- Page 1 The Involution ™ Ceiling Fan Net Weight 9.07 kg (20 lbs) Model No. FP4520** OWNER’S MANUAL READ AND SAVE THESE INSTRUCTIONS...
-
Page 2: Table Of Contents
Fanimation. 7. Fanimation reserves the right to modify or discontinue any product at any time and may substitute any part under this warranty. 8. Under no circumstances may a fan be returned without prior authorization from Fanimation. The receipt of purchase must ac- company authorized returns and must be sent freight prepaid to Fanimation. -
Page 3: Tools Needed For Assembly
Fanimation. Substitution of parts or accessories not designated for use with this product by Fanimation could result in personal injury or property damage. Contact your retail store for missing or damaged parts. -
Page 4: Energy Effi Cient Use Of Ceiling Fans
If ceiling height allows, install the fan 8 - 9 feet above the floor for optimal airflow. Consult your Fanimation Retailer for optional mounting accessories. Turn Off When Not in the Room Ceiling fans cool people, not rooms. If the room is unoccupied, turn off the ceiling fan to save energy. -
Page 5: How To Assemble Your Ceiling Fan
How to Assemble Your Ceiling Fan 1. Remove the Hanger Ball by loosening the setscrew in the Hanger Ball until the ball falls freely down the Downrod. (Figure 1) Remove the Pin from the Downrod, then remove the Hanger Ball. Retain the Pin and Hanger Ball for reinstallation in Step 5. -
Page 6: How To Hang Your Ceiling Fan
How to Hang Your Ceiling Fan ▲WARNING To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before hanging. NOTE: If you are not sure if the outlet box is grounded, contact a licensed electrician for advice, as it must be grounded for safe operation. -
Page 7: How To Wire Your Ceiling Fan - Cw40 Wall Control
How to Wire Your Ceiling Fan - CW40 Wall Control If you feel that you do not have enough electrical wiring knowledge or experience, have your fan installed by a licensed electrician. ▲WARNING To avoid possible electrical shock, be sure electricity is turned off at the main fuse box before wiring. -
Page 8: Mounting And Assembling The Floating Rings Or Nameplate
Assembling and Mounting the Floating Rings or Nameplate INSTALLATION NOTE Do not connect fan blades until the Floating Rings or Nameplate Plug are installed. Floating Rings Installation: 1. Carefully slide the two Floating Rings into the slot with the upward motion to avoid scratching the finish on the fan housing. -
Page 9: Mounting The Fan Blades And Switch Cup Assembly
Mounting the Fan Blades and Switch Cup Assembly INSTALLATION NOTE Do not connect fan blades until the fan is completely installed. Installing the fan with blades assembled may result in damage to the fan blades. ▲WARNING To reduce the risk of personal injury, do not bend the blades when installing, balancing or cleaning the fan. - Page 10 Mounting the Fan Blades and Switch Cup Assembly (cont’d) 5. Assemble the Switch Cup Assembly onto the assembled Adapter with three screws. (Figure 5) NOTE: The reverse switch is located on the Switch Cup Assembly. (Figure 5) 6. Assemble the Lower Cover onto the assembled Switch Cup Adapter by twisting in the clockwise direction.
-
Page 11: Operating Instructions - Cw40 Wall Control
Operating Instructions - CW40 Wall Control 1. Restore electrical power to the outlet box by turning the electricity on at the main fuse box. 2. Your fan model is equipped with a 4-position, 3-speed, slide switch wall control. The operating sequence is as follows: •... -
Page 12: Parts List
Before discarding packaging materials, be certain all parts have been removed When ordering repair parts, always give the following information: Contact your retail store for repair parts. Parts List Model FP4520** Description How To Order Parts • Part Number • Part Description •... -
Page 13: Exploded-View Illustration
Model FP4520** Exploded-View NOTE: The illustration shown is not to scale or its actual confi guration may vary. Product/parts are subject to change without notice. The Involution ™ Figure 1... -
Page 14: Trouble Shooting
For your own safety turn off power at fuse box or circuit breaker before trouble shooting your fan. Trouble 1. Fuse or circuit breaker blown. 2. Loose power line connections to the fan, or loose switch wire connections in the switch housing. 1. - Page 16 10983 Bennett Parkway Zionsville, IN 46077 (888) 567-2055 FAX (866) 482-5215 Outside U.S. call (317) 733-4113 Visit Our Website @ www.fanimation.com Copyright 2008 Fanimation 2008/01...
