Canon imagePROGRAF iPF8300 Basic Guide No.1 Basic Manual page 35

Replace the shaft cleaner
1
After the message is displayed regarding Shaft Cleaner
replacement, press ▲ or ▼ to select Yes , and then press
the OK button.
After the Carriage is moved, the Display Screen indicates
Open Upper Cover .
2
Open the Top Cover .
• If you do not respond within two minutes, shaft cleaner replacement is canceled. In this case, repeat the
procedure.
3
Hold the Shaft Cleaner on the right side of the Carriage
by the grips (a) and pull it to the right to remove it.
4
Holding the new Shaft Cleaner by the grips (a), attach it
to the Carriage .
• Be sure to put the used Shaft Cleaner in the small box before putting it in the larger box with the used
Maintenance Cartridge for disposal.
5
Close the Top Cover .
The Carriage moves back into position.
35
Replacing the Maintenance Cartridge
a
a
