Summary of Contents for Asko CCT9051S
- Page 1 INSTRUCTIONS FOR USE CCT9051S Cooker hood...
-
Page 2: Table Of Contents
Contents Use .............. Changing the colour lighting temperature ..Introduction ..........Maintenance ..........Description hood ......... Cleaning ............Description user interface ......Filter indicator ..........Description remote control ......Lighting ............Operation ............ Battery of the remote ........Pairing the remote ........Technical data .......... -
Page 3: Use
-5.2 dBm EIRP average (calculated) Maximum antenna gain -7 dBi Hereby, ASKO Appliances AB declares that the radio equipment type Cooker hood (Ceiling unit) is in compliance with Directive 2014/53/EU. The following symbols are used throughout the manual and they have the following meanings:... -
Page 4: Description Hood
Description hood 1. User interface 2. LED bar 3. Edge extraction panel 4. Grease filter 5. Latch Description user interface 1. Filter reset button, signals when filters require cleaning 2. Speed level 1 indicator 3. Speed level 2 indicator 4. Speed level 3 indicator 5. -
Page 5: Description Remote Control
Description remote control 1. Timer function 2. Increase light intensity 3. Colder light temperature 4. Decrease light intensity 5. Decrease air extraction capacity 6. Clean Air function 7. Warmer light temperature 8. Switch on/off lighting 9. Increase air extraction capacity 10. -
Page 6: Operation
Operation Pairing the remote This remote control must be paired to the cooker hood before first use. 1. Start up the appliance (power on). The hood will start in ‘pairing mode for 5 minutes. 2. Activate the Remote pairing mode by holding ‘c and ‘w for 3 sec. 3. -
Page 7: Switch On The Boost Setting
Operation Switch on the boost setting 1. Press and hold the ‘+ button for at least 1 second. The boost setting is switched on for 10 minutes. The speed level 4 indicator will flash during this period. The original extraction setting will be reactivated after this period. 2. -
Page 8: Switching On Recirculation Mode
Operation Switching on recirculation mode When the light and fan are off, simultaneously hold the timer key and the light key until the filter indicator flashes 3 times. The carbon filter indicator is activated. Switching off recirculation mode When the light and fan are off, simultaneously hold the timer key and the light key until the filter indicator lights up for 3 seconds and then turns off. -
Page 9: Switching The Light On And Off
Operation Switching the light on and off 1. Press and hold the light key for 1 second. The light switches on at maximum strength. 2. Press and hold the ‘increase light or ‘decrease light key to set the lighting intensity. 3. -
Page 10: Maintenance
Maintenance Cleaning WARNING! Important! For all maintenance, first switch off the mains power to the cooker hood by pulling the plug out of the socket or by turning off the home's master switch. The hood needs to be cleaned regularly, both inside as well as outside (at least as often as the grease filter). Do not use abrasive cleaning products. - Page 11 Maintenance Removing cassette filter 1. Switch off the motor and lighting. 2. Push in the latches and open the panel. 3. Open the filter s access latch. Support the filter with your hand. 4. Remove the filter from the hood. Cleaning The filters can be cleaned in the dishwasher.
-
Page 12: Filter Indicator
Maintenance Active carbon filters The regenerable active carbon filter must be washed by hand with neutral cleaning products, or in the dishwasher at a maximum temperature of 65 °C (the washing should be done without any plates, dishes, cups, etc. in the machine). Do not use washing detergent. Remove the excess water without damaging the filter, remove the holder and let the filter dry in the oven for at least 40 minutes at a maximum temperature of 70 °C. -
Page 13: Battery Of The Remote
Maintenance Battery of the remote TIP! When the batteries are replaced the pairing connection will remain. Replace the batteries in time, as the receiving distance will be shortened if the voltage of the battery is too low. Don t forget to remove the batteries if you don t use the remote for a long time. Don t leave the remote lying upside down on a conductive surface. -
Page 14: Technical Data
Technical data EU Product Sheet Data determined according to: Standard EN61591 and Commission Regulations (EU) no. 65/2014 and (EU) no. 66/2014. CCT9051S Trademark ASKO Type of model WC90BA-BCC01 Annual Energy Consumption (AEC ) [kWh/a] 35.3 hood Energy efficiency class Fluid Dynamic Efficiency (FDE ) [%] 37.6... -
Page 15: Environmental Aspects
Environmental aspects Tips for energy-efficient cooking with hoods • Use a low extractor setting and use the highest setting (boost) if necessary. • A well-ventilated kitchen makes the range hood more efficient. • Clean filters regularly and replace filters when needed to keep the filter efficiency high, as a saturated filter cannot perform and leads to longer usage times. - Page 16 843825 We reserve the right to make changes.
