- Page 1 USER’S AND INSTALLER’S MANUAL V6.2 REV. 05/2022...
-
Page 2: Table Of Contents
00. CONTENT 01. SAFETY INSTRUCTIONS INDEX STANDARDS TO FOLLOW 01. SAFETY INSTRUCTIONS This product is certified in accordance with European STANDARDS TO FOLLOW Community (EC) safety standards. 02. PACKAGE INSIDE PACKAGE This product complies with Directive 2011/65/EU of the 03. MOTOR European Parliament and of the Council, of 8 June 2011, on TECHNICAL SPECIFICATIONS the restriction of the use of certain hazardous substances... -
Page 3: Safety Instructions
01. SAFETY INSTRUCTIONS 01. SAFETY INSTRUCTIONS GENERAL WARNINGS the motorized door or gate from being triggered involuntarily. • This manual contains very important safety and usage information. WARNINGS FOR TECHNICIANS very important. Read all instructions carefully before beginning the installation/usage procedures and keep this manual in a safe place •... - Page 4 • Keep this manual in a safe place to be consulted whenever necessary. • If the product has contact with fluids without being prepared, it must MOTORLINE ELECTROCELOS SA. Travessa do Sobreiro, nº29 immediately disconnect from the power supply to avoid short circuits, 4755-474 Rio Côvo (Santa Eugénia)
-
Page 5: Package
03. MOTOR INSIDE PACKAGE TECHNICAL SPECIFICATIONS JAG specifications are as follow: In the package you will find the following components: 01 • 02 swing motors JAG400 JAG600 02 • 01 Control Board 230V 230Vac 50/60Hz 230Vac 50/60Hz 03 • 02 remote controls (4 channels) •... -
Page 6: Installation
03. MOTOR 04. INSTALLATION TECHNICAL SPECIFICATIONS HEIGHT OF THE SUPPORTS JAG 400 || 600 dimensions are the following: Motor must be installed with a small inclination , to prevent water infiltration through the extension arm. For this, the front support must be fixed to the gate with a height lower than the height of the rear support. -
Page 7: Interior Opening Installation Quotas
04. INSTALLATION INTERIOR OPENING INSTALLATION QUOTAS On the Illustrated diagrams below and on the next page, are the dimensions for the installation of the automated system. * The installation of opening stopper is not mandatory. (EXTERIOR) Axis of rotation of the motor, on the front bracket Legend: Dimension X - Horizontal distance between hinge axis of the door and the axis axle of the motor. -
Page 8: External Opening Installation Quotas
04. INSTALLATION EXTERNAL OPENING INSTALLATION QUOTAS On the Illustrated diagrams below and on the next page, are the dimensions for the installation of the automated system. * The installation of opening stopper is not mandatory. Legend: Dimension X - Horizontal distance between hinge axis of the door and the rear axis of the motor. *Opening Dimension Y - Vertical distance between hinge axis of the door and the rear axis of the motor. -
Page 9: Installation Steps 8A
04. INSTALLATION 04. INSTALLATION INSTALLATION STEPS INSTALLATION STEPS Pay attention to the installation dimensions mentioned on pages 4B, 5 and 6! 03 • Test the movement. • Install the pins removed earlier on each side with a small amount of lubricant for less friction. - Page 10 04. INSTALLATION 04. INSTALLATION MICROS ADJUSTMENT MICROS ADJUSTMENT 01 • Unlock the motor (see page 4A). 06 • Take the gate to the open position. 02 • Loosen the 3 front screws, remove the cover and the profile cover. 07 • Loosen the screw shown in the image (24), so that it is possible to move the micro-switch in the profile.
-
Page 11: Installation Map
04. INSTALLATION INSTALLATION MAP CONTROL WARNING MOTOR BOARD LAMP ANTENNA SELECTOR EXTERIOR PHOTOCELLS JUNCTION BOX EXTERIOR INTERIOR PHOTOCELLS PHOTOCELLS GATE STOPPER LEGEND: Connection cables It is important to use mechanical stoppers in the opening and closing position of the gate. It is important to use junction boxes for connections between motors, components and If not respected, components of the automation may suffer efforts for which they were not control board. -
Page 12: Connection Scheme
06. COMPONENTS TEST 05. CONNECTION SCHEME 110V/230V MOTOR 24V MOTOR To detect which are the components with problems in a 24V JAG automatism installation, it is necessary to conduct tests with a direct connection to a external power supply (battery 24V). In the scheme below is shown how it should be done this link. -
Page 13: 230V/110V Motor
06. COMPONENTS TEST 230V/110V MOTOR To detect if the malfunction is on the control board or on the motor All tests must be performed by qualified per- NOTES: is, sometimes, necessary to perform tests with connection directly sonnel due to serious danger associated with •... -
Page 14: Maintenance
07. MAINTENANCE MAINTENANCE • Clean stainless steel arm • With a cloth soaked in lubricant spray, wipe any residue that accumulates on the motors stainless steel arm. • Apply a small amount of spray lubricant on the arm and using a dry cloth remove the ex- cess, leaving a homogeneous layer of lubri- cant over the arm. -
Page 15: Troubleshooting
11). diagnosis; A) SECURITY SYSTEMS: B) START SYSTEMS: All MOTORLINE control boards have LEDs that • Unlock motor and easily allow to conclude which devices are 1 • Close with a shunt all safety systems 1 • Disconnect all wires from START terminal 1 •...
