EU-292 User's manual
Step 3 – assign comfort temperature or economical temperature to particular hours
An hour which is being edited is displayed on the controller screen. In order to assign comfort
temperature, press
automatically moves on to editing the next hour.
The parameters of the weekly program are displayed at the bottom of the screen: hours to which
comfort temperature has been assigned are displayed whereas hours to which economical
temperature has been assigned are not displayed.
Example:
The following screenshot presents daily settings of
program no. 7 for Monday
24⁰⁰-01⁵⁹- economical temperature
02⁰⁰-06⁵⁹- comfort temperature
07⁰⁰-14⁵⁹- economical temperature
15⁰⁰-21⁵⁹- comfort temperature
22⁰⁰-00⁵⁹- economical temperature
NOTE
When the user finishes the editing process by pressing EXIT button, the controller
returns to the main screen view and this program is selected as the current program.

VII.c.9) Floor sensor

NOTE
This parameter is not available in the menu if the additional sensor has not been
connected to the floor sensor contact or when the cooling mode is selected.
This function enables the user to activate the floor sensor. When the floor sensor is enabled, the
contact status depends also on the floor temperature. The contact remains closed (the device is
on) when the floor temperature is lower than the minimum value (regardless of the room
temperature). When the minimum temperature of the floor sensor has been exceeded, the contact
remains closed until the pre-set room temperature
is reached. If the floor sensor temperature exceeds
the maximum value, the contact is opened (the
device is disabled) regardless of the current room
temperature.
Use or to activate/deactivate the floor sensor
by selecting ON or OFF.
. In order to select economical temperature,
21
press . The controller
Edited hour
