Linear Technology DC1954A Demo Manual page 7

parts list
ITEM QTY REFERENCE
DC1954A-B Required Circuit Components
1 1
2 0 R1, R6
3 1 R11
4 4 Z1-Z4
5 2 Z5, Z6
6 1 U1
DC1954A-C Required Circuit Components
1 1
2 0 R1
3 2 R6, R11
4 2 Z1-Z2
5 4 Z3, Z4, Z5, Z6
6 1 U1
DC1954A-D Required Circuit Components
1 1
2 3 R1, R6, R11
3 6 Z1, Z2, Z3, Z4, Z5, Z6
4 1 U1
DEMO MANUAL DC1954A
PART DESCRIPTION
GENERAL BOM
RES., CHIP, 0402
RES., CHIP, 100Ω 1/16W, 5%, 0402
CAP., X7R, 0.1µF 16V, 10%, 0402
RES., CHIP, 0Ω, 0402
I.C., QFN36UFF-4X7
GENERAL BOM
RES., CHIP, 0402
RES., CHIP, 100Ω 1/16W, 5%, 0402
CAP., X7R, 0.1µF 16V, 10%, 0402
RES., CHIP, 0Ω, 0402
I.C., QFN36UFF-4X7
GENERAL BOM
RES., CHIP, 100Ω 1/16W, 5%, 0402
RES., CHIP, 0Ω, 0402
I.C., QFN36UFF-4X7
MANUFACTURER/PART NUMBER
OPT
NIC, NRC04J101TRF
AVX, 0402YC104KAT2A
NIC, NRC04Z0TRF
LINEAR TECH., LTC6954IUFF-2#PBF
OPT
NIC, NRC04J101TRF
AVX, 0402YC104KAT2A
NIC, NRC04Z0TRF
LINEAR TECH., LTC6954IUFF-3#PBF
NIC, NRC04J101TRF
NIC, NRC04Z0TRF
LINEAR TECH., LTC6954IUFF-4#PBF
dc1954af
7
