- Page 1 The Zonix ™ Ceiling Fan Net Weight 9.07 kg (20 lbs) Model No. FP4620**-220 OWNER’S MANUAL READ AND SAVE THESE INSTRUCTIONS...
-
Page 2: Table Of Contents
Fanimation. 7. Fanimation reserves the right to modify or discontinue any product at any time and may substitute any part under this warranty. 8. Under no circumstances may a fan be returned without prior authorization from Fanimation. The receipt of purchase must ac- company authorized returns and must be sent freight prepaid to Fanimation. -
Page 3: Unpacking Instructions
• Motor Coupling Cover Fanimation. Substitution of parts or accessories not • Adapter Plate designated for use with this product by Fanimation could • Lower Cover Assembly • Wood Blades (3) result in personal injury or property damage. Contact •... -
Page 4: Energy Effi Cient Use Of Ceiling Fans
8 - 9 feet above the floor for optimal airflow. Consult your down into the occupied space.Remember to adjust your Fanimation Retailer for optional mounting accessories. thermostat when using your ceiling fan - additional energy and dollar savings could be realized with this simple step! Turn Off When Not in the Room Ceiling fans cool people, not rooms. -
Page 5: How To Assemble Your Ceiling Fan
How to Assemble Your Ceiling Fan 1. Remove the Hanger Ball by loosening the setscrew in the Hanger Ball until the ball falls freely down the Downrod. (Figure 1) Remove the Pin from the Downrod, then remove the Hanger Ball. Retain the Pin and Hanger Ball for reinstallation in Step 5. -
Page 6: How To Hang Your Ceiling Fan
How to Hang Your Ceiling Fan ▲WARNING To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before hanging. NOTE: If you are not sure if the outlet box is grounded, contact a licensed electrician for advice, as it must be grounded for safe operation. -
Page 7: How To Wire Your Ceiling Fan
How to Wire Your Ceiling Fan If you feel that you do not have enough electrical wiring knowledge or experience, have your fan installed by a licensed electrician. CAUTION 220-240VAC Terminal Block Household on Bracket Wiring Supply To reduce the risk of fire and electrical shock, be sure BRN–To Motor L Brown to Motor electricity is turned off before installing the wall control. -
Page 8: Installing The Canopy Housing
How to Wire and Operate Your CW40-220 Wall Control (cont’d) ▲WARNING To avoid possible fire or shock, make sure that the electrical wires are completely inside the outlet box and not pinched between the wall plate and the wall. ▲WARNING Check to see that all connections are tight, including ground, and that no bare wire is visible at the wire connectors, except for the ground wire. -
Page 9: Mounting The Fan Blades And Lower Housing Cover
Mounting the Fan Blades and Switch Cup Cover Assembly INSTALLATION NOTE Do not connect fan blades until the fan is completely installed. Installing the fan with blades assembled may result in damage to the fan blades. ▲WARNING Fan Blade To reduce the risk of personal injury, do not bend the blades when installing, balancing or cleaning the fan. -
Page 10: Maintenance
Mounting the Fan Blades and Switch Cup Cover Assembly (cont’d) 6. Assemble the Switch Cup Cover onto the assembled Switch Cup Support Plate with three screws provided. (Figure 6) 7. Restore Power and your fan is now wired to be turned on and off from the wall speed control. -
Page 11: Trouble Shooting
Trouble Shooting ▲WARNING For your own safety turn off power at fuse box or circuit breaker before trouble shooting your fan. Trouble Probable Cause Suggested Remedy 1. Fuse or circuit breaker blown. 1. Check main and branch circuit fuses or circuit breakers. -
Page 12: Parts List
Parts List Model FP4620**-220 Ref. # Description Part # Hanger Bracket Assembly with Screws AP255BL Downrod/Hanger Ball Assembly Containing: Hanger Ball Assembly Downrod ADR1-6** Clevis Pin Hairpin Clip Ceiling Canopy PG154** Canopy Screw Cover AP260** Motor Coupling Cover with Grommet AP1115** Fan Motor Assembly AMA4620**-220... -
Page 13: Exploded-View Illustration
The Zonix ™ Model FP4620**-220 Exploded-View Figure 1 NOTE: The illustration shown is not to scale or its actual confi guration may vary. Product/parts are subject to change without notice. - Page 14 10983 Bennett Parkway Zionsville, IN 46077 Toll Free (888) 567-2055 FAX (866) 482-5215 Outside U.S. call (317) 733-4113 Visit Our Website @ www.fanimation.com Copyright 2008 Fanimation 2009/04...
