  • Page 1 CONNECTION English AND OPERATIONAL MANUAL Control unit CUL01 2020 www.alutech-group.com...
  • Page 3: Table Of Contents

    Storage, tranportation and utilisation ................8 Warranty ..........................8 Certificate of comissioning ....................9 Warranty repair ........................10 ALUTECH Group of companies has the right to change and complement item construction and this document without warning. CONNECTION AND OPERATIONAL MANUAL. CONTROL UNIT CUL01...
  • Page 5: General Provisions And Safety Measures

    Do not start item installation or operation if you have any questions or you do not understand something. If necessary, contact the nearest ALUTECH Group of Companies service department or office. Follow the safety measures of the existing normative documents and of this manual.
  • Page 6: Item Description

    Wires connected to the sockets cross section, mm max 2.5 Ingress protection rating IP54 (professional installation) Operating temperatures range, º С − 25…+ 40 Power cord length / wire cross section not less than 1 m / 1.5 m CONNECTION AND OPERATIONAL MANUAL. CONTROL UNIT CUL01...
  • Page 7: Packaged Electronic Circuit

    A control unit body has a packaged electronic circuit installed to which electrical devices are connected (pic. 2). See the circuit elements list in Table 2. 2A-T 24V+ Sens Vent+ 400V 230V REL2 LED1 HPT-IN REL1 PE PE MOTOR Pic. 2. Packaged electronic circuit CONNECTION AND OPERATIONAL MANUAL. CONTROL UNIT CUL01...
  • Page 8 If the jumper is removed, the LED is off. If security sensors are not plugged in (J10 and J11 adapters), jumpers must be installed (pic. 2). If a security sensor is plugged in, remove the jumper. CONNECTION AND OPERATIONAL MANUAL. CONTROL UNIT CUL01...
  • Page 9 2 is pushed, two electric motor phase wires are to change their positions. 24V+ 24V+ Sens Sens BN — BK — Vent+ Vent+ BU — Pic. 6. Security sensor connection Pic. 5. Valve connection (sectional doors position sensor) CONNECTION AND OPERATIONAL MANUAL. CONTROL UNIT CUL01...
  • Page 10: Operation

    • breakages and defects when there is no planned service maintenance and inspection; • absence of a completed (filled-in) manual. More information about service departments: http://www.alutech-group.com/feedback/service/ CONNECTION AND OPERATIONAL MANUAL. CONTROL UNIT CUL01...
  • Page 11: Certificate Of Comissioning

    Safety and operational instruction has been conducted. Applicant (consumer) ������������������������������������������������������������ ������������������������������������������������������������������������������ name, address and telephone Applicant’s (customer’s) signature ���������������������������� signature �������������������������������������������������������� print name CONNECTION AND OPERATIONAL MANUAL. CONTROL UNIT CUL01...
  • Page 12: Warranty Repair

    - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Repair organisation ������������������������������������������������������������� List of repair works ������������������������������������������������������������� ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ Date of repair ������������������������������������������������������������������ Responsible for repair ������������������������������� signature ������������������������������������������������� print name CONNECTION AND OPERATIONAL MANUAL. CONTROL UNIT CUL01...
  • Page 13 COMMENTS COMMENTS ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ ������������������������������������������������������������������������������ CONNECTION AND OPERATIONAL MANUAL. CONTROL UNIT CUL01...
  • Page 16 10, Selitskogo str. 220075, Minsk, Republic of Belarus Tel. +375 (17) 330 11 00 Fax +375 (17) 330 11 01 www.alutech-group.com R7090126 Art. 03.2018...
