Code Parameter
d.06 Target domestic hot wa-
ter temperature
d.08 Status of the 230 V room
thermostat
d.09 Target heating flow tem-
perature that is set on
the eBUS room thermo-
stat
d.10 Status of the internal
pump in the heating cir-
cuit
d.11 Status of the heating
circuit's shunt pump
d.13 Status of the domestic
hot water circuit's circula-
tion pump
d.14 Operating mode of the
modulating pump
d.15 Pump speed
d.16 Status of the 24 V room
thermostat (ON/OFF)
d.17 Heating control
d.18 Pump overrun operating
mode
d.20 Maximum target do-
mestic hot water tem-
perature
d.21 Status of the warm start
for domestic hot water
d.22 Status of the DHW de-
mand
d.23 Status of the heat de-
mand
d.27 Function of relay 1
(multi-functional module)
d.28 Function of relay 2
(multi-functional module)
d.33 Fan speed target value
d.34 Value for the fan speed
44
Values
Unit
Min. Max.
℃
Current value
–
Current value
℃
Current value
–
Current value
–
Current value
–
Current value
–
0 5
Current value %
–
Current value
– – –
–
1 3
℃
50 55
–
Current value
–
Current value
–
Current value
–
1 10
–
1 10
Current value rpm
Current value rpm
Increment, select, explanation
–
OF = Open (0 V, no heating mode)
on = Closed (230 V, heating mode)
–
OF = Pump off
on = Pump on
Applies to: Installed heating circuit shunt pump
(optional)
OF = Pump off
on = Pump on
Applies to: Installed domestic hot water circuit
circulation pump (optional)
OF = Pump off
on = Pump on
0 = Speed-regulated (automatic pump operation in
levels 1 to 5)
1 = PWM = 55 %
2 = PWM = 65 %
3 = PWM = 75 %
4 = PWM = 85 %
5 = PWM = 95 %
1; 2; 3; 4; 5 = Fixed rotational speeds → Section
"Setting the pump output"
Hi = 100%
OF = Heating off
on = Heating on or eBUS control used
0 = Flow temperature
1 = Return temperature (adjustment for underfloor
heating. If you have activated the return temperat-
ure control, the automatic heat output determina-
tion function is not active.)
1 = Comfort (continuously operating pump)
3 = Eco (pump runs intermittently)
Increment = 1
This function is displayed by the warm start is
not actually available for this product. OF is per-
manently displayed since the function is deactiv-
ated.on = function is activated and available
OF = No current requirement
on = Current requirement
OF = Heating off (Summer mode)
on = Heating on
1 = Circulation pump
2 = External pump
3 = Cylinder charging pump
4 = Extraction hood
5 = External solenoid valve
6 = Fault message
7 = Solar pump (omitted)
8 = eBUS remote control
9 = Anti-legionella pump
10 = Solar valve
Fan speed = Display value x 1000
Fan speed = Display value x 1000
Installation and maintenance instructions Compact 0020313973_01
Factory
setting
–
–
–
–
–
–
0
–
–
0
3
55
–
–
–
1
2
–
–
