- Page 1 DFS360 | User Manual WHALETEQ DFS360 / DFS360D User Manual PC Software Version 1.0.1.18 Revision 2022-08-08...
- Page 2 This document could contain technical inaccuracies or typographical errors. Changes are periodically made to the information herein; these changes will be incorporated in future revisions of this document. WhaleTeq Co. LTD. is under no obligation to notify any person of the changes.
-
Page 3: Table Of Contents
DFS360 | User Manual Contents 1 Introduction .................. 6 1.1 Concept ...................... 6 1.2 Applications ....................6 2 Specification .................. 7 2.1 General Specifications ................7 2.2 Compliance Specifications ................. 7 2.3 Energy Measurement Specifications ............8 2.4 ECG Signal Specifications ................ - Page 4 DFS360 | User Manual 5.4.1 Command Function .....................34 6 Standalone Operation ..............35 7 Calibration and Validation ............35 8 Troubleshooting ................36 9 Cautions ..................36 10 Ordering Information ..............37 11 Package Contents ................ 40 12 Revision History ................
- Page 5 Table 10: Ordering info. for DFS360 ..........37 Table 11: Ordering info. for DFS360D ..........37 Table 12: Optional DFS360 / DFS360D Paddle Box Set ....38 Table 13: Optional Software Add-On Pack ........39 Table 14: Optional Tool ..............39 Table 15: Optional Calibration Service and Warranty Extension ..
- Page 6 Figure 2: Front Side of DFS360 / DFS360D ........9 Figure 3: Rear Side of DFS360 / DFS360D ........10 Figure 4: Left Side of DFS360 / DFS360D (Top: DFS360; Bottom: DFS360D) ................. 11 Figure 5: Right Side of DFS360 / DFS360D ........11 Figure 6: Wiring Diagram ..............
-
Page 7: Introduction
DFS360D is designed to withstand more intense defibrillation shocks over longer stretches; it takes shocks at 15-second intervals, meaning a boost of testing capacity. in all, DFS360 / DFS360D is a durable tester to speed up AED or defibrillator automatic production. Applications... -
Page 8: Specification
Remote (PC Software via API and SDK) Modes Housing: ABS Plastic Mechanical Size (L x W x H): 19.0 x 12.5 x 6.0 (cm) Weight: DFS360: 665g / DFS360D: 815g Compliance Specifications Table 2: Compliance Specifications Items Specifications CE: IEC/EN61010-1:2010 + A1:2016; Pollution... -
Page 9: Energy Measurement Specifications
Accuracy: ±0.05 ms Sample rate 250 kHz (4 μs sample) Maximum Average DFS360: 12 W, for 1 defib. Pulse of 360 J every 30 sec. Power DFS360D: 24 W, for 1 defib. pulses of 360 J every 15 sec. ECG Signal Specifications... -
Page 10: Instrument Familiarization
(Max. 5K Sample Rate) Normal Sinus Rhythm (NSR): 30 to 240 (increment by 1) BPM Amplitude range: V 0.5 ~ 5.0mV, step 0.5 mV Instrument Familiarization Figure 1: Top Side of DFS360 / DFS360D Front Figure 2: Front Side of DFS360 / DFS360D... -
Page 11: Rear
DFS360 | User Manual AED Input Ports: Use AED cables provided to connect device under test (an AED or a defibrillator) to the DFS360 / DFS360D. Rear Figure 3: Rear Side of DFS360 / DFS360D USB Port: Use to supply power. Also, it can be used to connect to the computer for sending commands and transferring data. -
Page 12: Left And Right Side
DFS360 | User Manual Left and Right Side Figure 4: Left Side of DFS360 / DFS360D (Top: DFS360; Bottom: DFS360D) Figure 5: Right Side of DFS360 / DFS360D Air Inlet: Allow ventilation during long hours of operation. External Load Box Port: Connect this port to the external load box with various resistance values for tests. -
Page 13: Wiring Diagram
3.5.1 Connection Diagram and Precautions Connect the AED cable to DFS360 / DFS360D. 。 Do not put the AED cable on DFS360 / DFS360D main console. 。 The AED cable should not twist together. Figure 7: Correct Wiring Diagram of the AED Cable After connecting the AED cable, connect DFS360 / DFS360D and PC / Laptop with the USB cable. -
Page 14: Getting Started
DFS360 | User Manual 。 The USB cable should not be placed on DFS360 / DFS360D main console. Figure 8: Correct Wiring Diagram of the USB Cable Make sure the output voltage of the USB cable is between 4.75V ~ 5.25V (The minimum input voltage that DFS360 / DFS360D can work is 4.5V). -
Page 15: Software Installation
Note: If DFS software can’t be executed properly, or this is the first time using WhaleTeq’s product, please refer to the two sections below (4.3 and 4.4) to confirm that the USB driver and Microsoft .Net Framework 4.0 are both installed. -
Page 16: Microsoft .Net Framework Installation
⚫ If Windows 7 can’t recognize DFS360 unit, please / DFS360D download “mchpcdc.inf” from WhaleTeq’s website. This driver is provided by Microchip®, and is intended to be used with PIC microprocessors which have built-in USB functions. ⚫ When the USB module is connected for the first time, select Manual Installation, and point to the folder containing the above file. -
Page 17: Pc Software And Firmware Update
User cannot update the DFS software, please contact WhaleTeq’s service team (service@whaleteq.com). PC Software Operation Software Function Introduction When opening DFS360 AP, User will see the figure below on the screen. Figure 9: AP Interface Table 5: AP Interface Function Introduction... - Page 18 Graph Setup: Set the time range and display of voltage or current on Shock Function Buttons Waveform. Waveform Error Report: Allow users to report issues to WhaleTeq in case of software errors. Consistency and Availability Analysis: Superimpose multiple test waveforms to confirm the consistency of quality on multiple DUTs or the availability of a single DUT.
