VIVOTEK
Installation option A:
A-1. See below for the mounting holes used with applicable conduit boxes.
1
4-11/16" square gang box
3
5
A-2. Use the A holes to mount the base plate to a wall.
Using A holes
The mounting plate and conduit bracket are separately
purchased. The 1/2" threaded pipe and hex nut are
user-supplied.
18 - User's Manual
4" square and round box
2
4
4" octagon box
Cantex 3/4" type FSE 2 Gang, Outdoor/Indoor electrical box
Generic 3/4" conduit box enclosure, 3/5 holes
x4
1" single gang box
1
1
2
2
5
4
5
3
3
5
4
5
2
2
1
1
