Features

CPU

1. Supports Intel Pentium P54C/MMX (P55C) CPUs at 75
~ 233 MHz
2. Supports Cyrix 6x86(L) CPUs at PR120 + ~ PR166 + MHz
(PR200 + MHz is optional)
3. Supports AMD K5, K6 CPUs at PR75 ~ PR233
4. Provides SOCKET 7 ZIF Socket
5. Supports CPU dual voltage circuit.

Chipset

1. Intel 82430VX chipset
2. PCI Rev 2.1 compliant

L2 Cache

1. Onboard supports 256K/512k write back cache with
Pipelined Burst SRAMs

Main Memory

1. Memory range from 4MB (minimum) to 128MB
(maximum) with DRAM Table Free configurations
2. Supports Fast Page Mode/EDO/BEDO/Synchronous
DRAM with 60ns/70ns DRAM speed
3. Supports 4 pcs 72pin SIMM sockets and 2 pcs 168pin
DIMM sockets (3.3V unbuffered type)