-
Page 19: Table 6: Setting List Introduction
Ventricular Tachycardia Plus (the faster VT) Atrial Fibrillation Asystole Right-click the Settings button and the settings below will show. Figure 10: Setting List Table 6: Setting List Introduction Item Name Description Check whether the DFS360 AP is the Check for Updates latest version. -
Page 20: 5.1.1 Function Buttons Operation
Chinese, Simplified Chinese, and English. 5.1.1 Function Buttons Operation Function Buttons on the right of DFS360 / DFS360D AP screen will be elaborated from top to bottom: Folder After every test, the system will automatically save the test result in three... -
Page 21: Figure 12: Waveform Details
DFS360 | User Manual Waveform Details After each test, users can click the Waveform Details button to display the positions of parameters and characteristic points on the defibrillation waveform. Figure 12: Waveform Details Graph Setup Users can set the time range (30ms, 40ms, or 60ms) and display of voltage or current for the Shock Waveform. -
Page 22: Figure 14: Error Report Window
DFS360 | User Manual Waveform Error Report When users encounter any software errors, click the Waveform Error Report button to describe the issue in the window and report to WhaleTeq. Figure 14: Window Error Report Consistency and Availability Analysis (optional function) -
Page 23: Figure 16: Check Desired Test Results For Analysis
DFS360 | User Manual Figure 16: Check Desired Test Results for Analysis (2) After checking desired test results, click Reproducibility button to bring up the Reproducibility Analysis window for the analysis result. The upper section of the window shows shock waveforms; the lower section shows energy (in Joules). -
Page 24: Figure 17: Consistency And Availability Analysis (Top: The Consistency Of Shock Waveforms Of Multiple Duts; Bottom: The Availability Of A Single Dut)
DFS360 | User Manual Figure 17: Consistency and Availability Analysis (Top: The Consistency of Shock Waveforms of Multiple DUTs; Bottom: The Availability of a Single DUT) Standard Waveforms Select Sine, Square or Triangle waveforms with adjustable BPM, frequency, and amplitude for essential performance test and calibration. -
Page 25: Customize Ecg Waveform (Optional Function)
DFS360 | User Manual 5.1.2 Customize ECG Waveform (optional function) After purchasing this function, users will receive an Activation Key. Input the key to activate the function and bring up the ECG Waveform window. Users can add 10 sets of user-defined waveforms or raw data at most. - Page 26 5mV; if not, then it will remain the same. 4. The waveform automatically offsets to 0mV. 5. Support only WhaleTeq format when loaded. DFS360 AP supports text file (*.txt) only and file content describes as below: File Format: [sampling frequency]...
- Page 27 DFS360 | User Manual The limitation is related to the available memory size of PC system. If PC system has available memory for 1GB, the maximum number of single channel sample data would be 131,072. number of signals This number must be greater than 1.
- Page 28 DFS360 | User Manual 0.284856 0.282452 0.276442 0.270433 0.271635 0.268029 0.262019 0.259615 0.254808 0.256010 0.254808 0.253606 … 0.515625 0.519231 0.521635 0.526442 0.531250 0.534856 0.539663 0.543269 0.546875 0.554087 0.560096 0.561298 0.561298 0.561298 0.560096 0.555288 0.551683 0.550481 0.546875 0.542067 0.534856 0.531250 0.524038 0.520433...
