI UTILITY AWARD FLASH UTILITY DESKTOP MANAGEMENT INTERFACE (DMI) OVERVIEW APPENDIX A QUICK GUIDE...
-
Page 7: Introduction
CHAPTER 1 INTRODUCTION Preface The motherboard is a 4 layers, microATX form factor high performance PCI/AMR mainboard with Socket 370 or Slot 1 CPU on one board. It includes Intel 810DC100 or 810E system chipset, Realtek 10/100M EtherNet controller, Winbond USB HUB & Winbond W83627HF LPC I/O controller on board. - Page 8 Chapter 1 Chipset • Intel 810DC100 or 810E chipsets & 82801AA ICH • Winbond W83627HF LPC I/O Controller • Winbond W81181D USB HUB • Realtek RTL8139B 10/100Mb EtherNet Controller Main Memory • Memory configurations up to 512MB SDRAM • DIMM socket for SDRAM (3.3V unbuffered). •...
- Page 9 Introduction Fig. 1 Key Components of the Mainboard...
- Page 10 Chapter 1...
-
Page 11: Jumper Settings
CHAPTER 2 JUMPER SETTINGS JUMPERS PRESENTATION Pins 1 and 2 are shorted with a jumper cap. Pins 2 and 3 are shorted with a jumper cap. The jumper is shorted when the jumper cap is placed over the two pins of the jumper. The jumper is open when the jumper cap is removed from jumper. -
Page 12: Graphical Description Of Jumper Settings
Chapter 2 GRAPHICAL DESCRIPTION OF JUMPER SETTINGS Fig. 2 Jumper Location of the mainboard... -
Page 13: Cpu Speed
Jumper Settings CPU SPEED The table below summaries the CPU frequency and settings of each jumper of the motherboard. CPU Type Freq. Bus Freq. 300MHz 333MHz 366MHz Socket370/Pentium II 66MHz 400MHz 433MHz 466MHz 350MHz Pentium II 400MHz 450MHz 450MHz 100MHz 500MHz Pentium III 550MHz... -
Page 14: Jp1 - Onboard Ethernet Select
Chapter 2 JP1 - ONBOARD ETHERNET SELECT Table 2 JP2 - CLEAR CMOS DATA JP2 is used to clear the content of the CMOS Data in the RTC (build in PIIX4 chip). Table 3 JP3 - BIOS LOCK/UNLOCK SELECT Table 4... -
Page 15: Jp6 - Keyboard/Mouse Power Select
Jumper Settings JP6 - KEYBOARD/MOUSE POWER SELECT Table 5 RESERVED JUMPERS JP4 and JP5 are the reserved jumpers. MEMORY CONFIGUARTION The mainboard lets user upgrade system memory via DIMM sockets on the mainboard. On board memory is located in four banks: Bank 0 - 3. Two DIMM sockets are provided for EDO DRAM or Synchronous DRAM. - Page 16 Chapter 2...
-
Page 17: Connector Configuration
CHAPTER 3 CONNECTOR CONFIGURATION Once the mainboard has been fastened into system case, the next step is to connect the internal cables. The internal cables are wire leads with plastic female connectors that attach to the connectors. The mainboard connectors have varying numbers of pins and are the points of contact between the mainboard and other parts of the computer. -
Page 18: J1 - Multiple Function Jumper
Chapter 3 J1 – MULTIPLE FUNCTION JUMPER J1 is a front panel multi-function jumper includes speaker, reset, keylock, harddisk, LED, ACPI (suspend) LED and power button (suspend switch). The pin definition is following figure. Fig. 4 Multiple Function Jumper J2 – USB HUB EXTENSION FOR USB2 & 3 If the Winbond USB HUB chipset exist on board, the USB1 to USB4 will be replaced with the HUB supported USB ports, and the USB1 comes out from J20, USB2 &... -
Page 19: J5, J6 -Primary /Secondary Ide Connectors
Connector Configuration J5, J6 –PRIMARY /SECONDARY IDE CONNECTORS These connectors support the provided IDE hard disk ribbon cable. After connecting the single end to the board, connect the two plugs on the other end to your hard disk or other device. J7 - FLOPPY DRIVE CONTROLLER This connector supports the floppy drive ribbon cable. -
Page 20: J11 - Cd-Rom Audio Connector (Sony)
Chapter 3 3.10 J11 – CD-ROM AUDIO CONNECTOR (SONY) J11 is a four-pin connector, which is used to connect with the Sony CD-ROM audio output. This pin definition is as following: Fig. 6 CD-ROM Audio Connector 3.11 J12 – CD-ROM AUDIO CONNECTOR (MISUMI/ PANASONIC) J12 is four-pin connector, which is used to connect with the Panasonic or Misumi CD-ROM audio output. -
Page 21: J22 - Atx Power Supply Connector
Connector Configuration 3.14 J22 - ATX POWER SUPPLY CONNECTOR J22 is a 2x10 pin male connector. Plug the power connector of the ATX power supply onto the connector. Fig. 8 ATX Power Supply Connector 3.15 J23 – LCD/TV OUT CONNECTOR This is a reserved connector for TV-OUT extension which is a TV Encoder chip on the card to encode the VGA signals to TV composite signals. - Page 22 Chapter 3...
