- Page 1 INSTALLATION, SERVICE & PARTS MANUAL Series: PF5CU 1-1/2” x 1-1/2” PF7CU 2” x 2” Universal Drive /Frame Mtd 877-24PUMPS • www.powerflopumps.com ISP No: PF5_7CU - 1/2021...
-
Page 2: General Safety Information
® Power-Flo is a registered trademark of Power-Flo Technologies Inc. Other brand and product names are trademarks or registered trademarks of their respective holders. Alteration Rights Reserved. 7/08, 7/09, 3/10, 2/11, 4/12, 1/13, 5/13, 8/14, 12/19, 9/2020, 1/2021... -
Page 3: Specifications
BEARING-PUMP END Single Row, Ball, Grease Lubricated Neoprene Flap type valve, with steel Series: PF5CU CHECK VALVE weight 1-1/2” x 1-1/2” OPTIONAL Bronze Volute PF7CU 2” x 2” Universal Drive /Frame Mtd Power-Flo Pumps & Systems • 877-24PUMPS • www.powerflopumps.com... - Page 4 Not for pumping flammable liquids or hazardous materials that is not compatible with pump materials. Model Weight Suction Discharge PF7CU 82 lbs 2” NPT 2” NPT Not for pumping flammable liquids or hazardous materials that is not compatible with pump materials. Power-Flo Pumps & Systems • 877-24PUMPS • www.powerflopumps.com...
- Page 5 PF5CU Self-Priming Universal Pumps Performance Power-Flo Pumps & Systems • 877-24PUMPS • www.powerflopumps.com...
- Page 6 PF7CU Self-Priming Universal Pumps Performance Power-Flo Pumps & Systems • 877-24PUMPS • www.powerflopumps.com...
- Page 7 (16) and fill the pump body completely impeller-to-volute clearance of .015” max. with solids free liquid. In freezing weather the control selected properly match the prime pump with warm water. electrical specifications of the pump. Power-Flo Pumps & Systems • 877-24PUMPS • www.powerflopumps.com...
- Page 8 (18). (29), press off of shaft (23). faces of rotating member and stationary are together. Handle all seal parts with care. REASSEMBLE PUMP IN OPPOSITE ORDER. Do Not damage lapped faces. Power-Flo Pumps & Systems • 877-24PUMPS • www.powerflopumps.com...
-
Page 9: Repair Parts
Self-Priming Universal Pumps For Repair Part Please supply: Model Number and MFG Date as shown on Repair Parts Name Plate, and Part Description and Part Number as shown on Parts List. Figure 1 Power-Flo Pumps & Systems • 877-24PUMPS • www.powerflopumps.com... - Page 10 Seal & Gasket Kit - Includes items 8, 9, 10, 14, 18, 32 ◊ PF5CUSEAL-KIT PF5CUSEAL-KIT = Aquire standard hardware locally. ◊ = Seal/Gasket Kit = Check Valve Assembly = Supplied as individual items Power-Flo Pumps & Systems • 877-24PUMPS • www.powerflopumps.com...
-
Page 11: Troubleshooting Chart
2. Follow service instructions for installing seal NOTE: Power-Flo Pumps & Systems assumes no responsibility for damage or injury due to disassembly in the field. Disassembly of the pumps or supplied accessories other than at Power-Flo Pumps & Systems or its authorized service centers, automatically voids warranty. -
Page 12: Limited Warranty
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights and you may also have other rights which vary from state to state. Power-Flo Pumps & Systems • 877-24PUMPS • www.powerflopumps.com...
