- Page 1 Operating Instructions Main electronics VEGAPULS 6X Two-wire 4 … 20 mA/HART Document ID: 66441...
-
Page 2: Table Of Contents
Supplement ..........................10 Technical data ........................ 10 Safety instructions for Ex areas: Take note of the Ex specific safety instructions for Ex applications. These instructions are attached as documents to each instrument with Ex approval and are part of the operating instructions. Editing status: 2022-02-07 Main electronics • VEGAPULS 6X... -
Page 3: About This Document
Symbols used Document ID This symbol on the front page of this instruction refers to the Docu- ment ID. By entering the Document ID on www.vega.com you will reach the document download. Information, note, tip: This symbol indicates helpful additional infor- mation and tips for successful work. -
Page 4: For Your Safety
That is why we have introduced an environment management system with the goal of continuously improving company environmental pro- tection. The environment management system is certified according to DIN EN ISO 14001. Please help us fulfil this obligation by observing the environmental instructions in this manual: • Chapter " Packaging, transport and storage" • Chapter " Disposal" Main electronics • VEGAPULS 6X... -
Page 5: Product Description
– If necessary, further certificates Principle of operation Application area The electronics module " Main electronics" is a replacement module for the sensor VEGAPULS 6X two-wire 4 … 20 mA/HART. Packaging, transport and storage Packaging Your instrument was protected by packaging during transport. Its capacity to handle normal loads during transport is assured by a test based on ISO 4180. -
Page 6: Mounting
Position in the housing - Double chamber Fig. 2: Double chamber housing Position of the mains electronics in the electronics compartment Procedure Proceed as follows: 1. Switch off voltage supply 2. Unscrew the lid of the electronics compartment Main electronics • VEGAPULS 6X... - Page 7 7. Screw in the holding screws and tighten them 8. Insert the connection cables into the terminals again 9. Screw the housing lid back on The electronics exchange is now finished. As a rule, an exchange of electronics must be documented internally if Ex applications are involved. Main electronics • VEGAPULS 6X...
-
Page 8: Setup
It is recommended to recreated an existing false signal suppression after an electronics exchange. If this is not possible, for example, because the vessel is filled, the false signal suppression can be imported also via the DTM. However, the false signal suppression should be updated or recreated next time when the vessel is empty. Main electronics • VEGAPULS 6X... -
Page 9: Dismount
If personal data is stored on the old device to be disposed of, delete it before disposal. If you have no way to dispose of the old instrument properly, please contact us concerning return and disposal. Main electronics • VEGAPULS 6X... -
Page 10: Supplement
7 Supplement Supplement Technical data Technical data The technical data are listed in the operating instructions manual of the respective device. Main electronics • VEGAPULS 6X... - Page 11 Notes Main electronics • VEGAPULS 6X...
- Page 12 Subject to change without prior notice © VEGA Grieshaber KG, Schiltach/Germany 2022 VEGA Grieshaber KG Am Hohenstein 113 Phone +49 7836 50-0 77761 Schiltach E-mail: info.de@vega.com...
