- Page 1 Compact Flyscreen OEM INSTALLATION MANUAL...
- Page 2 TABLE OF CONTENTS Introduction Safety Resources Required Installation Post Installation Check Introduction The flyscreen door system keeps out insects and debris while allowing fresh airflow. The flyscreen can only be used while the coach's door is open. Open the flyscreen door before closing the coach's door. For information on the assembly or individual components of this product, please visit: https://support.lci1.com/entry-doors.
- Page 3 Installation Position the retracted flyscreen portion of the screen door over the wall and place the bottom rail of the screen door on the floor (Fig. 1). Center the flyscreen door within the coach's door opening. Make sure the side of the latch door—where the inner side of the spacer profile is located—is next to but NOT on it.
- Page 4 Install 10 OEM-supplied screws (1-10) in the order shown in figure 2. At screw locations 5-8 (Fig. 2), the flyscreen door material tends to move out of position. Apply enough pressure to those mounting areas to keep the profile straight. Fig.
- Page 5 The size and length of the screws needed to install the flyscreen door varies depending on the dimension of the OEM-supplied spacer used. Refer to the following table for suggested screw sizes for a given spacer being used. Spacer - inch (mm) Screw - inch (mm) 0 (0) #6 x 3/4 (3.5 x 20)
- Page 6 The contents of this manual are proprietary and copyright protected by Lippert Components, Inc. (LCI). LCI prohibits the copying or dissemination of portions of this manual unless prior written consent from an authorized LCI representative has been provided. Any unauthorized use shall void any applicable warranty. ...
