Mi-Light MiBOXER FUT086 Instructions

0298-2

Product Features

This product is a 433MHz frequency wireless remote control. We use LoRa SPSP
Modem technology. It can control specified 433MHz series smart lights with color
changing, color temperature, saturation and brightness adjustable.

Technical Parameters

Model No.: FUT086
Voltage: 3V(AAA * 2PCS)
Transmitting Power: 10dBm
Standby Power Consumption: 16uA
RF: 433MHz
Modulation Method: LoRa Spread Spectrum
Control Distance: 50m
Size: 197.5mm*47mm*19mm

Products Key Diagram

Indicator light
Saturation / CCT Control
Speed- / 60S Delay OFF
" " Zone ON
(Link/Unlink)
Touch the color ring to change colors.
Under white light mode, adjust color temperature;
Under color light mode, change color saturation.
Slide the brightness slider to adjust the brightness.
Press the button to get white light.
W
Touch ON button, turn on the linked device.
ON
Touch OFF button, turn off the linked device.
OFF
Dynamic mode switching button.
M
Short press: Lower the dynamic mode speed.
S-
Long press under static mode, lamp will blink one time into 60S Delay OFF mode.
Short press: Accelerate the dynamic mode speed.
S+
Long press under static mode, lamp will blink one time into 10min Delay OFF mode.
LoRa 433MHz RF Remote
Model No.: FUT086
(Lamps 0.5m underwater)
White light
Master ON
Subordinate New Brand
ON
S-
1
3
5
7
LoRa 433MHz RF Remote
47mm
ON W OFF
S- M S+
1 2
3 4
5 6
7 8
LoRa 433MHz RF Remote
W OFF
M S+
2
4
6
8
19mm
Antenna
Color Ring
Brightness Dimming
Master OFF
Speed+ /
10min Delay OFF
Mode
" " Zone OFF
24mm
53mm