-
Page 23: Amr - Amr Slot
Connector Configuration 3.16 AMR – AMR SLOT Fig. 10 AMR Slot 3.17 SLOT1 – SLOT FOR PENTIUM II/III CPU Slot1 is the slot for Pentium II or Pentium III CPU. Fig. 11 Slot for Pentium II/III CPU... -
Page 24: U1 - Socket370 For Celeron Cpu
Chapter 3 3.18 U1 – SOCKET370 FOR CELERON CPU U1 is the Socket370 for Celeron CPU. Fig. 12 Socket370 for Celeron CPU Fig. 13 I/O Connector 3.19 J16 – AUDIO/MIDI PORT CONNECTOR Three 1/8” female connectors used as speaker, line in and microphones. SPK can be connected to headphones or preferably powered speakers. -
Page 25: J18 - Vga Connector
Connector Configuration 3.21 J18 – VGA CONNECTOR This is a D-Type 15 pin male connector for monitor. 3.22 J19 – SERIAL PORT COM1 This is a D-Type 9 pin male connector for pointing devices or other serial devices. 3.23 J20 – UNIVERSAL SERIAL BUS PORTS 0 & 1 These connectors are two four pin female sockets which are available for connecting USB device. -
Page 26: Retention Mechanism Kits Installation Guide
Chapter 3 3.26 RETENTION MECHANISM KITS INSTALLATION GUIDE Retention Mechanism Kits includes following components: Retention mechanism Assembly Fig. 14 Retention Mechanism Attach Mount Fig. 15... - Page 27 Connector Configuration Before the installation of RM Kits find the six holes on the motherboard for RM installation. The hole position and usage is as following: Fig. 16 Installation Guide Mount the two RM Attach Mounts onto the motherboard from bottom side. These mounts will be used to attach the RM Assembly.
-
Page 28: Award Bios
Chapter 4 CHAPTER 4 AWARD BIOS If the first time installation of this system board, please press the “DEL” key to get into the BIOS Setup while Power-on memory testing, and select “Load Optimized Defaults”, and then select the Frequency/Voltage Control to choose the proper “CPU Clock Ratio” for the CPU installed. -
Page 30: Driver Installation
CHAPTER 5 DRIVER INSTALLATION The ALL-IN-ONE Multimedia CD-ROM will auto execute with a menu displayed when put into CD-ROM Drive. Then the correct product needs to be selected, and the Drivers list will be showed on the right side of the screen: The 810 Drivers, Utility files, Manual & Catalog. Click the 810 Drivers for the drivers of system must be installed. -
Page 31: Ide Drivers Installation
IDE DRIVERS INSTALLATION INF files enable the Intel® 810 and Intel® 820 Chipsets to be recognized by listed operating systems. This installer will unpack updated .INF files into a specified folder. Supported operating system: Microsoft Windows* 95 OSR2.1+ and Windows* 98 operating system Chipset: Intel®... -
Page 32: Flash And Dmi Utility
Chapter 5 CHAPTER 6 FLASH AND DMI UTILITY AWARD FLASH UTILITY This section will provide instructions to guide you through updating your old BIOS. The file name we use to program here is test.bin, and the file name to save old BIOS is 2A69JD1J.OLD. - Page 33 Flash and DMI Utility If you do not wish to save the old BIOS: Please type “N”, and then press the ENTER key. Then you will be request to answer: “Are You Sure to Program?” Answer “N” if you do not want to program, and then it will exit. To save the old BIOS: Please respond “Y”, and then press the ENTER key.
-
Page 34: Desktop Management Interface (Dmi) Overview
Chapter 6 DESKTOP MANAGEMENT INTERFACE (DMI) OVERVIEW This motherboard can support DMI within the BIOS level. DMI is able to auto- detect and record information pertinent to a computer’s system such as the CPU type, CPU speed, and internal/external frequencies, and memory size. The onboard BIOS will detect as many system information as possible and store those collected information in a 4KB block in the motherboard’s flash EPROM and allow the DMI to retrieve data from this database. - Page 35 Flash and DMI Utility Use the ←→ (left-right) cursors to move the top menu items and the ↑↓ (up-down) cursor to move between the left hand menu items. The bottom of the screen will show the available keys for each screen. Press enter at the menu item to enter the right hand screen for editing. “Edit component”...
- Page 36 Chapter 6 Load DMI File You can load the disk file to memory by entering a drive and path and file name here.
- Page 37 Flash and DMI Utility Save DMI File You can save the DMI (normally only saved to flash ROM) to a file by entering the drive and path here. If you want to cancel save, you may press ESC and a message “Bad File Name” appears here to show it was not saved.
-
Page 38: Appendix A Quick Guide
Chapter 6 APPENDIX A QUICK GUIDE The table below summaries the functions and settings of each jumper of the motherboard. Function Jumper Settings Enabled (Default) JP1: short Onboard Ethernet Select Disabled JP1: open Normal (Default) JP2: 1-2 short Clear CMOS Data Clear CMOS JP2:... - Page 39 It’ll auto execute and has a drivers selection list after a while. If it can not auto execute, just click the “AUTORUN.EXE” in the root of CD-ROM and please select the product as PRM-23I E1. And follow the drivers list sequence below to install the drivers.