-
Page 29: Pc Software Operation Instructions
ECG Output for selection. Figure 22: Complete Customized Waveform Settings PC Software Operation Instructions Note: The maximum voltage that the DFS360 / DFS360D can receive is 3000V. Please confirm the DUT’s voltage specification of defibrillation is within 3000V before conducting the test. -
Page 30: Figure 23: Select Test Items
Child mode, and test results may be inaccurate because the shock energy exceeds the upper voltage limit. 2. Click the Start button, and the DFS360 / DFS360D will start sending the ECG signals to the AED / defibrillator. Users may check the working status of the DFS360 / DFS360D by the Test List. -
Page 31: Table 8: Shock Result Introduction
DFS360 | User Manual Figure 24: Shock Result Figure 25: Shock Waveform Details Table 8: Shock Result Introduction Item Name Description If there are more than one test item, users need to wait for 30 seconds to start the next one. - Page 32 DFS360 | User Manual Item Name Description and y-axis to check information of a designated range. Right-click on the waveform to bring up Reset Cursor (the orange frame on figure 25) to reset the cursors for reselecting. The Type of Shock Show the type of shock waveform.
-
Page 33: Over Heat Warning And Function Protection
DFS360 | User Manual Over Heat Warning and Function Protection 5.3.1 AP Display Status When the heat within the DFS360 / DFS360D is too high, the test functions will pause until the temperature drops. High temperature Figure 26: High-Temperature Alert When the temperature in the DFS360 / DFS360D is under control, the Start button will be unlocked. -
Page 34: 5.3.2 Dfs Status Led
5.3.3 Fan Behavior When the temperature in the DFS360 / DFS360D is too high, the fan in the DFS360 / DFS360D will start operating. When the temperature in the DFS360 / DFS360D drops to normal temperature, the fan stops. -
Page 35: 5.4.1 Command Function
DFS360 | User Manual 5.4.1 Command Function Table 9: Command Function Command Function Description Send ECG Waveform Arrhythmia Selection (Ventricular Fibrillation – Coarse/ Fine, Ventricular Tachycardia, Ventricular Tachycardia Plus, Atrial Fibrillation, Asystole) Patient Simulator (NSR) 30 to 240 (increment by 1) BPM (optional) User-defined pattern: max. -
Page 36: Standalone Operation
DFS360 AP on the USB-connected computer, the DFS360 / DFS360D device is in Standalone mode. In this mode, the ECG pattern that DFS360 / DFS360D automatically plays is NSR at 5 mV, 80 BPM. Calibration and Validation It is recommended to calibrate DFS360 / DFS360D annually. Calibration and validation both require traceable equipment. -
Page 37: Troubleshooting
2. Ensure the USB cable and the AED cable are not entangled with each other. (Please refer to sec. 3.5.1 for detailed information.) 3. Ensure good airflow around the ventilation holes of the DFS360 / DFS360D. 4. Follow color code and/or labeling when connecting the DFS360 / DFS360D and AED / defibrillator via AED cable. -
Page 38: Ordering Information
DFS360 | User Manual Ordering Information Standard Test System Table 10: Ordering info. for DFS360 Image Part No. Description DFS360 AED/Defibrillator 300-DFS36S Tester Main Unit Open-ended AED cable K22-0500101 (Banana Male), 0.5 meter (Black) Open-ended AED cable K22-0500102 (Banana Male), 0.5 meter... -
Page 39: Table 12: Optional Dfs360 / Dfs360D Paddle Box Set
Compact Splicing Connector USB Transfer Cable: Type-A K27-1800304 to Type-C (Male to Male), 1.8 meter Optional DFS360 / DFS360D Paddle Box Set Table 12: Optional DFS360 / DFS360D Paddle Box Set Part No. Description Image DFS Tester Docking Base for 300-DFPDOCK... -
Page 40: Table 13: Optional Software Add-On Pack
Extend the limited warranty from (1) year to (3) years. Note: Due to the properties of DFS360 / DFS360D parts, in addition to the one- year warranty, its warranty is also based on the actual number of shocks: DFS360: 15000 times... -
Page 41: Package Contents
DFS360 | User Manual DFS360D: 30000 times The DFS360 / DFS360D software automatically counts the number of shocks and reminds users to return to WhaleTeq for inspection. Either of the two kinds of warranty will be adopted, and the adoption is based on which one’s conditions are fulfilled first. -
Page 42: Revision History
3.5.1 Connection Diagram and Precautions Ch 5 PC Software Operation Ch 10 Ordering Information Ch 11 Package Contents Contact WhaleTeq WHALETEQ Co., LTD service@whaleteq.com | (O)+886 2 2517 6255 8F., No. 125, Songjiang Rd., Zhongshan Dist., Taipei City 104474, Taiwan...
